traefik 沒有重定向到 https

我正在嘗試使用 docker、letencrypt 和 traefik 建立一個家庭自動化伺服器。也使用 duckdns 作為 ddns。我在同一台機器上還有一些其他容器，例如“sickrage”等。

我已開啟路由器上的連接埠 80 和 443 並將其轉發到我的 ubuntu 18.04 伺服器。當我嘗試透過 http 連線到ickrage.myserver.duckdns.org 時，出現以下錯誤：

**Your connection is not private**
Attackers might be trying to steal your information from sabnzbd.myserver.duckdns.org
NET::ERR_CERT_AUTHORITY_INVALID

這是我的 traefik.toml 檔案：

    logLevel = "WARN" #DEBUG, INFO, WARN, ERROR, FATAL, PANIC
defaultEntryPoints = ["http", "https"]

# WEB interface of Traefik - it will show web page with overview of frontend and backend configurations
[api]
  entryPoint = "traefik"
  dashboard = true
  address = ":8080"

# Force HTTPS
[entryPoints]
  [entryPoints.http]
  address = ":80"
    [entryPoints.http.redirect]
     entryPoint = "https"
  [entryPoints.https]
  address = ":443"
    [entryPoints.https.tls]

[retry]


[file]
  watch = true
  filename = "${USERDIR}/docker/traefik/rules.toml"

# Let's encrypt configura
[acme]
caServer = "https://acme-v02.api.letsencrypt.org/directory"
email = "[email protected]"     #any email id will work
storage="${USERDIR}/docker/traefik/acme/acme.json"
entryPoint = "https"
acmeLogging=true
onDemand = false #create certificate when container is created
onHostRule = true
  # Use a HTTP-01 acme challenge rather than TLS-SNI-01 challenge
  # uncomment 2 lines for subdirs
#[acme.httpChallenge]
[acme.dnsChallenge]
provider = "duckdns"
entryPoint = "https"
  # uncomment follwoing for suubsomains
#[[acme.domains]]
  #main = "myserver.duckdns.org"
#[[acme.domains]]
  #main = "*.myserver.duckdns.org"
#[acme.dnsChallenge]
  #provider = "duckdns"
  #delayBeforeCheck = 0

# Connection to docker host system (docker.sock)
[docker]
endpoint = "unix:///var/run/docker.sock"
domain = "myserver.duckdns.org"
watch = true
# This will hide all docker containers that don't have explicitly
# set label to "enable"
exposedbydefault = false

以及我的 docker-compose 檔案的部分內容：

    ---
version: "3.6"
services:
  #############################################   Frontends               ############################
  #############################################   Traefik - Reverse proxy  ###########################
  traefik:
    hostname: traefik
    image: traefik:latest
    container_name: traefik
    restart: always
    domainname: ${DOMAINNAME}
    command: --api --docker --docker.domain=${DOMAINNAME} --docker.watch --loglevel=DEBUG
    #command: --api --docker --docker.domain=docker.localhost --docker.watch --loglevel=DEBUG
    networks:
      - default
      - traefik_proxy
    depends_on:
      - duckdns
    environment:
      - TOKEN=${DUCKDNS_TOKEN}
    ports:
      - "80:80"
      - "443:443"
      - "8008:8080"
    labels:
      - "traefik.enable=true"
      - "traefik.backend=traefik"
      - "traefik.port=8080"
      - "traefik.protocol=http"
        #- "traefik.frontend.auth.basic=patrick:$$2y$$05$$a8dtYfcMqH.kUFq3zZPGqe9kq7Tyok7.3/mKdMa1NaCuSwAZ0InOq"
        #- "traefik.frontend.rule=Host:${DOMAINNAME}; PathPrefixStrip: /traefik"
      - "traefik.frontend.rule=Host:traefik.${DOMAINNAME}"
      - "traefik.docker.network=traefik_proxy"
      - "traefik.frontend.entryPoints=https"
      - "traefik.frontend.headers.SSLRedirect=true"
      - "traefik.frontend.headers.STSSeconds=315360000"
      - "traefik.frontend.headers.browserXSSFilter=true"
      - "traefik.frontend.headers.contentTypeNosniff=true"
      - "traefik.frontend.headers.forceSTSHeader=true"
      - "traefik.frontend.headers.SSLHost=dellubuntu.duckdns.org"
      - "traefik.frontend.headers.STSIncludeSubdomains=false"
      - "traefik.frontend.headers.STSPreload=true"
      - "traefik.frontend.headers.frameDeny=true"
        #- "traefik.frontend.auth.basic.users=${HTTP_USERNAME}:${HTTP_PASSWORD}"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ${USERDIR}/docker/traefik/acme/acme.json:/acme.json
      - ${USERDIR}/docker/traefik/traefik.toml:/traefik.toml
      - ${USERDIR}/docker/letsencrypt/config/etc/letsencrypt:/le-ssl
      - ${USERDIR}/docker/traefik:/etc/traefik
      - ${USERDIR}/docker/shared:/shared
  #Letsencrypt                                                    ------------------------ Letsencrypt
  letsencrypt:
    image:  linuxserver/letsencrypt
    container_name: le
    #ports:
      #- "447:443"
    networks:
      - default
      - traefik_proxy
    volumes:
      - ${USERDIR}/docker/letsencrypt/config:/config
    restart: always
    depends_on:
      - portainer
      - heimdall
      - organizr2
      - lazylibrarian
      - plex
      - tautulli
      - headphones
        #- lidarr
      - couchpotato
        #- radarr
      - sickrage
        #- sonarr
        #- airsonic
      - glances
      - ghost
      - transmission-vpn
      - sabnzbd
      - huginn
      - netdata
        #- nextcloud
        #- hydra2
        #- nzbget
        #- jackett
        ##- duplicati
        ##- bazarr
        ##- homeassistant
        ##- filebrowser
        ##- ombi
        ##- elkarbackup
    environment:
      - PUID=${PUID}
      - PGID=${PGID}
      - TZ=${TZ}
      - URL=${DOMAINNAME}
      - EMAIL=${EMAIL}
      - SUBDOMAINS=wildcard
      - VALIDATION=duckdns
      - DUCKDNSTOKEN=${DUCKDNS_TOKEN}
      - ONLY_SUBDOMAINS=false
      - DHLEVEL=4096

我嘗試遵循的範例不包括 LetsEncrypt 容器。我應該刪除它嗎？如果是這樣，LetsEncrypt 將如何追蹤停止和啟動的容器？還有其他方法可以讓它運作嗎？

答案1

Traefik 包含 LetsEncrypt 集成，不需要單獨的 LetsEncrypt 容器。

預設情況下，Traefik 也會終止 TLS 連接，透過 Docker 內部網路以 HTTP 形式將請求傳遞到您的應用程式。您透過網路的連線仍然是安全的，但您連接的應用程式不會知道這一點。您可以透過在服務上指定來重新加密連接traefik.protocol=https，但是您的應用程式將需要維護自己的 TLS 證書，Traefik 需要將其配置為信任，因為這些證書不是來自 LetsEncrypt。
