使用 FFMPEG 自動連線（合併）DVD 中的 VOB 檔案時發生問題

Question

經過大量的實驗和研究，我發現最好的方法是製作一個 BAT 檔案腳本，在變數中建立第二個 BAT 檔案腳本並將其儲存為臨時 BAt 檔案。然後，可以根據所需的 DVD 標題集以及標題集中發現的檔案數量，使用自訂構造的「concat:」參數來建立建構的 BAT 檔案。唯一美中不足的是，幾乎不可能在包含管道 (|) 字元的變數中建構字串。我透過在建置過程中取代「@」字元解決了這個問題，後來使用開源檔案搜尋和取代實用程式將「@」實例變更為「|」。效果很好。注意我使用的是 Windows 10，FFMPEG 版本為 git-2020-06-26-7447045，於 2020 年 6 月下載並安裝。下面是我創建的帶有註釋的批次文件，因此如果有人想做類似的事情，他們可以從這裡開始。我知道它可以改進，但它有效（總是一個好的開始）！

::
:: Batch file to automate conversion of a series of VOB files in a DVD
::  titleset into a single MPG file, via FFMPEG.
:: Pass a name you'd like for the final output movie file in param 1

:: This script needs a a file search and replace utility, and I'm useing
:: SKF (Swiss Army Knife), which is open source and free ...
:: https://sourceforge.net/projects/swissfileknife/

:: Whatever search/replace util you use, you'll have to put it in a
:: 'utilities' folder somewhere in your C: drive, and make sure
:: your system (or USER) PATH variable includes it.

:: Also, unless you have unencrytpted DVD copies to work with, OR a
:: Decryptor that automatically works in the background (like DVD43),
:: you'll have to start with a program like "1-Click DVD Copy (Pro)".
:: In that case you can put the Resulting VIDEO_TS folder in a temp
:: area on your HD. This will make this batch process run faster,
:: and eliminate the needs to waste a blank DVD.

echo off
SETLOCAL ENABLEDELAYEDEXPANSION

:: Set a path where converted ouptput videos will go
:: Temporary files created by this script will also go here.
set outPath="C:\Users\Public\Videos\Temp"
:: set a path to your DVD. Playable DVDs always have aVIDEO_TS folder
set inPathDVD="Q:\VIDEO_TS"
:: In the event you are making unencrypted copies (maybe with 1-Click),
:: set that software to put its output files here. In that case,
:: the parameter you pass this script should match the folder name
:: created by that software!
set inPathHD="C:\Users\Public\Videos\Temp\%1\Video_TS"

:: some variables to construct expecteed files to seach for and gather
set inpTitleSet=VTS_
set inpExt=.VOB
set output=%outPath%\%1.mpg
set outTemp=%outPath%\%1%inpExt%

:: choose whether files come directly from DVD (must be unencrypted!)
:: or defined location on HD
choice /M "Choose Source 1 = DVD  2 = HD Temp Area" /C 12

if ERRORLEVEL 1 set inPath=%inPathDVD%
if ERRORLEVEL 2 set inPath=%inPathHD%

echo input path is: %inPath%
cd /D %inPath%
echo .
echo VOB files from %inpath%...
echo .

:: create filespec for search "VTS_01_*.vob"
set inputFileSpec=%inpTitleSet%*%inpExt%
dir %inputFileSpec%
echo .
:: select desired titleset. Usually the group with the
:: biggest file sizes is  the main movie titleset.
:: You'll be entering the digit after "VTS_0"
choice /M "Select Desired Titleset (digit after VTS_): " /C 12345678
echo you picked %ERRORLEVEL%
set inpTitleSet=%inpTitleSet%0%ERRORLEVEL%_
set inputFileSpec=%inpTitleSet%*%inpExt%

:: use a brute force loop to calculate number of
:: files matching %inputFileSpec% and display them.
:: Note that the '0' file is usually title/menu information,
:: and is skipped by making the %start% var '1'

echo files selected...
echo .
set start=1
:loop0
set tmp=%inpTitleSet%%start%%inpExt%
IF EXIST %tmp% (
echo %tmp%
set /A start=start+1
GOTO loop0
)
set /A count=%start%-1
echo .
:: confirm total files
echo Total Files = %count%

:: safety exit, in odd event where no movie files found
if %count% NEQ 0 GOTO continue1
echo .
echo Must Exit... no Files Found.
goto exit
:continue1

:: Build string containing of file names for FFMPEG "concat:" parameter.
:: Another Brute force loop. Again file *0.VOB will be skipped,
:: by making loop start=1::

:: set an 'empty' variable
set cc=
set start=1
:: create a temp substitute for the pipe "|" character,
:: because | can't be cant be used in a script (^| or similar
::  constructs just won't work here). So I'll use '@' and change it
:: later with a file search/replace utility.
set mypipe=@

:loop1
set tmp=%inpTitleSet%%start%%inpExt%
if %start% EQU %count% set mypipe=
IF EXIST %tmp% (
set cc=%cc%%inp%%tmp%%mypipe%
set /A start=start+1
GOTO loop1
)

:: create whole FFMPEG command as a string
set ffm=ffmpeg -i "concat:%cc%" -f DVD -c copy %output%

:: put it in a tmp batch file
set cmdfile=tmp.bat
echo %ffm%  > %outPath%\%cmdfile%

:: now use SKF to replace the @ chars with |
:: if you have another search/replace utility, feel free to use it.
sfk replace %outPath%\%cmdfile% "/@/|/" -yes -quiet

:: prove string in batch file looks right. You can delete
:: these two lines if you want.
echo Final command...
type %outPath%\%cmdfile%

:: run the new batch file... Give user chance to start process
@pause
call %outPath%\%cmdfile%

:: delete batch file?
del %outPath%\%cmdfile%
echo .
echo .
echo %output% converted file should be ready

ENDLOCAL
:exit

Answer 1

經過大量的實驗和研究，我發現最好的方法是製作一個 BAT 檔案腳本，在變數中建立第二個 BAT 檔案腳本並將其儲存為臨時 BAt 檔案。然後，可以根據所需的 DVD 標題集以及標題集中發現的檔案數量，使用自訂構造的「concat:」參數來建立建構的 BAT 檔案。唯一美中不足的是，幾乎不可能在包含管道 (|) 字元的變數中建構字串。我透過在建置過程中取代「@」字元解決了這個問題，後來使用開源檔案搜尋和取代實用程式將「@」實例變更為「|」。效果很好。注意我使用的是 Windows 10，FFMPEG 版本為 git-2020-06-26-7447045，於 2020 年 6 月下載並安裝。下面是我創建的帶有註釋的批次文件，因此如果有人想做類似的事情，他們可以從這裡開始。我知道它可以改進，但它有效（總是一個好的開始）！

::
:: Batch file to automate conversion of a series of VOB files in a DVD
::  titleset into a single MPG file, via FFMPEG.
:: Pass a name you'd like for the final output movie file in param 1

:: This script needs a a file search and replace utility, and I'm useing
:: SKF (Swiss Army Knife), which is open source and free ...
:: https://sourceforge.net/projects/swissfileknife/

:: Whatever search/replace util you use, you'll have to put it in a
:: 'utilities' folder somewhere in your C: drive, and make sure
:: your system (or USER) PATH variable includes it.

:: Also, unless you have unencrytpted DVD copies to work with, OR a
:: Decryptor that automatically works in the background (like DVD43),
:: you'll have to start with a program like "1-Click DVD Copy (Pro)".
:: In that case you can put the Resulting VIDEO_TS folder in a temp
:: area on your HD. This will make this batch process run faster,
:: and eliminate the needs to waste a blank DVD.

echo off
SETLOCAL ENABLEDELAYEDEXPANSION

:: Set a path where converted ouptput videos will go
:: Temporary files created by this script will also go here.
set outPath="C:\Users\Public\Videos\Temp"
:: set a path to your DVD. Playable DVDs always have aVIDEO_TS folder
set inPathDVD="Q:\VIDEO_TS"
:: In the event you are making unencrypted copies (maybe with 1-Click),
:: set that software to put its output files here. In that case,
:: the parameter you pass this script should match the folder name
:: created by that software!
set inPathHD="C:\Users\Public\Videos\Temp\%1\Video_TS"

:: some variables to construct expecteed files to seach for and gather
set inpTitleSet=VTS_
set inpExt=.VOB
set output=%outPath%\%1.mpg
set outTemp=%outPath%\%1%inpExt%

:: choose whether files come directly from DVD (must be unencrypted!)
:: or defined location on HD
choice /M "Choose Source 1 = DVD  2 = HD Temp Area" /C 12

if ERRORLEVEL 1 set inPath=%inPathDVD%
if ERRORLEVEL 2 set inPath=%inPathHD%

echo input path is: %inPath%
cd /D %inPath%
echo .
echo VOB files from %inpath%...
echo .

:: create filespec for search "VTS_01_*.vob"
set inputFileSpec=%inpTitleSet%*%inpExt%
dir %inputFileSpec%
echo .
:: select desired titleset. Usually the group with the
:: biggest file sizes is  the main movie titleset.
:: You'll be entering the digit after "VTS_0"
choice /M "Select Desired Titleset (digit after VTS_): " /C 12345678
echo you picked %ERRORLEVEL%
set inpTitleSet=%inpTitleSet%0%ERRORLEVEL%_
set inputFileSpec=%inpTitleSet%*%inpExt%

:: use a brute force loop to calculate number of
:: files matching %inputFileSpec% and display them.
:: Note that the '0' file is usually title/menu information,
:: and is skipped by making the %start% var '1'

echo files selected...
echo .
set start=1
:loop0
set tmp=%inpTitleSet%%start%%inpExt%
IF EXIST %tmp% (
echo %tmp%
set /A start=start+1
GOTO loop0
)
set /A count=%start%-1
echo .
:: confirm total files
echo Total Files = %count%

:: safety exit, in odd event where no movie files found
if %count% NEQ 0 GOTO continue1
echo .
echo Must Exit... no Files Found.
goto exit
:continue1

:: Build string containing of file names for FFMPEG "concat:" parameter.
:: Another Brute force loop. Again file *0.VOB will be skipped,
:: by making loop start=1::

:: set an 'empty' variable
set cc=
set start=1
:: create a temp substitute for the pipe "|" character,
:: because | can't be cant be used in a script (^| or similar
::  constructs just won't work here). So I'll use '@' and change it
:: later with a file search/replace utility.
set mypipe=@

:loop1
set tmp=%inpTitleSet%%start%%inpExt%
if %start% EQU %count% set mypipe=
IF EXIST %tmp% (
set cc=%cc%%inp%%tmp%%mypipe%
set /A start=start+1
GOTO loop1
)

:: create whole FFMPEG command as a string
set ffm=ffmpeg -i "concat:%cc%" -f DVD -c copy %output%

:: put it in a tmp batch file
set cmdfile=tmp.bat
echo %ffm%  > %outPath%\%cmdfile%

:: now use SKF to replace the @ chars with |
:: if you have another search/replace utility, feel free to use it.
sfk replace %outPath%\%cmdfile% "/@/|/" -yes -quiet

:: prove string in batch file looks right. You can delete
:: these two lines if you want.
echo Final command...
type %outPath%\%cmdfile%

:: run the new batch file... Give user chance to start process
@pause
call %outPath%\%cmdfile%

:: delete batch file?
del %outPath%\%cmdfile%
echo .
echo .
echo %output% converted file should be ready

ENDLOCAL
:exit
