使用真實 IP 從 LAN 連接到 NAT 後面的伺服器

我有一個小網路。 網路 它有一個連接到網際網路 (WAN) 的防火牆，具有真實的 ​​IP 和 DNS 名稱，也充當內部網路 (LAN) 的 DHCP 伺服器。在防火牆電腦上，我為位於 LAN 中的網站伺服器設定了連接埠轉送。這是我的nftables.conf：

#!/usr/sbin/nft -f

flush ruleset

define lan = eth0
define wan = eth1
define lan_addresses = 192.168.100.0/24
define server_address = 192.168.100.2
define server_http_port = 80
define server_https_port = 443

table firewall {
    map hosts {
        type ipv4_addr . ether_addr : verdict
            elements = {
                192.168.100.2  . 30:01:ED:BD:6B:CB : accept , # SERVER
                192.168.100.3  . 30:01:ED:BD:6B:C1 : accept , # CLIENT
            }
    }
    set remote_allowed {
            type ipv4_addr
            elements = { 91.198.174.192 , 209.51.188.148 }
    }
    chain prerouting {
        type nat hook prerouting priority 0; policy accept;
        # server
        iifname $wan ip protocol tcp tcp dport $server_http_port log prefix "Server HTTP Prerouted " dnat $server_address:$server_http_port
        iifname $wan ip protocol tcp tcp dport $server_https_port log prefix "Server HTTPS Prerouted " dnat $server_address:$server_https_port
    }
    chain postrouting {
        type nat hook postrouting priority 100; policy accept;
        ip saddr $lan_addresses oifname $wan masquerade
        # server
        iifname $wan ip protocol tcp ip saddr $server_address tcp sport $server_http_port log prefix "Server HTTP Postrouted " masquerade
        iifname $wan ip protocol tcp ip saddr $server_address tcp sport $server_https_port log prefix "Server HTTPS Postrouted " masquerade
    }
    chain input {
        type filter hook input priority 0; policy drop;
        # drop invalid, allow established
        ct state vmap {invalid : drop, established : accept, related : accept}
        # allow loopback
        iifname "lo" accept
        # allow ping from LAN
        iifname $lan ip saddr $lan_addresses ip protocol icmp icmp type echo-request accept
        # allow SSH from LAN
        iifname != $wan ip protocol tcp tcp dport 22 accept
        # allow SSH from allowed remotes
        iifname $wan ip protocol tcp ip saddr @remote_allowed tcp dport 22 accept
        # open SQUID, DHCP port for lan
        iifname $lan ip protocol tcp ip saddr $lan_addresses tcp dport {3128, 67} accept
        # LAN nice reject
        iifname != $wan ip saddr $lan_addresses reject with icmp type host-prohibited
    }
    chain forward {
        type filter hook forward priority 0; policy drop;
        ct state {established,related} accept
        # server
        iifname $wan ip protocol tcp ip daddr $server_address tcp dport $server_http_port log prefix "Server HTTP Forwarded To " accept
        iifname $lan ip protocol tcp ip saddr $server_address tcp sport $server_http_port log prefix "Server HTTP Forwarded From " accept
        iifname $wan ip protocol tcp ip daddr $server_address tcp dport $server_https_port log prefix "Server HTTPS Forwarded To " accept
        iifname $lan ip protocol tcp ip saddr $server_address tcp sport $server_https_port log prefix "Server HTTPS Forwarded From " accept
        # only allow selected machines to access internet
        iifname $lan oifname $wan ip saddr . ether saddr vmap @hosts
        iifname $lan oifname $wan reject
    }
    chain output {
        type filter hook output priority 0; policy accept;
    }
}

只要我不嘗試從 LAN 存取我的伺服器，此設定就可以正常工作，在這種情況下我會收到 No route to host錯誤訊息：

> ping 192.168.100.1 # OK
> ping example.com # OK
> curl http://192.168.100.2 # OK
> curl http://192.168.100.1 # `No route to host`
> curl http://93.184.216.34 # `No route to host`
> curl http://example.com   # `No route to host`

如何修改 netfilter 設定以便可以使用防火牆 IP 或 DNS 名稱存取 LAN 伺服器？

PS我需要這個以便我可以正確配置吉茲見面 會議錄音通過吉加西，它使用網站 URL 連接到會議。

PPS 此配置僅允許指定用戶端無限制地存取網際網路。

答案1

我能夠在不接觸防火牆配置的情況下克服這個問題。我已將包含本機伺服器位址和 DNS 名稱的項目新增至用戶端/etc/hosts檔案：

192.168.100.3   example.com

我認為它也可以由 DHCP 伺服器廣播。
