如何在清單（清單包）中用背景顏色標記整行或部分行？

Question

我想使用背景顏色來突出顯示列表中的整行程式碼或行的一部分（子表達式）（以免干擾語法突出顯示）。

我使用lstlistings“listings”套件中的環境。

Answer 1

清單允許轉義到 TeX，因此您可以在背景放置一個框：

\documentclass{standalone}
\usepackage{listings,xcolor}
\lstset{language=c,escapechar=|}
\begin{document}
\begin{lstlisting}
int main (int argc, char ** argv)
{
  |\makebox[0pt]{\color{yellow}\rule[-0.1ex]{30em}{2ex}}|printf("Hello, world\n");
  exit(0);
}
\end{lstlisting}
\end{document}

Answer 2

這是一種基於該網站帖子構建的易於使用的解決方案。

資料來源：

1. 使用清單創建斑馬效果
2. 列表、斑馬效應和折線
3. 在清單中突出顯示行範圍：部分解決方案，但存在擴展問題

代碼：

\documentclass[10pt,a4paper]{article}
    \usepackage[utf8x]{inputenc}
    \usepackage{ucs}
    \usepackage{amsmath}
    \usepackage{amsfonts}
    \usepackage{amssymb}

    \usepackage{xcolor}
    \usepackage{listings}

    \usepackage{pgf}
    \usepackage{pgffor}

% Define backgroundcolor
    \usepackage[
        style=1,
        skipbelow=\topskip,
        skipabove=\topskip
    ]{mdframed}

    \definecolor{bggray}{rgb}{0.85, 0.85, 0.85}
    \mdfsetup{
        leftmargin = 20pt,
        rightmargin = 20pt,
        backgroundcolor = bggray,
        middlelinecolor = black,
        roundcorner = 15
    }
    \BeforeBeginEnvironment{lstlisting}{\begin{mdframed}\vskip-.5\baselineskip}
    \AfterEndEnvironment{lstlisting}{\end{mdframed}}

    \makeatletter
%
% \btIfInRange{number}{range list}{TRUE}{FALSE}
%
% Test if int number <number> is element of a (comma separated) list of ranges
% (such as: {1,3-5,7,10-12,14}) and processes <TRUE> or <FALSE> respectively
%
        \newcount\bt@rangea
        \newcount\bt@rangeb

        \newcommand\btIfInRange[2]{%
            \global\let\bt@inrange\@secondoftwo%
            \edef\bt@rangelist{#2}%
            \foreach \range in \bt@rangelist {%
                \afterassignment\bt@getrangeb%
                \bt@rangea=0\range\relax%
                \pgfmathtruncatemacro\result{ ( #1 >= \bt@rangea) && (#1 <= \bt@rangeb) }%
                \ifnum\result=1\relax%
                    \breakforeach%
                    \global\let\bt@inrange\@firstoftwo%
                \fi%
            }%
            \bt@inrange%
        }

        \newcommand\bt@getrangeb{%
            \@ifnextchar\relax%
            {\bt@rangeb=\bt@rangea}%
            {\@getrangeb}%
        }

        \def\@getrangeb-#1\relax{%
            \ifx\relax#1\relax%
                \bt@rangeb=100000%   \maxdimen is too large for pgfmath
            \else%
                \bt@rangeb=#1\relax%
            \fi%
        }

%
% \btLstHL{range list}
%
        \newcommand{\btLstHL}[1]{%
            \btIfInRange{\value{lstnumber}}{#1}%
            {\color{blue!30}}%
            {\def\lst@linebgrd}%
        }%

%
% \btInputEmph[listing options]{range list}{file name}
%
        \newcommand{\btLstInputEmph}[3][\empty]{%
            \lstset{%
                linebackgroundcolor=\btLstHL{#2}%
                \lstinputlisting{#3}%
            }% \only
        }

% Patch line number key to call line background macro
        \lst@Key{numbers}{none}{%
            \def\lst@PlaceNumber{\lst@linebgrd}%
            \lstKV@SwitchCases{#1}{%
                none&\\%
                left&\def\lst@PlaceNumber{\llap{\normalfont
                \lst@numberstyle{\thelstnumber}\kern\lst@numbersep}\lst@linebgrd}\\%
                right&\def\lst@PlaceNumber{\rlap{\normalfont
                \kern\linewidth \kern\lst@numbersep
                \lst@numberstyle{\thelstnumber}}\lst@linebgrd}%
            }{%
                \PackageError{Listings}{Numbers #1 unknown}\@ehc%
            }%
        }

% New keys
        \lst@Key{linebackgroundcolor}{}{%
            \def\lst@linebgrdcolor{#1}%
        }
        \lst@Key{linebackgroundsep}{0pt}{%
            \def\lst@linebgrdsep{#1}%
        }
        \lst@Key{linebackgroundwidth}{\linewidth}{%
            \def\lst@linebgrdwidth{#1}%
        }
        \lst@Key{linebackgroundheight}{\ht\strutbox}{%
            \def\lst@linebgrdheight{#1}%
        }
        \lst@Key{linebackgrounddepth}{\dp\strutbox}{%
            \def\lst@linebgrddepth{#1}%
        }
        \lst@Key{linebackgroundcmd}{\color@block}{%
            \def\lst@linebgrdcmd{#1}%
        }

% Line Background macro
        \newcommand{\lst@linebgrd}{%
            \ifx\lst@linebgrdcolor\empty\else
                \rlap{%
                    \lst@basicstyle
                    \color{-.}% By default use the opposite (`-`) of the current color (`.`) as background
                    \lst@linebgrdcolor{%
                        \kern-\dimexpr\lst@linebgrdsep\relax%
                        \lst@linebgrdcmd{\lst@linebgrdwidth}{\lst@linebgrdheight}{\lst@linebgrddepth}%
                    }%
                }%
            \fi
        }

    \makeatother


\begin{document}

\begin{lstlisting}[
    language = C,
    linebackgroundcolor = {\btLstHL{4-6,9}},
]
/**
* Prints Hello World.
**/
#include <stdio.h>
}
int main(void) {
    printf("Hello World!");
    return 0;
}
\end{lstlisting}

\end{document}
