metauml安裝與使用錯誤

tag-icon • tag-icon metauml
metauml安裝與使用錯誤

這個問題有點廣泛，但我正在嘗試安裝metauml（我正在使用Mac和texlive）。我下載了該軟體包並運行了安裝腳本，該腳本將一個metauml 目錄放在metapost 目錄下（這是我所期望的）。但是，我無法讓它運行。我有這個代碼：

\documentclass[a4paper,12pt]{article}
\usepackage{amssymb} % needed for math
\usepackage{amsmath} % needed for math
\usepackage[utf8]{inputenc} % this is needed for german umlauts
\usepackage[ngerman]{babel} % this is needed for german umlauts
\usepackage[T1]{fontenc}    % this is needed for correct output of umlauts in pdf
\usepackage[margin=1.5cm]{geometry} %layout

% this is needed for forms and links within the text
\usepackage{hyperref}

% The following is needed in order to make the code compatible
% with both latex/dvips and pdflatex.
\ifx\pdftexversion\undefined
\usepackage[dvips]{graphicx}
\else
\usepackage[pdftex]{graphicx}
\DeclareGraphicsRule{*}{mps}{*}{}
\fi

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% THE DOCUMENT BEGINS                                                %
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{document}
\section{Class diagram}
\includegraphics{metadiagram.mp}
\end{document}

metadiagram.mp 位於同一資料夾中，定義如下：

input metauml;
beginfig(1);
Class.World("World")
       ("-age: int",
        "#ressources: List")
       ("+sayHello(): void");

Class.NoHuman("Human")
       ("-birthday: Date",
        "-nickname: String",
        "-secret: String")
       ("+code(language: Language): Program");

leftToRight(50)(World, NoHuman);
drawObjects(World, NoHuman);

link(aggregation)(NoHuman.w -- World.e);
item(iAssoc)("1")(obj.n     = .2[World.e,NoHuman.w]);
item(iAssoc)("has >")(obj.n = .5[World.e,NoHuman.w]);
item(iAssoc)("0..*")(obj.n  = .8[World.e,NoHuman.w]);

endfig;
end

我收到錯誤：無法確定 metadiagram.mp 中圖形的大小（無 BoundingBox）

有人可以幫忙嗎？

答案1

您不能包含.mp文件，該文件應事先由 Metapost 處理。

如何運行 Metapost 取決於您的作業系統和 TeX 發行版； TeXShop 和 TeXworks 可能有用於此目的的選單項目。一般來說，您可以打開一個終端機窗口，cd進入包含該文件的目錄並執行以下操作

mpost metadiagram.mp

這將產生一個文件metadiagram.1，因為你說的beginfig(1)是

\includegraphics{metadiagram.1}

會做。

請注意，您用於加載的內容graphicx是錯誤的。它應該是

\usepackage{ifpdf}
\usepackage{graphicx}
\ifpdf
  \DeclareGraphicsRule{*}{mps}{*}{}
\fi

還有另一種方法可以繼續進行，就是使用gmp套件。對於您的情況，輸入應該是

\documentclass[a4paper,12pt]{article}
\usepackage{amssymb} % needed for math
\usepackage{amsmath} % needed for math
\usepackage[utf8]{inputenc} % this is needed for german umlauts
\usepackage[ngerman]{babel} % this is needed for german umlauts
\usepackage[T1]{fontenc}    % this is needed for correct output of umlauts in pdf
\usepackage[margin=1.5cm]{geometry} %layout

\usepackage[shellescape]{gmp}

\usepackage{ifpdf}
\ifpdf
\DeclareGraphicsRule{*}{mps}{*}{}
\fi

% this is needed for forms and links within the text
\usepackage{hyperref}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% THE DOCUMENT BEGINS                                                %
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{document}
\section{Class diagram}

\begin{mpost}[mpsettings={input metauml;},use]
Class.World("World")
       ("-age: int",
        "#ressources: List")
       ("+sayHello(): void");

Class.NoHuman("Human")
       ("-birthday: Date",
        "-nickname: String",
        "-secret: String")
       ("+code(language: Language): Program");

leftToRight(50)(World, NoHuman);
drawObjects(World, NoHuman);

link(aggregation)(NoHuman.w -- World.e);
item(iAssoc)("1")(obj.n     = .2[World.e,NoHuman.w]);
item(iAssoc)("has >")(obj.n = .5[World.e,NoHuman.w]);
item(iAssoc)("0..*")(obj.n  = .8[World.e,NoHuman.w]);
\end{mpost}

\end{document}

如果您使用開關（TeXShop 中的首選項允許您啟用它）處理此文件（請注意其中嵌入了 Metapost 來源）-shell-escape，則 Metapost 運行將自動執行。
