pgf 帶線圖的堆疊長條圖

我想繪製一個帶有一個參數的堆積長條圖作為線圖。下面是我的程式碼 -

\begin{tikzpicture}
\pgfplotstableread{Figures/measurements.dat}
\datatable

\definecolor{RYB1}{RGB}{51, 102, 153}
\definecolor{RYB2}{RGB}{102, 51, 0}
\definecolor{RYB3}{RGB}{204, 153, 0}
\definecolor{RYB4}{RGB}{51, 51, 0}
\definecolor{RYB5}{RGB}{204, 102, 0}

\pgfplotscreateplotcyclelist{colorbrewer-RYB}{
    {fill=RYB1},
    {fill=RYB2},
    {fill=RYB3},
    {fill=RYB4},
    {fill=RYB5},
    }

\begin{axis}[
symbolic x coords={1.2.1.a,1.2.3.b,1.1.3.c,1.1.1.d,1.3.1.e,1.3.3.f,3.3.3.g,1.3.3.h,1.1.3.i,1.1.1.j,1.2.1.k,1.3.1.l},
ybar stacked,
legend style={
    legend columns=4,
    at={(xticklabel cs:0.5)},
    anchor=north,
    draw=none
},
axis y line*=none,
axis x line*=bottom,
tick label style={font=\footnotesize},
legend style={font=\footnotesize},
label style={font=\footnotesize},
width=.8\textwidth,
bar width=6mm,
area legend,
x tick label style={rotate=90,anchor=east},
xlabel=Processor Configuration,
ylabel=Clock Cycles,
cycle list name=colorbrewer-RYB,
xtick=data,
xticklabels={1.2.1,1.2.3,1.1.3,1.1.1,1.3.1,1.3.3,3.3.3,1.3.3,1.1.3,1.1.1,1.2.1,1.3.1},
]
    \addplot table[y=C] from \datatable ;
    \addlegendentry{C};
    \addplot table[y=E] from \datatable ;
    \addlegendentry{E};
    \addplot table[y=F] from \datatable ;
    \addlegendentry{F};
    \addplot table[y=D] from \datatable ;
    \addlegendentry{D};
\end{axis}
\end{tikzpicture}

這是數據文件 -

 A  B   C   D   E   F   G
1.2.1.a 2044238 2025137 138 15859   1400    1358
1.2.3.b 2108559 2088724 894 14662   1898    2035
1.1.3.c 3498648 3482495 1610    11490   1405    1302
1.1.1.d 2097564 2089859 871 5021    898 569
1.3.1.e 3489783 3470704 138 15888   1405    1302
1.3.3.f 3496917 3481357 871 11110   1909    1324
3.3.3.g 2110448 2089855 871 16015   2476    885
1.3.3.h 4897582 4875299 1375    17401   1903    1258
1.1.3.i 2800891 2786201 877 10704   1405    1358
1.1.1.j 2740737 2733003 894 5027    898 569
1.2.1.k 3500439 3481371 138 15882   1400    1302
1.3.1.l 2111014 2088720 894 18347   1405    1302

現在在這個圖中參數 D，我希望將其作為線圖而不是長條圖。誰能告訴我應該在程式碼中添加什麼來實現它？

謝謝 ！

答案1

這是解決我的問題的最終程式碼。

\begin{tikzpicture}
  \pgfplotstableread{Figures/measurements.dat}
  \datatable

  \definecolor{RYB1}{RGB}{51, 102, 153}
  \definecolor{RYB2}{RGB}{102, 51, 0}
  \definecolor{RYB3}{RGB}{204, 153, 0}
  \definecolor{RYB4}{RGB}{51, 51, 0}
  \definecolor{RYB5}{RGB}{204, 102, 0}
  \pgfplotscreateplotcyclelist{colorbrewer-RYB}{
    {fill=RYB1},
    {fill=RYB2},
    {fill=RYB3},
    {fill=RYB4},
    {fill=RYB5},
    }

 \begin{axis}[
symbolic x coords={1.2.1.a,1.2.3.b,1.1.3.c,1.1.1.d,1.3.1.e,1.3.3.f,3.3.3.g,1.3.3.h,1.1.3.i,1.1.1.j,1.2.1.k,1.3.1.l},
ybar stacked,
legend style={
    legend columns=4,
    at={(xticklabel cs:0.5)},
    anchor=north,
    draw=none
},
axis y line*=none,
axis x line*=bottom,
tick label style={font=\footnotesize},
legend style={font=\footnotesize},
width=.8\textwidth,
bar width=6mm,
x tick label style={rotate=90,anchor=east},
xlabel=Processor Configuration,
ylabel=Clock Cycles,
cycle list name=colorbrewer-RYB,
xtick=data,
xticklabels={1.2.1,1.2.3,1.1.3,1.1.1,1.3.1,1.3.3,3.3.3,1.3.3,1.1.3,1.1.1,1.2.1,1.3.1},
x label style={at={(0.5,-0.15)}},
]
\addplot table[y=C] from \datatable ;
\addlegendentry{C};
\addplot table[y=E] from \datatable ;
\addlegendentry{E};
\addplot table[y=F] from \datatable ;
\addlegendentry{F};
 \addplot [line legend, thick, sharp plot, stack plots=false] table[y=D] from \datatable ;
\addlegendentry{D};

\end{axis}
\end{tikzpicture}
