使用 KOMA 腳本在三部分錶旁邊正確頂部對齊標題

Question

沒有 的話，事情看起來還不錯threeparttable。

取消註解 Threeparttable 和 tablenotes 會導致標題進入上一段。

\documentclass{scrbook}
%
\usepackage[english]{babel}
\usepackage{caption}
\usepackage{threeparttable}
\usepackage{lipsum}
%
\KOMAoptions{captions=topbeside}
\setcapindent*{0pt}%
\begin{document}

\chapter{Crapper}

\lipsum[1]

\begin{table}[h]%
  \label{tab:psource:final-params}%
  \begin{captionbeside}{This is the captions which should be top aligned}[l]%
      \raisebox{\dimexpr0.5\baselineskip-0.5\totalheight\relax}{%
      %\begin{threeparttable}
        \begin{tabular}{cccc}
          \hline
          Test & Test & Test & Test \\
          Test & Test & Test & Test\tnote{1} \\
          Test & Test & Test & Test \\
          Test & Test & Test & Test \\
          Test & Test & Test & Test\tnote{2} \\
          \hline
        \end{tabular}
      %  \begin{tablenotes}
      %    \item[1]{Test note}
      %    \item[2]{Test note}
      %    \end{tablenotes}
      %\end{threeparttable}%
  }%
  \end{captionbeside}
\end{table}

\end{document}

Answer 1

不需要\raisebox；t在 的可選參數中使用（頂部對齊） tabular，並且\firsthline（來自array包）而不是第一個\hline：

\documentclass{scrbook}
%
\usepackage[english]{babel}
\usepackage{caption}
\usepackage{threeparttable,array}
\usepackage{lipsum}
%
\KOMAoptions{captions=topbeside}
\setcapindent*{0pt}%

\begin{document}

\chapter{Test}

\lipsum[1]
\begin{table}%
  \label{tab:psource:final-params}%
  \begin{captionbeside}{This is the caption which is now top aligned}[l]%
      \begin{threeparttable}
        \begin{tabular}[t]{cccc}
          \firsthline
          Test & Test & Test & Test \\
          Test & Test & Test & Test\tnote{1} \\
          Test & Test & Test & Test \\
          Test & Test & Test & Test \\
          Test & Test & Test & Test\tnote{2} \\
          \hline
        \end{tabular}
        \begin{tablenotes}
          \item[1]{Test note}
          \item[2]{Test note}
          \end{tablenotes}
      \end{threeparttable}%
  \end{captionbeside}
\end{table}

\end{document}

如果您決定在表中使用該booktabs套件（我建議這樣做），則必須完成一些額外的工作：在下面的範例中，我定義了一個混合了和\firsttoprule的功能的命令：\firsthline\toprule

\documentclass{scrbook}
%
\usepackage[english]{babel}
\usepackage{caption}
\usepackage{threeparttable,array,booktabs}
\usepackage{lipsum}
%
\KOMAoptions{captions=topbeside}
\setcapindent*{0pt}%

\makeatletter
\newcommand\firsttoprule{%
  \multicolumn1c{%
    \global\backup@length\ht\@arstrutbox
    \global\advance\backup@length\dp\@arstrutbox
    \global\advance\backup@length\arrayrulewidth
     \raise\extratabsurround\copy\@arstrutbox
    }\\[-\backup@length]\toprule
}
\makeatother


\begin{document}

\chapter{Test}

\lipsum[1]
\begin{table}[h]%
  \label{tab:psource:final-params}%
  \begin{captionbeside}{This is the caption which is now top aligned}[l]%
      \begin{threeparttable}[t]
        \begin{tabular}[t]{cccc}
          \firsttoprule
          Test & Test & Test & Test \\
          Test & Test & Test & Test\tnote{1} \\
          Test & Test & Test & Test \\
          Test & Test & Test & Test \\
          Test & Test & Test & Test\tnote{2} \\
          \bottomrule
        \end{tabular}
        \begin{tablenotes}
          \item[1]{Test note}
          \item[2]{Test note}
          \end{tablenotes}
      \end{threeparttable}%
  \end{captionbeside}
\end{table}

\end{document}
