IEEE 乳膠模板。如何將帶有 tikzpicture 的圖形放入一列中？

我正在使用 IEEE Con​​ference Latex 模板。我想要一個人物tikzpicture。我的圖不是圖像，而是一個盒子（矩形），裡面有一些文字。這是我的程式碼：

\begin{figure}[t]
\begin{tikzpicture}
\node [draw,rectangle,align=left,right=2pt] (mid)
            {\textless bug\textgreater\\
            \textless \texttt{bug\_id}\textgreater 175229\textless \texttt{/bug\_id}\textgreater\\
           \textless \texttt{creation\_ts}\textgreater 2007-02-23 03:34:00 \textless\texttt{/creation\_ts}\textgreater\\
            \textless \texttt{short\_desc}\textgreater\\
                \hspace*{0.1in}
Should be able to open editor automatically when a task is activated\\
            \textless \texttt{/short\_desc}\textgreater\\
           \textless /bug\textgreater\\
          .......................................................................... };

\end{tikzpicture}
\captionsetup{justification=centering}
\caption{The overall structure of approach}
\end{figure}

問題是，最後，圖形穿過第一列，並且與第二列重疊。我如何才能將其調整為一列？

答案1

您可以透過新增例如某個因子來縮放節點

 scale=0.9

作為節點的參數，或者您可以手動斷開線。

樣本輸出

\documentclass[conference]{IEEEtran}

\usepackage{tikz,caption}

\usepackage{lipsum}

\begin{document}

\title{Sample document}

\author{\IEEEauthorblockN{A. Author}
\IEEEauthorblockA{Address\\City}}

\maketitle

\IEEEpeerreviewmaketitle

\section{Introduction}

\lipsum[1-2]

\begin{figure}[t]
\centering
\begin{tikzpicture}
\node [draw,rectangle,align=left,right=2pt,scale=0.8] (mid)
            {\textless bug\textgreater\\
            \textless \texttt{bug\_id}\textgreater 175229\textless \texttt{/bug\_id}\textgreater\\
           \textless \texttt{creation\_ts}\textgreater 2007-02-23 03:34:00 \textless\texttt{/creation\_ts}\textgreater\\
            \textless \texttt{short\_desc}\textgreater\\
                \hspace*{0.1in}
Should be able to open editor automatically when a task is activated\\
            \textless \texttt{/short\_desc}\textgreater\\
           \textless /bug\textgreater\\
          .......................................................................... };

\end{tikzpicture}
\captionsetup{justification=centering}
\caption{The overall structure of approach}
\end{figure}

\begin{figure}[t]
\centering
\begin{tikzpicture}
\node [draw,rectangle,align=left,right=2pt] (mid)
            {\textless bug\textgreater\\
            \textless \texttt{bug\_id}\textgreater 175229\textless \texttt{/bug\_id}\textgreater\\
           \textless \texttt{creation\_ts}\textgreater 2007-02-23 03:34:00 \\\textless\texttt{/creation\_ts}\textgreater\\
            \textless \texttt{short\_desc}\textgreater\\
                \hspace*{0.1in}
                Should be able to open editor automatically when a task\\
                \hspace*{0.1in}is activated\\
            \textless \texttt{/short\_desc}\textgreater\\
           \textless /bug\textgreater\\
          .......................................................................... };

\end{tikzpicture}
\captionsetup{justification=centering}
\caption{The overall structure of approach}
\end{figure}

\lipsum[2-4]
\end{document}

然而，顯示此類材料的更常用方法是使用例如listings包裹
