TikZ 節點中的自動換行？

tag-icon • tag-icon tikz-pgf
TikZ 節點中的自動換行？

我正在TikZ製作一個流程圖，逐步展示我的方案。我注意到節點中的自動換行不是自動的。也就是說，該行在整個頁面上可能非常長。

MWE如下。

\documentclass[a4paper]{article}

\usepackage[english]{babel}
\usepackage[utf8]{inputenc}
\usepackage{amsmath}
\usepackage{graphicx}
\usepackage[colorinlistoftodos]{todonotes}
\usepackage{tikz}

\title{Your Paper}

\begin{document}
\maketitle

\begin{tikzpicture}[block/.style={draw, fill=white, rectangle, minimum width=0.95*\columnwidth, anchor=west}, font=\small]
    \node[block, minimum width=0.95\columnwidth, minimum height=1cm, fill=white, opacity=1, text opacity=1, rounded corners, thick](step1) at (0,0){};
    \node[below=0cm of step1.north, align=left]{\textbf{Step 1}: This is Step one, which is a very very very long sentence. I really hate it when it does not automatically do the wrapping.};
    \node[block, minimum width=0.95\columnwidth, minimum height=1cm, below right=0.9cm and 0cm of step1.south, fill=white, opacity=1, text opacity=1, rounded corners, thick](step2) at (0,0){};
    \node[below=0cm of step2.north, align=left]{\textbf{Step 2}: Step 2 is cute and short.};
    \draw[-stealth](step1.south)--(step2.north)node[pos=0.5, above=0cm]{};
\end{tikzpicture}


\end{document}

呈現為 在此輸入影像描述

我目前的解決方法是手動插入新行，非常麻煩。

因此，我希望找到一種在節點中實現自動換行的優雅方法TikZ。

答案1

您沒有獲得預期的自動文字換行align=<option>，因為您正在設定minimum width密鑰。為text width（不是為）提供適當的值minimum width；然後align=<option>將提供所需的對齊方式：

\documentclass[a4paper]{article}
\usepackage[english]{babel}
\usepackage[utf8]{inputenc}
\usepackage{amsmath}
\usepackage{graphicx}
\usepackage[colorinlistoftodos]{todonotes}
\usepackage{tikz}

\title{Your Paper}

\begin{document}
\maketitle

\begin{tikzpicture}[
block/.style={
  draw,
  fill=white,
  text width=0.95*\columnwidth,
  anchor=west,
  minimum height=1cm,
  rounded corners
  },
font=\small
]
\node[block,align=left]
  (step1)
  {\textbf{Step 1}: This is Step one, which is a very very very long sentence. I really hate it when it does not automatically do the wrapping.};
\node[block,below=2cm of step1.north,align=center]
  (step2)
  {\textbf{Step 2}: Step 2 is cute and short.};
\draw[-stealth]
  (step1.south)--(step2.north)node[pos=0.5, above=0cm]{};
\end{tikzpicture}

\end{document}

在此輸入影像描述

我還對原始程式碼進行了一些簡化，取消了一些（顯然不必要的）節點。
