從巨集值設定 tikzpicture 中的樣本

Question

我正在嘗試在全域範圍內設定每個 tikzpicture 的樣本數量：

\documentclass{standalone}
\usepackage{pgfplots}
\pgfmathdeclarefunction{gauss}{2}{%
  \pgfmathparse{1/(#2*sqrt(2*pi))*exp(-((x-#1)^2)/(2*#2^2))}%
}
%\samplesize = <number>% How do I get this one to work?
\begin{document}
\section{Gaussian distribution}

\begin{tikzpicture}
\begin{axis}[
      hide y axis,
      axis lines*=center,
      axis on top,
      no markers,
      domain=2.5:25.5,
      samples=\samplesize,
      xlabel=\empty,
      ylabel=\empty,
      every axis x label/.style={at=(current axis.right of origin),anchor=west},
      every axis y label/.style={at=(current axis.above origin),anchor=south},
      height=5cm, width=12cm,
      xmin = 4, xmax=24,
      xtick={14}, ytick=\empty,
      enlargelimits=false,
      clip=false,
      grid=major
  ]
  \addplot [fill=cyan!20, draw=cyan!80, domain=4:7] {gauss(14,3.41696)} \closedcycle;
  \addplot [very thick,cyan!50!black] {gauss(14,3.416969)};
\end{axis}
\end{tikzpicture}
\end{document}

我無法讓它與 TeX 原始計數器、\value、\def、\let、\newcommand等一起使用。

Answer 1

您可以\newcommand為此使用，例如

\newcommand\samplesize{100}

另請注意，預設情況下，該類別standalone似乎不處理節標題（除其他外），但如果添加varwidth=true它就會起作用。 （儘管這\section可能只是完整文件中的遺物。）

完整程式碼：

\documentclass[varwidth=true]{standalone}
\usepackage{pgfplots}
\pgfmathdeclarefunction{gauss}{2}{%
  \pgfmathparse{1/(#2*sqrt(2*pi))*exp(-((x-#1)^2)/(2*#2^2))}%
}

\newcommand\samplesize{100}

\begin{document}
\section{Gaussian distribution}

\begin{tikzpicture}
\begin{axis}[
      hide y axis,
      axis lines*=center,
      axis on top,
      no markers,
      domain=2.5:25.5,
      samples=\samplesize,
      xlabel=\empty,
      ylabel=\empty,
      every axis x label/.style={at=(current axis.right of origin),anchor=west},
      every axis y label/.style={at=(current axis.above origin),anchor=south},
      height=5cm, width=12cm,
      xmin = 4, xmax=24,
      xtick={14}, ytick=\empty,
      enlargelimits=false,
      clip=false,
      grid=major
  ]
  \addplot [fill=cyan!20, draw=cyan!80, domain=4:7] {gauss(14,3.41696)} \closedcycle;
  \addplot [very thick,cyan!50!black] {gauss(14,3.416969)};
\end{axis}
\end{tikzpicture}
\end{document}
