我去年一直在 mac 上使用 matlab2tikz，它運行得非常好。現在我在Ubuntu上使用它並遇到了一些問題。僅供參考，已安裝的 texlive-full 確實包含 pgf 2.1，並且在我的序言中我添加了 \usepackage{tikz} 和 \usepackage{pgfplots}。當我在 KILE 中編譯我的乳膠文件（beamer 類別）時，我收到以下錯誤訊息：
`(./TIKZTest.tikz
! Missing \endcsname inserted.
<to be read again>
\def
l.25 };
! LaTeX Error: Something's wrong--perhaps a missing \item.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
l.25 };
! LaTeX Error: Something's wrong--perhaps a missing \item.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
l.25 };
! Missing control sequence inserted.
<inserted text>
\inaccessible
l.25 };
! LaTeX Error: Something's wrong--perhaps a missing \item.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
l.25 };
! LaTeX Error: Something's wrong--perhaps a missing \item.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
l.25 };
! Undefined control sequence.
<recently read> \pgfplotstable@loc@TMPa
l.25 };
! Package pgfplots Error: The requested list entry with index 0 of \pgfplots@ta
ble is too large; this list has not enough elements..
See the pgfplots package documentation for explanation.
Type H <return> for immediate help.
...
l.25 };
! Package pgfplots Error: Sorry, could not retrieve column '' from table '\\pgf
plots@table@@table@name '. Please check spelling (or introduce name aliases)..
See the pgfplots package documentation for explanation.
Type H <return> for immediate help.
...
l.25 };
! Package pgfplots Error: The requested list entry with index 1 of \pgfplots@ta
ble is too large; this list has not enough elements..
See the pgfplots package documentation for explanation.
Type H <return> for immediate help.
...
l.25 };
! Package pgfplots Error: Sorry, could not retrieve column '' from table '\\pgf
plots@table@@table@name '. Please check spelling (or introduce name aliases)..
See the pgfplots package documentation for explanation.
Type H <return> for immediate help.
...
l.25 };
! Package pgfplots Warning: the current plot has no coordinates (left?)
! Package pgfkeys Error: I do not know the key '/tikz/legend cell align' and I
am going to ignore it. Perhaps you misspelled it.
See the pgfkeys package documentation for explanation.
Type H <return> for immediate help.
...
l.28 \end{axis}
) <use Queenslscapelogocmyk-eps-converted-to.pdf>
<use Aqua-spot-rgb-clear10025.jpg> <use TUHHLogo-eps-converted-to.pdf> [10]
(./GroupSemPres.aux)
LaTeX Font Warning: Size substitutions with differences
(Font) up to 1.0pt have occurred.
LaTeX Font Warning: Some font shapes were not available, defaults substituted.
)`
它確實顯示了座標系和圖例，但不繪製任何數據。我剛剛發現，當我將資料作為座標而不是表格提供時，它確實會繪製一些內容。 Linux 上 tikz 中的表格可能有一般問題，或者我是否遺漏了某些內容。否則我必須將整個 tikz 檔案轉換為 matlab2tikz 給我的座標列表。
這是我從 matlab2tikz 獲得的 tikz 檔案（我刪除了一些資料以使其更短）：
% This file was created by matlab2tikz v0.4.7 running on MATLAB 8.1.
% Copyright (c) 2008--2014, Nico Schlömer <[email protected]>
% All rights reserved.
% Minimal pgfplots version: 1.3
%
% The latest updates can be retrieved from
% http://www.mathworks.com/matlabcentral/fileexchange/22022-matlab2tikz
% where you can also make suggestions and rate matlab2tikz.
%
\begin{tikzpicture}
\begin{axis}[%
width=5cm,
height=4cm,
scale only axis,
xmin=0,
xmax=0.018,
ymin=0.00015,
ymax=0.0005,
legend style={draw=black,fill=white,legend cell align=left}
]
\addplot [color=blue,solid]
table[row sep=crcr]{0 0.000311697265625003\\
0.001953125 0.000321697265625003\\
};
\addlegendentry{wp1Exp};
\end{axis}
\end{tikzpicture}%
