嘗試重現一個不尋常的桌子

Question

我是乳膠初學者。我（在某種程度上）知道如何製作傳統表格，但我不知道如何重現該表格。

如果有人能告訴我這種桌子是如何繪製的，我將非常感激。謝謝你！

\documentclass[11pt]{article}

\setlength{\parskip}{1em}
\setlength{\parindent}{1em}
\usepackage{amsmath}
\usepackage{amssymb}

\usepackage{graphicx}

\usepackage{caption}
\usepackage{comment}

\usepackage{ftnxtra}

\usepackage{array}

\usepackage{tabu}


\begin{document}

\renewcommand{\linespread}{1.1mm}

\begin{table}[t]{\textbf{Table 1}\\}

\begin{tabular}{ | l | l | l | p{2.25cm} |}

\hline
Country & Survey Year & 1 Percent Tax on Wealthiest 10 Percent of Households & Progressive Tax Rate Schedule: 1 Percent on Top 10 Percent and Additional 1 Percent on Top 5 Percent \\

\hline

\hline Canada & 1999 & 0.6 & 1.1 \\

\hline Germany & 2006 & 1.1 & 2.0 \\

\hline Italy & 2004 & 1.0 & 1.7 \\

\hline Japan & 2003 & 1.2 & 2.0 \\

\hline United Kingdom & 2000 & 0.8 & 1.3 \\

\hline United States & 2006 & 1.1 & 3.1 \\

\hline Unweighted Average & \textemdash & 1.1 & 1.9 \\

\hline

\end{tabular}

\end{document}

Answer 1

這裡有兩種方法——用包裝打破單元格中的行makecell；我們還可以提供通用的格式、對齊方式等。到命令\thead和引入的單元格\makecell。順便說一句，您不應該將\parskip和都設為\parindent非零值。另外，\linespread是一個因素，不是長度。

垂直線：

\documentclass[11pt]{article}
\usepackage{geometry}
\setlength{\parskip}{1em}
\setlength{\parindent}{1em}
\usepackage{amsmath}
\usepackage{amssymb}

\usepackage{graphicx}

\usepackage{caption}
\captionsetup{font ={bf, sf}}
\usepackage{comment}

\usepackage{ftnxtra}

\usepackage{array}
\usepackage{makecell}
\renewcommand\theadalign{bc}

\begin{document}

\begin{table}[t]
  \sffamily\renewcommand{\arraystretch}{1.25}
  \caption{A first table}
  \begin{tabular}{ | l | *{3}{c|} }
    \hline
    Country & Survey Year & \thead{1 Percent Tax on Wealthiest & \\ 10 Percent of Households} & \thead{Progressive Tax Rate Schedule:\\ 1 Percent on Top 10 Percent and\\ Additional 1 Percent on Top 5 Percent} \\
    \hline\noalign{\vskip0.667ex}
    \hline
    Canada & 1999 & 0.6 & 1.1 \\
    \hline
    Germany & 2006 & 1.1 & 2.0 \\
    \hline
    Italy & 2004 & 1.0 & 1.7 \\
    \hline
    Japan & 2003 & 1.2 & 2.0 \\
    \hline
    United Kingdom & 2000 & 0.8 & 1.3 \\
    \hline
    United States & 2006 & 1.1 & 3.1 \\
    \hline
    Unweighted Average & \textemdash & 1.1 & 1.9 \\
    \hline
  \end{tabular}
\end{table}

\end{document}

booktabs在許多人看來，沒有垂直線，使用: 看起來更專業：

\documentclass[11pt]{article}
\usepackage{geometry}
\setlength{\parskip}{1em}
\setlength{\parindent}{1em}
\usepackage{amsmath}
\usepackage{amssymb}

\usepackage{graphicx}

\usepackage{caption}
\captionsetup{font ={bf, sf}, singlelinecheck=off}
\usepackage{comment}

\usepackage{ftnxtra}

\usepackage{array, booktabs}
\usepackage{makecell}
\renewcommand\theadalign{bc}

\begin{document}

\begin{table}[t]
  \sffamily\renewcommand{\arraystretch}{1.25}
  \caption{A first table}
  \begin{tabular}{ @{\,}l *{3}{c}@{\,} }
    \toprule
    Country & Survey Year & \thead{1 Percent Tax on Wealthiest \\ 10 Percent of Households} & \thead{Progressive Tax Rate Schedule:\\ 1 Percent on Top 10 Percent and\\ Additional 1 Percent on Top 5 Percent} \\
    \midrule
    Canada & 1999 & 0.6 & 1.1 \\
    Germany & 2006 & 1.1 & 2.0 \\
    Italy & 2004 & 1.0 & 1.7 \\
    Japan & 2003 & 1.2 & 2.0 \\
    United Kingdom & 2000 & 0.8 & 1.3 \\
    United States & 2006 & 1.1 & 3.1 \\
    \addlinespace
    Unweighted Average & \textemdash & 1.1 & 1.9 \\
    \bottomrule
  \end{tabular}
\end{table}

\end{document}

Answer 2

此版本使用手動換行符。不知道為什麼你想使用所有這些套件而不使用 booktabs。

\documentclass[11pt]{article}
\setlength{\parskip}{1em}
\setlength{\parindent}{1em}
\usepackage{amsmath}
\usepackage{amssymb}
%\usepackage{graphicx}
\usepackage{caption}
%\usepackage{comment}
%\usepackage{ftnxtra}
%\usepackage{array}
%\usepackage{tabu}

\begin{document}
\renewcommand{\linespread}{1.1mm}
\begin{table}[t]
\caption{}
\tiny
\centering\begin{tabular}{|l|c|c|c|}
\hline
 &&& Progressive Tax Rate Schedule: \\
 && 1 Percent Tax on Wealthiest & 1 Percent on Top 10 Percent and \\
Country & Survey Year &  10 Percent of Households & Additional 1 Percent on Top 5 Percent \\
\hline
Canada & 1999 & 0.6 & 1.1 \\
Germany & 2006 & 1.1 & 2.0 \\
Italy & 2004 & 1.0 & 1.7 \\
Japan & 2003 & 1.2 & 2.0 \\
United Kingdom & 2000 & 0.8 & 1.3 \\
United States & 2006 & 1.1 & 3.1 \\
\hline
Unweighted Average & \textemdash & 1.1 & 1.9 \\
\hline
\end{tabular}
\end{table}
\end{document}
