圖片和表格清單

Question

我知道圖和表格的組合清單？，但是那裡的提問者要求一數字和表格的編號方案，我不要。不幸的是，答案似乎取決於這個先決條件。

我的問題是關於預期的結果/輸出，例如：

---

圖片和表格清單

圖1：新奧爾良的樹木地圖.................................... ........... 3

圖2：每天落葉數....................... 5

表1：樹木種類....................................... .... ............ 12

圖 3：每 1000 片落葉空氣品質下降 ....... 20

---

為了實現這一點，按照上面連結中的建議將數字重新定義為表格（或相反的方式）（即類似的東西\let\figure\table\let\endtable\endfigure）是行不通的，因為它當然會導致所有數字也被稱為「Table x」。 。

Answer 1

這有效。該程式碼已得到很好的註釋，因此我認為不需要更多註釋。

\documentclass{article}

% To make the page shorter
\pagestyle{empty}
\textheight3in

% CODE STARTS HERE
% Based on `tocloft` package
\usepackage[titles]{tocloft}
\newlistof{figtab}{loft}{List of Figures and Tables}
\makeatletter
% Change the file extension of both lot and lof
\def\ext@figure{loft}
\def\ext@table{loft}
% Store the original `\thefigure` and `\thetable`
\let\tohe@thefigure\thefigure
\let\tohe@thetable\thetable
% Redefine them to contain a "dummy" `\tohe@list...`
\def\thefigure{\tohe@listfig\tohe@thefigure}
\def\thetable{\tohe@listtab\tohe@thetable}
% Make the two dummy commands truly dummy
\let\tohe@listfig\relax
\let\tohe@listtab\relax
% Store the original `\listoffigtab`
\let\tohe@listoffigtab\listoffigtab
% Redefine it in such a way that the dummy commands insert "Fig." or "Tab." respectively
\def\listoffigtab{%
  \begingroup
  \def\tohe@listfig{Fig.~}
  \def\tohe@listtab{Tab.~}
  \tohe@listoffigtab
  \endgroup
}
% Change \listoffigtab spacing
\setlength{\cftfignumwidth}{5em}
\setlength{\cfttabnumwidth}{5em}
\setlength{\cftfigindent}{0pt}
\setlength{\cfttabindent}{0pt}
\makeatother
% CODE ENDS HERE

\begin{document}

\listoffigtab

% !b just to make the floats appear on the bottom of the first page
\begin{figure}[!b]
\caption{First}
\end{figure}

\begin{table}[!b]
\caption{Little Table}
\end{table}

\begin{figure}[!b]
\caption{Second}
\end{figure}

\end{document}

Answer 2

相關指令是 as 'always' \addcontentsline。

figure並且標題被寫入副檔名為或 的table檔案中。\ext@figure\ext@table

在\@caption（實際上是內部處理器巨集）中我們發現：

\long\def\@caption#1[#2]#3{%
  \par
  \addcontentsline{\csname ext@#1\endcsname}{#1}%
    {\protect\numberline{\csname the#1\endcsname}{\ignorespaces #2}}%
  \begingroup
    \@parboxrestore
    \if@minipage
      \@setminipage
    \fi
    \normalsize
    \@makecaption{\csname fnum@#1\endcsname}{\ignorespaces #3}\par
  \endgroup}

第一個參數\@caption是浮點數的名稱，即figureor table（通常）。可以使用和修補它，將table字幕及其redirect擴展名保存到檔案中\ext@figure。

\documentclass{book}

\usepackage{caption}
\usepackage{xstring}
\usepackage{xpatch}

\makeatletter
\xpatchcmd{\@caption}{%
  \addcontentsline{\csname ext@#1\endcsname}{#1}%
  {\protect\numberline{\csname the#1\endcsname}{\ignorespaces #2}}%
}{%
  \IfStrEq{#1}{table}{% Filter `table` out
    \addcontentsline{\csname ext@figure\endcsname}{table}%
    {\protect\numberline{\csname the#1\endcsname}{\ignorespaces #2}}%
  }{%
    \addcontentsline{\csname ext@#1\endcsname}{#1}%
    {\protect\numberline{\csname the#1\endcsname}{\ignorespaces #2}}%
  }%
}{\typeout{Patch success}}{}
\makeatother

\renewcommand{\listfigurename}{List of Figures and Tables}

\begin{document}
\listoffigures
\begin{figure}
\caption{first figure}
\end{figure}

\begin{figure}
\caption{Another first figure}
\end{figure}


\begin{table}
\caption{first table}
\end{table}

\chapter{Another chapter}
\begin{table}
\caption{Yet another table}
\end{table}

\end{document}

yo'正確注意到不清楚它是 LOFT 中的表格還是圖形後面的一個小更新：

\documentclass{book}

\usepackage{caption}
\usepackage{xstring}
\usepackage{tocloft}
\usepackage{xpatch}

\addtolength{\cftfignumwidth}{30pt}
\addtolength{\cfttabnumwidth}{30pt}
% Prepend the tab or fig number with a `\makebox` (for equal width) and put `Tab.` or `Fig.` in there. Change the names at will
\renewcommand{\cfttabpresnum}{\makebox[30pt][l]{Tab.}}
\renewcommand{\cftfigpresnum}{\makebox[30pt][l]{Fig.}}


\makeatletter
\xpatchcmd{\@caption}{%
  \addcontentsline{\csname ext@#1\endcsname}{#1}%
  {\protect\numberline{\csname the#1\endcsname}{\ignorespaces #2}}%
}{%
  \IfStrEq{#1}{table}{%
    \addcontentsline{\csname ext@figure\endcsname}{table}%
    {\protect\numberline{\csname the#1\endcsname\hfill\hspace{1em}}{\ignorespaces #2}}%
  }{%
    \IfStrEq{#1}{figure}{%
      \addcontentsline{\csname ext@#1\endcsname}{#1}%
      {\protect\numberline{\csname the#1\endcsname\hfill\hspace{1em}}{\ignorespaces #2}}%
    }{%
     \addcontentsline{\csname ext@#1\endcsname}{#1}%
     {\protect\numberline{\csname the#1\endcsname}{ \ignorespaces #2}}%
    }
  }%
}{\typeout{Patch success}}{}
\makeatother

\renewcommand{\listfigurename}{List of Figures and Tables}

\begin{document}
\listoffigures
\begin{figure}
\caption{first figure}
\end{figure}

\begin{figure}
\caption{Another first figure}
\end{figure}


\begin{table}
\caption{first table}
\end{table}

\chapter{Another chapter}
\begin{table}
\caption{Yet another table}
\end{table}

\section{First section}
\subsection{First subsection}
\subsubsection{First subsubsection}
\begin{table}
\caption{Yet another another table}
\end{table}


\end{document}
