使用 Beamer 進行複雜的 tikz 動畫

Question

我沒有看到任何可能顯著減慢程式碼速度的重大問題。由於重新編譯大量複雜的 TikZ 圖片可能非常麻煩，因此有一個庫external強制 TikZ 保存並在可能的情況下重複使用圖片。這是按如下方式完成的。

\usetikzlibrary{external}
\tikzexternalize

編輯：正如 @brad 在評論中建議的那樣，使用\tikzexternalize[prefix=tikz/], 為臨時 TikZ 圖片設置一個資料夾可能會很有利。

由於您使用的是投影機構\only造，因此這不會按預期工作，僅渲染第一幀。然而，有一個“黑客”：

用where來包裹整個tikzpicture環境\only<m-M>m最小的並且M是最大\only命令引用的幀號之內tikz 圖片。

由於該[visible on=<m-M>]選項與命令“等效” \only，因此您可以像這樣使用它。

\only<1-10>{%
\begin{tikzpicture}
    \node[visible on=<1>] {};
    % ...
    \node[visible on=<10>] {};
\end{tikzpicture}
}

我已經為您的程式碼嘗試過此操作，第二次（及以後）編譯時間是很多降低。

看僅將 tikz 外部功能與投影機一起使用了解更多。

完整程式碼：

\documentclass{beamer}
\usetheme{Berkeley}
\usepackage{graphicx}
\usepackage{ifthen}
\usepackage{tikz}
\tikzset{
  invisible/.style={opacity=0},
  visible on/.style={alt={#1{}{invisible}}},
  alt/.code args={<#1>#2#3}{\alt<#1>{\pgfkeysalso{#2}}{\pgfkeysalso{#3}}
  },
}

\usetikzlibrary{external}
\tikzexternalize

\begin{document}
\begin{frame}
\centering
\only<1-10>{%
\begin{tikzpicture}[scale=0.3, every node/.style={scale=0.3}]
 \pgfmathsetmacro{\alphsize}{26}
 \pgfmathsetmacro{\ang}{360/\alphsize}
 \pgfmathsetmacro{\d}{3}
 \pgfmathsetmacro{\op}{98 + \ang/2 - 1.2}
 \pgfmathsetmacro{\e}{\ang + \ang*\d}
 \pgfmathsetmacro{\ep}{\op + \ang*\d}
 \foreach \x in {0,\ang,...,360} {\draw[gray] (\x:8em) -- (\x:12em);}
 \foreach \x [count=\xi] in {A,...,Z} {
  \node[rotate=\ang - \ang*\xi,visible on=<1>]  at (\op - \ang*\xi:11em)     {{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<2>]  at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{T}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<3>]  at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{E}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<4>]  at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{L}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<5>]  at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{E}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<6>]  at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{P}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<7>]  at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{H}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<8>]  at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{O}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<9>]  at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{N}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\ang - \ang*\xi,visible on=<10>] at (\op - \ang*\xi:11em) {\ifthenelse{\equal{\x}{E}}{\color{green}\Large \x}{\Large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<1>]  at (\ep - \ang*\xi:9em) {{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<2>]  at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{W}}{\color{red}\large \x}{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<3>]  at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{H}}{\color{red}\large \x}{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<4>]  at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{O}}{\color{red}\large \x}{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<5>]  at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{H}}{\color{red}\large \x}{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<6>]  at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{S}}{\color{red}\large \x}{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<7>]  at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{K}}{\color{red}\large \x}{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<8>]  at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{R}}{\color{red}\large \x}{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<9>]  at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{Q}}{\color{red}\large \x}{\large \x}};
  \node[rotate=\e - \ang*\xi,visible on=<10>] at (\ep - \ang*\xi:9em) {\ifthenelse{\equal{\x}{H}}{\color{red}\large \x}{\large \x}};
}
 \draw[thick] (0cm,0cm) circle(12em);
 \draw[gray] (0cm,0cm) circle(10em);
 \draw[thick] (0cm,0cm) circle(8em);
\end{tikzpicture}
}
\bigskip

\centering
\only<1-10>{%
\begin{tikzpicture}[every node/.style={scale=0.6}]
  \draw[step=1em,gray,thin] (0em,0em) grid (9em,2em);
  \node at (0.5em,1.5em) {\textcolor<2> {green}T};
  \node at (1.5em,1.5em) {\textcolor<3> {green}E};
  \node at (2.5em,1.5em) {\textcolor<4> {green}L};
  \node at (3.5em,1.5em) {\textcolor<5> {green}E};
  \node at (4.5em,1.5em) {\textcolor<6> {green}P};
  \node at (5.5em,1.5em) {\textcolor<7> {green}H};
  \node at (6.5em,1.5em) {\textcolor<8> {green}O};
  \node at (7.5em,1.5em) {\textcolor<9> {green}N};
  \node at (8.5em,1.5em) {\textcolor<10>{green}E};
  \node[visible on=<2->]  at (0.5em,0.5em) {\textcolor<2> {red}W};
  \node[visible on=<3->]  at (1.5em,0.5em) {\textcolor<3> {red}H};
  \node[visible on=<4->]  at (2.5em,0.5em) {\textcolor<4> {red}O};
  \node[visible on=<5->]  at (3.5em,0.5em) {\textcolor<5> {red}H};
  \node[visible on=<6->]  at (4.5em,0.5em) {\textcolor<6> {red}S};
  \node[visible on=<7->]  at (5.5em,0.5em) {\textcolor<7> {red}K};
  \node[visible on=<8->]  at (6.5em,0.5em) {\textcolor<8> {red}R};
  \node[visible on=<9->]  at (7.5em,0.5em) {\textcolor<9> {red}Q};
  \node[visible on=<10->] at (8.5em,0.5em) {\textcolor<10>{red}H};
\end{tikzpicture}
}
\end{frame}
\end{document}
