我正在嘗試複製這張圖片：
這就是我到目前為止所擁有的（間距不同，但沒關係）：
我需要做的就是在圖形中間、深度 2、所有節點後面添加水平線。這是我的程式碼：
\begin{tikzpicture}
\begin{scope}[auto, every node/.style={draw,circle,minimum size=2em,inner sep=1, font=\footnotesize}]
\node (1) [circle, draw, fill=lightgray] at (0,0) {};
\node (2) [circle, draw, fill=lightgray, below left=of 1, shift={(-1,0)}] {};
\draw[->](1)--(2);
\node (4) [circle, draw, fill=lightgray, below left=of 2, shift={(0,0)}] {};
\draw[->](2)--(4);
\node (3) [circle, draw, fill=lightgray, below left=of 4, shift={(-.5,-1)}] {0};
\draw[dashed, ->](4)--(3);
\node (6) [circle, draw, fill=lightgray, right=of 3, shift={(-1,0)}] {100};
\draw[dashed, ->](4)--(6);
\node (7) [circle, draw, fill=lightgray, right=of 6, shift={(-1,0)}] {100};
\draw[dashed, ->](4)--(7);
\node (8) [circle, draw, fill=lightgray, right=of 7, shift={(-1,0)}] {0};
\draw[dashed, ->](4)--(8);
\node (5) [circle, draw, fill=lightgray, below right=of 2, shift={(0,0)}] {};
\draw[->](2)--(5);
\node (9) [circle, draw, fill=lightgray, below left=of 5, shift={(-.5,-1)}] {100};
\draw[dashed, ->](5)--(9);
\node (10) [circle, draw, fill=lightgray, right=of 9, shift={(-1,0)}] {0};
\draw[dashed, ->](5)--(10);
\node (11) [circle, draw, fill=lightgray, right=of 10, shift={(-1,0)}] {0};
\draw[dashed, ->](5)--(11);
\node (12) [circle, draw, fill=lightgray, right=of 11, shift={(-1,0)}] {0};
\draw[dashed, ->](5)--(12);
\node (13) [circle, draw, fill=lightgray, below right=of 1, shift={(1,0)}] {};
\draw[->](1)--(13);
\node (14) [circle, draw, fill=lightgray, below left=of 13, shift={(0,0)}] {};
\draw[->](13)--(14);
\node (16) [circle, draw, fill=lightgray, below right=of 14, shift={(.5,-1)}] {0};
\draw[dashed, ->](14)--(16);
\node (17) [circle, draw, fill=lightgray, left=of 16, shift={(1,0)}] {0};
\draw[dashed, ->](14)--(17);
\node (18) [circle, draw, fill=lightgray, left=of 17, shift={(1,0)}] {0};
\draw[dashed, ->](14)--(18);
\node (19) [circle, draw, fill=lightgray, left=of 18, shift={(1,0)}] {0};
\draw[dashed, ->](14)--(19);
\node (15) [circle, draw, fill=lightgray, below right=of 13, shift={(0,0)}] {};
\draw[->](13)--(15);
\node (20) [circle, draw, fill=lightgray, below right=of 15, shift={(.5,-1)}] {100};
\draw[dashed, ->](15)--(20);
\node (21) [circle, draw, fill=lightgray, left=of 20, shift={(1,0)}] {0};
\draw[dashed, ->](15)--(21);
\node (22) [circle, draw, fill=lightgray, left=of 21, shift={(1,0)}] {100};
\draw[dashed, ->](15)--(22);
\node (23) [circle, draw, fill=lightgray, left=of 22, shift={(1,0)}] {100};
\draw[dashed, ->](15)--(23);
\end{scope}
\end{tikzpicture}
我怎麼能添加該行？
答案1
在序言中
\usetikzlibrary{backgrounds}
圖片的最後
\scoped[on background layer]{\draw (current bounding box.west) -- (current bounding box.east);}
例如。
例如，對於一棵樹，我會這樣做：
\documentclass[tikz,border=10pt,multi]{standalone}
\usepackage{forest}
\usetikzlibrary{backgrounds}
\begin{document}
\begin{forest}
for tree={
circle,
minimum size=25pt,
draw,
fill=lightgray,
font=\small\sffamily,
l sep+=10pt,
edge={->}
},
where n children=0{
tier=terminus,
+edge=densely dashed,
}{
if level=2{
tikz+={
\scoped[on background layer]{\path [line width=1pt, draw=lightgray, line cap=round] (current bounding box.west |- .center) -- (current bounding box.east |- .center);}
}
}{}
}
[
[
[
[0]
[100]
[100]
[0]
]
[
[100]
[0]
[0]
[0]
]
]
[
[
[0]
[0]
[0]
[0]
]
[
[100]
[100]
[0]
[100]
]
]
]
\end{forest}
\end{document}
您不一定希望使用forest，但使用一些樹形繪製工具將大大簡化任務。即使您只使用 TikZ 的內建樹內容或trees庫，雖然您的樹規範在 Forest 語法中比我的規範要簡潔得多，但它仍然比手動放置所有內容更簡潔且更易於維護。
