！包 tikz 錯誤：放棄此路徑。你忘了分號嗎？

Question

我似乎遺漏了一些關於 tikz 工作原理的相當基本的東西......我真的不知道我丟失的分號在哪裡！

微量元素：

\documentclass{article}
\usepackage{tikz}
\begin{document}
\begin{tikzpicture}[sibling distance=10em,
  every node/.style = {draw=none, fill=none}]]
  \node {What are the types of \code{a} and \code{b}?}
  child { \node {\code{int} and \code{int}}
    child { \node{Execute procedure \code{int\_add}. }; }; }
  child { \node {\code{float} and \code{float}}
    child { \node{Execute procedure \code{float\_add}.}; }; }
  child { \node {\code{float} and \code{int}}
    child { \node{Execute procedure \code{float\_plus\_int}.}; }; }
  child { \node {\code{int} and \code{float}}
    child { \node{Execute procedure \code{int\_plus\_float}.}; }; }
  child { \node {\code{string} and \code{string}}
    child { \node{Execute procedure \code{string\_concatenate}.}; }; }
  child { \node {Any other combination}
    child { \node{Raise \code{TypeError}.}; }; };
\end{tikzpicture}
\end{document}

Answer 1

• ]選項後面有一個虛假內容tikzpicture（這不會造成太大傷害，但不應該在那裡）。

• 左大括號比右大括號多。

• \node樹中的 s 應該只是s node（不含反斜線），不需要以分號結尾。

。

\documentclass{standalone}
\usepackage{tikz}
\newcommand\code[1]{\texttt{#1}}
\begin{document}
\begin{tikzpicture}[sibling distance=10em,
  every node/.style = {draw=none, fill=none}]]
  \node {What are the types of \code{a} and \code{b}?}
  child { node {\code{int} and \code{int}}
          child { node{Execute procedure \code{int\_add}. }
                }
          }
  child { node {\code{float} and \code{float}}
          child { node{Execute procedure \code{float\_add}.}
                }
        }
  child { node {\code{float} and \code{int}}
          child { node{Execute procedure \code{float\_plus\_int}.}
                }
        }
  child { node {\code{int} and \code{float}}
          child { node{Execute procedure \code{int\_plus\_float}.}
                }
        }
  child { node {\code{string} and \code{string}}
          child { node{Execute procedure \code{string\_concatenate}.}
                }
        }
  child { node {Any other combination}
          child { node{Raise \code{TypeError}.}
                }
        };
\end{tikzpicture}
\end{document}
