帶有文字和數字的表格

tag-icon • tag-icon tables
帶有文字和數字的表格

我正在製作一個帶有文字的表格，但無法以正確的形式生成它。

下面給出了一個最小的工作範例。

      \documentclass[12pt, a4paper, twoside]{article}
      \usepackage{titlesec}
      \usepackage[T1]{fontenc}
      \usepackage{times}
      \usepackage[latin9]{inputenc}
      \usepackage[english]{babel}
      \usepackage{float}
      \usepackage{url}
      \usepackage{setspace}
      \onehalfspacing
      \usepackage{titlesec}
      \usepackage{caption}% <-- added
      \usepackage{tabulary}
      \usepackage[para]{threeparttable}
      \usepackage{array,booktabs,longtable,tabularx}
      \newcolumntype{L}{>{\raggedright\arraybackslash}X}% <-- added
      \usepackage{caption}% <-- added
      \setlength{\LTcapwidth}{7in}
      \usepackage{ltablex}% <-- added
      \usepackage{siunitx}% <-- added
      \usepackage[flushleft]{threeparttablex}
      \usepackage{pdflscape}
      \usepackage{amssymb}
      \usepackage{multirow}
      \begin{document}
      Some text in the main section
      \begin{table}[htbp]
        \centering
        \caption{Asset Details}
          \begin{tabulary}{\columnwidth}{p{6cm}p{2cm}
          \toprule
          \textbf{Item} & \textbf{Factor} \\
          \midrule
          \multicolumn{2}{c}{\textbf{Details }} \\
          \midrule
          \textbf{A. Level 1 } &  \\
          \midrule
          All the assets held by the bank  & \multirow{4}[2]{*}{100\%} \\
          Some of important assets held by the bank.  &  \\
          Some other text will be added here. This text can be long as well.  &  \\
          More Text &  \\
          \midrule
          \multicolumn{1}{l}{\textbf{Level 2}} &  \\
          \midrule
          \textbf{Level 2A assets} &  \\
          \midrule
          Some 2A Assets  & \multirow{3}[2]{*}{85\%} \\
          Bank Debt &  \\
          \textit{\textbf{Some more text }} &  \\
          \midrule
          \textbf{Level 2B assets (maximum of 15\% of HQLA)} &  \\
          \midrule
          \textit{\textbf{Assets of High Quality}} & 75\% \\
          Assets of Lower Quality  & 50\% \\
          Assets of Lower Quality  & 50\% \\
          \bottomrule
          \end{tabulary}%
        \label{tab:asset}%
      \end{table}%
     \end{document}

實際的表格應該是這樣的。所需表任何幫助將不勝感激。

答案1

也許這看起來像你想要的？

\documentclass[12pt, a4paper, twoside]{article}
\usepackage{titlesec}
\usepackage[T1]{fontenc}
\usepackage{times}
\usepackage[latin9]{inputenc}
\usepackage[english]{babel}
\usepackage{float}
\usepackage{url}
\usepackage{setspace}
\onehalfspacing
\usepackage{titlesec}
\usepackage{caption}% <-- added
\usepackage{tabulary}
\usepackage[para]{threeparttable}
\usepackage{array,booktabs,longtable,tabularx}
\newcolumntype{L}{>{\raggedright\arraybackslash}X}% <-- added
\usepackage{caption}% <-- added
\setlength{\LTcapwidth}{7in}
\usepackage{ltablex}% <-- added
\usepackage{siunitx}% <-- added
\usepackage[flushleft]{threeparttablex}
\usepackage{pdflscape}
\usepackage{amssymb}
\usepackage{multirow}
\setlength\defaultaddspace{2ex}
\begin{document}
Some text in the main section
\begin{table}[htbp]
  \centering
  \caption{Asset Details}
  \begin{tabulary}{\linewidth}{Jc}
    \toprule
    \textbf{Item} & \textbf{Factor} \\
    \multicolumn{2}{c}{\textbf{Details }} \\
    \midrule
    \textbf{A. Level 1 } & \\
    \midrule
    All the assets held by the bank & \multirow{4}[2]{*}{100\,\%} \\
    \addlinespace
    Some of important assets held by the bank. \\
    \addlinespace
    Some other text will be added here. This text can be long as well. \\
    \addlinespace
    More Text \\
    \midrule
    \multicolumn{1}{l}{\textbf{Level 2}} \\
    \addlinespace[0.5ex]
    \textbf{Level 2A assets} & \\
    \midrule
    Some 2A Assets & \multirow{3}[2]{*}{85\,\%} \\
    \addlinespace
    Bank Debt \\
    \addlinespace
    \textit{\textbf{Some more text }} \\
    \midrule
    \textbf{Level 2B assets (maximum of 15\,\% of HQLA)} & \\
    \midrule
    \textit{\textbf{Assets of High Quality}} & 75\,\% \\
    \addlinespace
    Assets of Lower Quality & 50\,\% \\
    \addlinespace
    Assets of Lower Quality & 50\,\% \\
    \bottomrule
  \end{tabulary}%
  \label{tab:asset}%
\end{table}%

\end{document}

在此輸入影像描述

評論旁白：包times已完全棄用。使用 newtxtextandnewtxmath代替。

答案2

您的程式碼中（至少）有三個錯誤：

  • 您需要multirow透過 載入序言中的套件\usepackage{multirow}。

  • 程式碼片段

    \begin{tabulary}{\columnwith}{p{6cm}p{2cm}

    應該

    \begin{tabulary}{\columnwidth}{p{6cm}p{2cm}}

    請注意“columnwidth”的拼寫以及添加的右大括號。

  • 代替

    \end document

    你必須寫

    \end{document}

如果應用這些修復，程式碼將編譯。當然，我不知道表中的內容是否正確。
