如何在圓形圖中加入圓形箭頭？

Question

我需要關閉以下圓形圖（在“ee”後面添加一個指向“aa”的額外箭頭）。您能幫我一下嗎，程式碼如下：

\usesmartdiagramlibrary{additions} % required in the preamble
\usetikzlibrary{arrows} % required in the preamble
\bigskip
\begin{minipage}[c][8cm]{\textwidth}
\centering
\smartdiagramset{
uniform color list=orange!60!yellow for 5 items,
circular final arrow disabled=true,
circular distance=2.25cm,
arrow tip=to,
arrow line width=2pt,
additions={
additional item bottom color=orange!60!yellow,
additional item border color=gray,
additional item shadow=drop shadow,
additional item offset=0.65cm,
additional arrow line width=2pt,
additional arrow tip=to,
additional arrow color=orange!60!yellow,
}
}
\smartdiagramadd[circular diagram]{
aa,bb,cc,dd,ee
}{
above of module1/Start,right of module5/End
}
\smartdiagramconnect{to-}{module1/additional-module1}
\smartdiagramconnect{-to}{module5/additional-module2}
\end{minipage}

Answer 1

預設情況下circular diagram 是已關閉，但您已透過新增停用了最後一個箭頭

circular final arrow disabled=true

到\smartdiagramset.只需刪除該行即可。

我修改了一點的完整程式碼minipage如下。對於此螢幕截圖，我\fbox在 周圍添加了minipage，以表明 的大小minipage適合該圖：

\documentclass{article}
\usepackage{smartdiagram}
\usesmartdiagramlibrary{additions} % required in the preamble
\begin{document}
\begin{minipage}[b][7cm]{\textwidth}
\centering
\smartdiagramset{
uniform color list=orange!60!yellow for 5 items,
%circular final arrow disabled=true,
circular distance=2.25cm,
arrow tip=to,
arrow line width=2pt,
additions={
additional item bottom color=orange!60!yellow,
additional item border color=gray,
additional item shadow=drop shadow,
additional item offset=0.65cm,
additional arrow line width=2pt,
additional arrow tip=to,
additional arrow color=orange!60!yellow,
}
}%
\smartdiagramadd[circular diagram]{
aa,bb,cc,dd,ee
}{
above of module1/Start,right of module5/End
}%
\smartdiagramconnect{to-}{module1/additional-module1}%
\smartdiagramconnect{-to}{module5/additional-module2}%
\end{minipage}
\end{document}
