Tcolorbox、練習和 Manyfoot 包 - 2

tag-icon • tag-icon tcolorbox manyfoot
Tcolorbox、練習和 Manyfoot 包 - 2

我使用該tcolorbox包來製作帶有解決方案的練習。可以看到，通常的腳註都寫在方框內，但是當我有時有多個腳註時，我使用包manyfoot以“內聯”方式編寫這些腳註，但得到了不需要的結果。僅產生腳註標記，而不產生腳註本身。我的目的的第一個問題在這裡給出：

Tcolorbox、練習和 Manyfoot 包

我現在的問題如下：在練習框中，我使用基於在練習框之後給出的內聯項後綴在\footnotetextC哪裡），它會在解決方案的框外生成腳註，就像練習框一樣。C\footnotetextC

這是使用的 .tex 檔：

\documentclass{book}

\usepackage[most]{tcolorbox}
\tcbuselibrary{skins,breakable,xparse}

\usepackage{polyglossia}
\setmainlanguage{english}

\usepackage[para*]{manyfoot}
\DeclareNewFootnote[para]{C}
\makeatletter
\let\c@footnoteC\c@footnote
\makeatother

\renewcommand{\thefootnoteC}{\fnsymbol{footnote}}

\NewTColorBox[auto counter,number within=chapter]{exercise}{+O{}}{%
enhanced,colframe=green!20!black,colback=yellow!10!white,coltitle=green!40!black,
fonttitle=\bfseries,
underlay={\begin{tcbclipinterior}
\shade[inner color=green!80!yellow,outer color=yellow!10!white]
(interior.north west) circle (2cm);
\draw[help lines,step=5mm,yellow!80!black,shift={(interior.north west)}]
(interior.south west) grid (interior.north east);
\end{tcbclipinterior}},
title={Exercise~ \thetcbcounter:},
label={exercise@\thetcbcounter},
attach title to upper=\quad,
after upper={\par\hfill\textcolor{green!40!black}%
{\itshape Solution on page~\pageref{solution@\thetcbcounter}}},
lowerbox=ignored,
savelowerto=solutions/exercise-\thetcbcounter.tex,
record={\string\solution{\thetcbcounter}{solutions/exercise-\thetcbcounter.tex}},
#1
}
\NewTotalTColorBox{\solution}{mm}{%
enhanced,colframe=red!20!black,colback=yellow!10!white,coltitle=red!40!black,
fonttitle=\bfseries,
underlay={\begin{tcbclipinterior}
\shade[inner color=red!50!yellow,outer color=yellow!10!white]
(interior.north west) circle (2cm);
\draw[help lines,step=5mm,yellow!80!black,shift={(interior.north west)}]
(interior.south west) grid (interior.north east);
\end{tcbclipinterior}},
title={Solution of Exercise~\ref{exercise@#1} on page~\pageref{exercise@#1}:},
phantomlabel={solution@#1},
attach title to upper=\par,
}{\input{#2}}

\tcbset{no solution/.style={no recording,after upper=}}

\begin{document}
\chapter{The first chapter}

\section{Exercises}
\tcbstartrecording
\begin{exercise}
Exercise with inlined footnotes, \footnoteC{inlined footnote 1} and \footnoteC{inlined footnote 2}, in the question.
\tcblower
Exercise with inlined footnotes, \footnoteC{inlined footnote 1} and \footnoteC{inlined footnote 2}, in the answer.
\end{exercise}
\footnotetextC[1]{inlined footnote 1}
\footnotetextC[2]{inlined footnote 2}
\begin{exercise}
Exercise with usual footnotes, \footnote{footnote 1} and \footnote{footnote 2}, in the question.
\tcblower
Exercise with usual footnotes, \footnote{footnote 1} and \footnote{footnote 2}, in the answer.
\end{exercise}
\tcbstoprecording
\section{Solutions of exercises}
\tcbinputrecords

\end{document}

它是使用 xelatex 進行編譯的： 在此輸入影像描述

答案1

如果我正確理解你的問題，你希望你的腳註設定為 ' para' 樣式manyfoot，但在tcolorbox.該軟體包paranotes可以為您做到這一點。

如果不是複雜的「練習解決方案」tcolorbox，那麼自動化「parnotes」會更容易，它依賴隱式或明確\parnotes命令來列印筆記。但用部分自動化做也不算太麻煩。

\documentclass{book}

\usepackage[most]{tcolorbox}
\tcbuselibrary{skins,breakable,xparse}

\usepackage{polyglossia}
\setmainlanguage{english}

\usepackage{parnotes}

\NewTColorBox[auto counter,number within=chapter]{exercise}{+O{}}{%
  enhanced,
  colframe=green!20!black,
  colback=yellow!10!white,
  coltitle=green!40!black,
  fonttitle=\bfseries,
  underlay={\begin{tcbclipinterior}
      \shade[inner color=green!80!yellow,outer color=yellow!10!white]
      (interior.north west) circle (2cm);
      \draw[help lines,step=5mm,yellow!80!black,shift={(interior.north west)}]
      (interior.south west) grid (interior.north east);
    \end{tcbclipinterior}
  },
  title={Exercise~ \thetcbcounter:},
  label={exercise@\thetcbcounter},
  attach title to upper=\quad,
  after upper={\par\hfill\textcolor{green!40!black}%
    {\itshape Solution on page~\pageref{solution@\thetcbcounter}}%
    \par\parnotes
  },
  lowerbox=ignored,
  savelowerto=exercise-\thetcbcounter.tex,
  record={\string\solution{\thetcbcounter}{exercise-\thetcbcounter.tex}},
  #1,
  code={\parnotereset}, % <-- parnotes
}

\NewTotalTColorBox{\solution}{mm}{%
  enhanced,
  colframe=red!20!black,
  colback=yellow!10!white,
  coltitle=red!40!black,
  fonttitle=\bfseries,
  underlay={\begin{tcbclipinterior}
      \shade[inner color=red!50!yellow,outer color=yellow!10!white]
      (interior.north west) circle (2cm);
      \draw[help lines,step=5mm,yellow!80!black,shift={(interior.north west)}]
      (interior.south west) grid (interior.north east);
    \end{tcbclipinterior}},
  title={Solution of Exercise~\ref{exercise@#1} on page~\pageref{exercise@#1}:
  },
  phantomlabel={solution@#1},
  attach title to upper=\par,
}{\input{#2}}

\tcbset{no solution/.style={no recording,after upper=}}

\begin{document}

\chapter{The first chapter}

\section{Exercises}

\tcbstartrecording
\begin{exercise}
  1.  Exercise with inlined footnotes, \parnote{inlined footnote 1}
  and \parnote{inlined footnote 2}, in the question.

  % \parnotes % <-- this won't work because of your "Solution on page ..."

  \tcblower

  2.  Exercise with inlined footnotes, \parnote{inlined footnote 1}
  and \parnote{inlined footnote 2}, in the answer.

  \parnotes

\end{exercise}

% \footnotetextC[1]{inlined footnote 1}
% \footnotetextC[2]{inlined footnote 2}

\begin{exercise}
  Exercise with usual footnotes, \footnote{footnote 1} and
  \footnote{footnote 2}, in the question.

  \tcblower

  Exercise with usual footnotes, \footnote{footnote 1} and
  \footnote{footnote 2}, in the answer.
\end{exercise}
\tcbstoprecording

\section{Solutions of exercises}
\tcbinputrecords

\end{document}

注意：我刪除了您的程式碼以將框寫入另一個目錄（該目錄不應包含在 MWE 中，除非這是問題的焦點）。

tcolorbox-parnote

答案2

根據我接受的@jon給出的答案，我給出了我的問題的答案，這實際上是一個開發問題的答案......我把這個問題放在阿拉伯語環境中，從右到在左的環境中，並且拉丁語句子在命令 \LR{} 內給出，該命令從左到右書寫。我給了使用Manyfoot 套件的範例，其中我們看到腳註沒有寫入，以及使用parnotes 的範例，我們看到命令\LR{\parnotes} 以從左到右的模式寫入腳註，如果我想要的話，在盒子裡面。

這是獲得的 .tex 檔：

\documentclass{book}

\usepackage[most]{tcolorbox}
\tcbuselibrary{skins,breakable,xparse}

\usepackage{polyglossia}
\setmainlanguage[numerals=maghrib]{arabic}
\setotherlanguage{english}
\setmainfont[Script=Arabic,Scale=1.2]{Arial}

\usepackage{parnotes}

\usepackage[para*]{manyfoot}
\DeclareNewFootnote[para]{C}
\makeatletter
\let\c@footnoteC\c@footnote
\makeatother

\renewcommand{\thefootnoteC}{\fnsymbol{footnote}}

\NewTColorBox[auto counter,number within=chapter]{exercise}{+O{}}{%
enhanced,colframe=green!20!black,colback=yellow!10!white,coltitle=green!40!black,
fonttitle=\bfseries,
underlay={\begin{tcbclipinterior}
\shade[inner color=green!80!yellow,outer color=yellow!10!white]
(interior.north west) circle (2cm);
\draw[help lines,step=5mm,yellow!80!black,shift={(interior.north west)}]
(interior.south west) grid (interior.north east);
\end{tcbclipinterior}},
title={Exercise~ \thetcbcounter:},
label={exercise@\thetcbcounter},
attach title to upper=\quad,
after upper={\par\hfill\textcolor{green!40!black}%
{\itshape Solution on page~\pageref{solution@\thetcbcounter}}},
lowerbox=ignored,
savelowerto=solutions/exercise-\thetcbcounter.tex,
record={\string\solution{\thetcbcounter}{solutions/exercise-\thetcbcounter.tex}},
#1
}

\NewTotalTColorBox{\solution}{mm}{%
enhanced,colframe=red!20!black,colback=yellow!10!white,coltitle=red!40!black,
fonttitle=\bfseries,
underlay={\begin{tcbclipinterior}
\shade[inner color=red!50!yellow,outer color=yellow!10!white]
(interior.north west) circle (2cm);
\draw[help lines,step=5mm,yellow!80!black,shift={(interior.north west)}]
(interior.south west) grid (interior.north east);
\end{tcbclipinterior}},
title={Solution of Exercise~\ref{exercise@#1} on page~\pageref{exercise@#1}:},
phantomlabel={solution@#1},
attach title to upper=\par,
}{\input{#2}}

\tcbset{no solution/.style={no recording,after upper=}}

\renewcommand{\theparnotemark}{\fnsymbol{parnotemark}} %% The mark for parnote
\renewcommand{\parnotefmt}[1]{\footnotesize\rmfamily
 \noindent\rule{\linewidth}{.5pt}\\ %% The rule before the footnotes
 \noindent #1\par
 \noindent\rule{\linewidth}{.5pt} %% The rule below the footnotes
 }
\begin{document}
\chapter{The first chapter}
\section{Exercises}
\tcbstartrecording
\begin{exercise}
\LR{Exercise with inlined footnotes, using manyfoot, \footnoteC{inlined footnote 1} and \footnoteC{inlined footnote 2}, in the question.}
\tcblower
\LR{Exercise with inlined footnotes, using manyfoot, \footnoteC{inlined footnote 1} and \footnoteC{inlined footnote 2}, in the answer.}
\end{exercise}
\begin{exercise}
\LR{1.  Exercise with inlined footnotes, using parnotes, \parnote{inlined footnote 1} and \parnote{inlined footnote 2}, in the question.}
\LR{\parnotes}
\tcblower
\LR{2.  Exercise with inlined footnotes, using parnotes, \parnote{inlined footnote 1} and \parnote{inlined footnote 2}, in the answer.}
\LR{\parnotes}
\end{exercise}

\begin{exercise}
\LR{Exercise with usual footnotes, \footnote{footnote 1} and \footnote{footnote 2}, in the question.}
\tcblower
\LR{Exercise with usual footnotes, \footnote{footnote 1} and \footnote{footnote 2}, in the answer.}
\end{exercise}
\tcbstoprecording
\section{Solutions of exercises}
\tcbinputrecords
\end{document}

及其編譯，使用 xelatex：

在此輸入影像描述

在此輸入影像描述
