試著將圖中的正方形改為圓形

Question

我正在嘗試製作帶有圓形的一維隔間圖，但是用圓形更改 tikzstyle 不會將其從方形更改為圓形。

\documentclass[12pt]{report}
\usepackage{caption}
\usepackage{tikz}
\usetikzlibrary{arrows}

\begin{document}

\tikzstyle{int}=[draw, line width = 0.5mm, minimum size=5em]
\tikzstyle{make circle}=[circle, line width = 0.5 mm, minimum size=5em]

\begin{figure}
\centering

\begin{tikzpicture}[node distance=3cm,auto,>=latex']

\node [int] (a) {};

%%%%%%%%%%%%%
\node [makecircle] (c) [] {$M$}; %% This is the problem (still makes a square)
%%%%%%%%%%%

\node [int] (d) [right of=c, node distance=4cm] {$E$};

\draw[->, ultra thick, blue] (c) edge node {$r(1-p)$} (d);

\draw [green, ultra thick, ->]
    ([xshift=-0.25cm]a.north) to[out=120, in=60, distance=1.5cm] ([xshift=0.25cm]a.north);
\node [above=1.0cm,text=green] at (a.north) {$pr$};
\draw [red, ultra thick, ->] (0,-1) -- (0,-2);
\node [right=0.5cm,below=0.15cm,text=red] at (a.south) {$\approx 0$};

\end{tikzpicture}
\caption{This is a two compartment model}

\end{figure}

\end{document}

Answer 1

\node [int] (a) {};你用（這裡沒有定義圓）畫圓，但用\node [makecircle] (c) [] {$M$};（這裡沒有draw）寫文本M（你寫的是makecircle而不是make circle。）

因為make circle只會添加circle，所以我刪除了 tikzstyle 並重複使用了該int樣式。

\documentclass[12pt]{report}
\usepackage{caption}
\usepackage{tikz}
\usetikzlibrary{arrows}

\begin{document}

\tikzstyle{int}=[draw, line width = 0.5mm, minimum size=5em]

\begin{figure}
\centering

\begin{tikzpicture}[node distance=3cm,auto,>=latex']
    \node[int, circle] (c) [] {$M$};

    \node [int] (d) [right of=c, node distance=4cm] {$E$};

    \draw[->, ultra thick, blue] (c) edge node {$r(1-p)$} (d);

    \draw [green, ultra thick, ->]
        ([xshift=-0.25cm]c.north) to[out=120, in=60, distance=1.5cm] ([xshift=0.25cm]c.north);
    \node [above=1.0cm,text=green] at (c.north) {$pr$};
    \draw [red, ultra thick, ->] (0,-1) -- (0,-2);
    \node [right=0.5cm,below=0.15cm,text=red] at (c.south) {$\approx 0$};
\end{tikzpicture}
\caption{This is a two compartment model}

\end{figure}

\end{document}
