tikz - 將節點放置在絕對位置

Question

如何將節點放置在 I 和 C 節點的交叉點 (I |- C)？微量元素：

\documentclass[border=2pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{chains}
\usetikzlibrary{arrows,chains,positioning,shapes,scopes}

\begin{document}

\begin{tikzpicture}
[>=latex,node distance=.8cm,
start chain =going below,]

\tikzset{base/.style = {
        draw,rounded corners,minimum width=20mm, minimum height=6mm, align=center,
        inner sep=1mm, outer sep=0mm,
        on chain, join=by {->}}}
\tikzset{start/.style={base,minimum size=6mm,circle,fill=black}}
\tikzset{end/.style={base,circle}}
\tikzset{box/.style={base}}
\tikzset{decision/.style={base,rounded corners=0,minimum size=6mm,diamond,aspect=1.5,on chain}}

{
  \node[start] (A) {};
  \node[box] (B) {clone repository};
  \node[box] (C) {coding};
  \node[box] (D) {commit locally};
  \node[box] (E) {review};
  \node[decision] (F) {};
  {[start branch]
      \node[box,left=2cm of F] (G) {rework};
      \node[box,on chain=going above] (H) {recommit};
  }
  {[start branch]
    \node[box,right=2cm of F] (I) {submit};
    \coordinate  (O)  at (I |- C);
    \node[box] at (O) (J)  {update local repository};
  }

\draw[->] (H) -- (E);
\draw[->] (J) -- (C);
% debug code line
\draw[red] (O) -- (I) (O) -- (C);
}
\end{tikzpicture}
\end{document}

節點 J 應該放在 O 處，但實際上不是！

Answer 1

節點位置的不匹配J是由節點on chain的屬性引起的box。如果您在此取消此屬性，該節點將位於您想要的位置。

因為我不知道，是否可以對鏈中的特​​定節點執行此操作，所以我重新組織了您的tikzsetso，該on chain選項從base並添加到box，稍後將在其他節點樣式的樣式定義中使用。

透過此更改以及連接線的一些更改（這在您的 MWE 中是不合邏輯的），我獲得了以下圖像：

這是您要找的嗎？

\documentclass[tikz, margin=3mm]{standalone}
\usetikzlibrary{chains, shapes}
\begin{document}
    \begin{tikzpicture}[>=latex,
  node distance = 8mm,
    start chain = going below,
    base/.style = {draw, rounded corners,
                   minimum width=20mm, minimum height=6mm,
                   align=center,
                   inner sep=1mm, outer sep=0mm,
                   },
     box/.style = {base, on chain, join=by {->}},
   start/.style = {box,minimum size=6mm,circle,fill=black},
     end/.style = {box,circle, on chain},
decision/.style = {box, diamond, aspect=1.5,
                   sharp corners, minimum size=6mm}
                        ]
\node[start] (A) {};
\node[box] (B) {clone repository};
\node[box] (C) {coding};
\node[box] (D) {commit locally};
\node[box] (E) {review};
\node[decision] (F) {};
{%[start branch]
      \node[box,left=2cm of F] (G) {rework};
      \node[box,on chain=going above] (H) {recommit};
  }
  {%[start branch]
    \node[base,
          right=2cm of F] (I) {submit};
    \node[base]  (J)  at (I |- C) {update local repository};
  }

\draw[->] (H) -- (E);
\draw[->] (F) -- (I);
% debug code line
\draw[red,->] (I) edge (J) (J) to (C);
    \end{tikzpicture}
\end{document}
