Tikzset 具有多個預設值

Question

\documentclass[tikz,border=10pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{decorations.markings}
\usetikzlibrary{arrows.meta}
\begin{document}

\tikzset{%
  parallelone/.style={%
    decoration={markings, mark= at position #1 with
    {\arrow[line width=0.5mm, stealth-]{Latex[length=2.5mm, width=2mm]}}},
    postaction={decorate}
  },
   parallelone/.default=0.5,
}

\begin{tikzpicture}
    \draw[parallelone] (0,0)--(4,4);
\end{tikzpicture}

\end{document}

（我知道已經有人問過類似的問題。）

為了處理多個參數，我認為我需要有pgfkeys，但我仍然很困惑（例如，在上面的範例中，事情有些嵌套）。有相關的簡單教學嗎？或者有人可以為上述案例提供一步一步的解釋嗎？ （即創建我在使用時可能需要更改的盡可能多的鍵（例如箭頭線寬度、箭頭類型、長度、寬度等）。）

Answer 1

既然你問的是教程，我分兩步驟回答這個問題。 （恕我直言，pgfmanual 是一個很棒的教程，特別是當您使用它來理解可以在本網站上找到的範例時。）能使樣式取決於多個參數。但如果您只想更改其中一項，則始終需要指定所有這些。因此，我想說的是，使用預設值將參數儲存在 pgfkeys 中更容易。這導致

\documentclass[tikz,border=10pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{decorations.markings}
\usetikzlibrary{arrows.meta}
\begin{document}

\tikzset{%
  parallelone arrow length/.initial=2.5mm,
  parallelone arrow width/.initial=2mm,
  parallelone arrow type/.initial=Latex,
  parallelone/.style={%
    decoration={markings, mark= at position #1 with
    {\arrow{\pgfkeysvalueof{/tikz/parallelone arrow type}[length=\pgfkeysvalueof{/tikz/parallelone arrow length},
    width=\pgfkeysvalueof{/tikz/parallelone arrow width}]}}},
    postaction={decorate}
  },
   parallelone/.default=0.5
}

\begin{tikzpicture}
    \draw[parallelone] (0,0)--(4,4);
    % change the length and poisition
    \draw[parallelone=0.7,parallelone arrow length=5mm] (1,0)--(5,4);
    % change the type. the length is back to its initial or default values
    \draw[parallelone,parallelone arrow type=Stealth] (2,0)--(6,4);
    % change the width. the other paraneters are at their initial or deault values
    \draw[parallelone,parallelone arrow width=5mm] (3,0)--(7,4);
\end{tikzpicture}
\end{document}

當然，在某個給定點，您可能決定不想總是鍵入parallelone arrowbefore type，length等等。這就是關鍵家庭的目的。然後您只能說\draw[parallelone={type=Stealth}]是否要更改類型並將其他所有內容保留為預設值。

\documentclass[tikz,border=10pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{decorations.markings}
\usetikzlibrary{arrows.meta}
\begin{document}

\tikzset{%
  parallelone/.style={%
    /utils/exec=\tikzset{parallelone arrow/.cd,#1},
    decoration={markings, mark= at position \pgfkeysvalueof{/tikz/parallelone arrow/pos} with
    {\arrow{\pgfkeysvalueof{/tikz/parallelone arrow/type}[%
    length=\pgfkeysvalueof{/tikz/parallelone arrow/length},%
    width=\pgfkeysvalueof{/tikz/parallelone arrow/width}]}}},
    postaction={decorate}
  },
  parallelone/.default={pos=0.5},
  parallelone arrow/.is family,
  parallelone arrow/.cd,
  pos/.initial=0.5,
  length/.initial=2.5mm,
  width/.initial=2mm,
  type/.initial=Latex,
}

\begin{tikzpicture}
    \draw[parallelone] (0,0)--(4,4);
    % change the length and poisition
    \draw[parallelone={pos=0.7,length=5mm}] (1,0)--(5,4);
    % change the type. the length is back to its initial or default values
    \draw[parallelone={type=Stealth}] (2,0)--(6,4);
    % change the width. the other parameters are at their initial or deault values
    \draw[parallelone={width=5mm}] (3,0)--(7,4);
\end{tikzpicture}
\end{document}

如果您想要兩個具有相同功能的箭頭，您可以嘗試

\documentclass[tikz,border=10pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{decorations.markings}
\usetikzlibrary{arrows.meta}
\begin{document}

\tikzset{%
  parallelone/.style={%
    /utils/exec=\tikzset{parallelone arrow/.cd,#1},
    decoration={markings, mark= at position \pgfkeysvalueof{/tikz/parallelone arrow/pos} with
    {\arrow{\pgfkeysvalueof{/tikz/parallelone arrow/type}[%
    length=\pgfkeysvalueof{/tikz/parallelone arrow/length},%
    width=\pgfkeysvalueof{/tikz/parallelone arrow/width}]}}},
    postaction={decorate}
  },
  paralleltwo/.style={%
    /utils/exec=\tikzset{parallelone arrow/.cd,#1},
    decoration={markings, mark= at position \pgfkeysvalueof{/tikz/parallelone arrow/pos} with
    {\arrow{\pgfkeysvalueof{/tikz/parallelone arrow/type}[%
    length=\pgfkeysvalueof{/tikz/parallelone arrow/length},%
    width=\pgfkeysvalueof{/tikz/parallelone arrow/width}]%
    \pgfkeysvalueof{/tikz/parallelone arrow/type}[%
    length=\pgfkeysvalueof{/tikz/parallelone arrow/length},%
    width=\pgfkeysvalueof{/tikz/parallelone arrow/width}]}}},
    postaction={decorate}
  },
  parallelone/.default={pos=0.5},
  parallelone arrow/.is family,
  parallelone arrow/.cd,
  pos/.initial=0.5,
  length/.initial=2.5mm,
  width/.initial=2mm,
  type/.initial=Latex,
}

\begin{tikzpicture}
    \draw[paralleltwo] (0,0)--(4,4);
    % change the length and poisition
    \draw[parallelone={pos=0.7,length=5mm}] (1,0)--(5,4);
    % change the type. the length is back to its initial or default values
    \draw[parallelone={type=Stealth}] (2,0)--(6,4);
    % change the width. the other parameters are at their initial or deault values
    \draw[parallelone={width=5mm}] (3,0)--(7,4);
\end{tikzpicture}
\end{document}
