繪製周圍的矩形

Question

如果您不指定節點的座標或相對位置，則會將其放置在 (0,0) 處。這意味著 C_11 節點位於 (0,0)。所有其他節點都位於該節點的右側和/或下方，因此 a 自然\draw (0,0) rectangle (10,40);不會適合第一列，因為 y 軸的正方向是向上的。另外，由於預設單位向量的長度為 1 厘米，因此您將獲得一個 10 厘米 x 40 厘米的矩形，這太大了。

當然，使用rectangle路徑的一些其他座標也可以，例如

\draw (-1,1.2) rectangle (1,-9.8);

但你也可以使用fit圖書館。添加\usetikzlibrary{fit}到序言中，並且

\node [draw, fit=(v1)(v10), inner sep=30pt] {};

圖中。這將創建一個適合v1和v10節點周圍的節點。它比該樣式中使用的inner sep一半多一點。line widthedge

不相關的評論：\tikzstyle{foo}=[..]通常被認為已棄用，有利於\tikzset{foo/.style={...}}.並且在頂部標籤中，不要包含Task數學表達式的一部分。改為寫Task \( T_1 \)例如。

\documentclass{article}
\pagestyle{empty}
\usepackage{tikz}
\usetikzlibrary{fit}
\tikzset{
  vertex/.style={
     fill,
     shape=circle,
     node distance=80pt},
  edge/.style={
     fill,
     opacity=.2,
     fill opacity=.5,
     line cap=round,
     line join=round,
     line width=50pt},
  elabel/.style={
     fill,
     shape=circle,
     node distance=30pt,
     opacity = .2}
}

\pgfdeclarelayer{background}
\pgfsetlayers{background,main}

\begin{document}

\begin{tikzpicture}
\begin{pgfonlayer}{background}
\node[vertex,label={[font = \Large]above:\(C_{11}, \$30\)}, label={[font = \Large]below:\(F_{1}, F_{2}\)}] (v1) {};

\node[vertex,right of=v1,label={[font = \Large]above:\(C_{21}\)}, label={[font = \Large]below:\(F_{1}, F_{2}\)}] (v2) {};

\node[vertex,right of=v2,label={[font = \Large]above:\(C_{31}\)}, label={[font = \Large]below:\(F_{6}\)}] (v3) {};


\node[vertex,below of=v1,label={[font = \Large]above:\(C_{12},\$40\)}, label={[font = \Large]below:\(F_{1}, F_{2}\)}] (v4) {};

\node[vertex,right of=v4,label={[font = \Large]above:\(C_{22},\$20\)}, label={[font = \Large]below:\(F_{1}, F_{2}\)}] (v5) {};

\node[vertex,right of=v5,label={[font = \Large]above:\(C_{32},\$20\)}, label={[font = \Large]below:\(F_{6}\)}] (v6) {};


\node[vertex,below of=v4,label={[font = \Large]above:\(C_{31},\$45\)}, label={[font = \Large]below:\(F_{1}\)}] (v7) {};

\node[vertex,below of=v5,label={[font = \Large]above:\(C_{32},\$50\)}, label={[font = \Large]below:\(F_{4}, F_{5}\)}] (v8) {};

\node[vertex,below of=v6,label={[font = \Large]above:\(C_{33},\$40\)}, label={[font = \Large]below:\(F_{4}, F_{5}\)}] (v9) {};



\node[vertex,below of=v7,label={[font = \Large]above:\(C_{41}, \$30\)}, label={[font = \Large]below:\(F_{1}\)}] (v10) {};

\node[vertex,below of=v8,label={[font = \Large]above:\(C_{42}, \$70\)}, label={[font = \Large]below:\(F_{4}, F_{5}\)}] (v11) {};


\draw[edge,color=yellow,line width=65pt] (v2) -- (v3);

\draw[edge,color=red,line width=65pt] (v1) -- (v5);


\draw[edge,color=blue,line width=65pt] (v10) -- (v8) -- (v6);


\draw[edge,color=green, line width=65pt] (v10) -- (v11) -- (v6);


\end{pgfonlayer}

\node[elabel,color=yellow,label=right:\(\$25\)]  (e1) at (7,0) {};
\node[elabel,below of=e1,color=red,label=right:\(\$30\)]  (e2) {};
\node[elabel,below of=e2,color=blue,label=right:\(\$70\)]  (e3) {};
\node[elabel,below of=e3,color=green,label=right:\(\$90\)]  (e4) {};

%Task nodes

\node[above of=v1,label={[font = \Large]above:Task \( T_1\)}] (t1) {};

\node[above of=v2,label={[font = \Large]above:Task \(T_2\)}] (t2) {};

\node[above of=v3,label={[font = \Large]above:Task \(T_3\)}] (t3) {};


%\draw (-1,1.2) rectangle (1,-9.8);

\node [draw, fit=(v1)(v10), inner sep=30pt] {};
\end{tikzpicture}
\end{document}
