顯示奇數

Question

如何在 上顯示奇數xticklabels？

程式碼:

\documentclass[margin=3mm]{standalone}
\usepackage[english,spanish]{babel}         % multilenguaje
\usepackage{pgfplots}
\usetikzlibrary{babel,
    positioning}
\pgfplotsset{compat=1.16,width=0.98\linewidth}



\usepackage{filecontents}
\begin{filecontents}{performance.data}
    x    A       B         C        D        E         F
    0.01 0.9126  0.9126   0.9313   0.9494   0.9524   0.9462
    0.02 0.8872  0.8872   0.8980   0.9044   0.9014   0.8966
    0.03 0.8713  0.8713   0.8747   0.8767   0.8737   0.8722
    0.05 0.8549  0.8549   0.8552   0.8541   0.8538   0.8532
    0.09 0.8710  0.8710   0.8700   0.8687   0.8676   0.8667
    0.10 0.8782  0.8782   0.8771   0.8751   0.8740   0.8738
    0.20 0.9301  0.9301   0.9281   0.9275   0.9269   0.9271
\end{filecontents}
\decimalpoint


\begin{document}
    \begin{tikzpicture}
    \begin{axis}[
    grid = none,
    legend style={at={(0.97,0.03)}, anchor=south east, draw=black},
%   legend cell align=left,
%   legend pos=north east,
    xmin=0.000499999999999999, xmax=0.2095,
    ylabel={RMSE},
    xlabel={$\lambda$},
    %
    xticklabel style={font=\small,
        /pgf/number format/fixed},
    yticklabel style={font=\small},
    %
    every axis plot post/.append style={line width=1.2pt},
    %
    mark size=1.3pt,
    cycle list={
        {blue,mark=*},
        {black,mark=*},
        {red,mark=*},
        {green,mark=*},
        {orange,mark=*},
        {cyan,mark=*},% <-- don't add a comma here
    },
    ]
    \addplot    table [y=A] {performance.data};
    \addlegendentry{20 f}
    \addplot    table [y=B] {performance.data};
    \addlegendentry{40 f}
    \addplot    table [y=C] {performance.data};
    \addlegendentry{60 f}
    \addplot    table [y=D] {performance.data};
    \addlegendentry{100 f}
    \addplot    table [y=E] {performance.data};
    \addlegendentry{150 f}
    \addplot    table [y=F] {performance.data};
    \addlegendentry{200 f}
    \end{axis}
    \end{tikzpicture}
\end{document}

Answer 1

將評論轉換為答案。

您可以xticks像這樣手動提及：

xtick={0.01,0.03,...,0.20},

這樣只會顯示奇數刻度。

結果：

\documentclass[margin=3mm]{standalone}
\usepackage[english,spanish]{babel}         % multilenguaje
\usepackage{pgfplots}
\usetikzlibrary{babel,positioning}
\pgfplotsset{compat=1.16,width=0.98\linewidth}
\usepackage{filecontents}
\begin{filecontents}{performance.data}
    x    A       B         C        D        E         F
    0.01 0.9126  0.9126   0.9313   0.9494   0.9524   0.9462
    0.02 0.8872  0.8872   0.8980   0.9044   0.9014   0.8966
    0.03 0.8713  0.8713   0.8747   0.8767   0.8737   0.8722
    0.05 0.8549  0.8549   0.8552   0.8541   0.8538   0.8532
    0.09 0.8710  0.8710   0.8700   0.8687   0.8676   0.8667
    0.10 0.8782  0.8782   0.8771   0.8751   0.8740   0.8738
    0.20 0.9301  0.9301   0.9281   0.9275   0.9269   0.9271
\end{filecontents}
\decimalpoint


\begin{document}
    \begin{tikzpicture}
    \begin{axis}[
    grid = none,
    legend style={at={(0.97,0.03)}, anchor=south east, draw=black},
%   legend cell align=left,
%   legend pos=north east,
    xmin=0.000499999999999999, xmax=0.2095,
    ylabel={RMSE},
    xlabel={$\lambda$},
    %
    xtick={0.01,0.03,...,0.20},
    xticklabel style={font=\small,
        /pgf/number format/fixed},
    yticklabel style={font=\small},
    %
    every axis plot post/.append style={line width=1.2pt},
    %
    mark size=1.3pt,
    cycle list={
        {blue,mark=*},
        {black,mark=*},
        {red,mark=*},
        {green,mark=*},
        {orange,mark=*},
        {cyan,mark=*},% <-- don't add a comma here
    },
    ]
    \addplot    table [y=A] {performance.data};
    \addlegendentry{20 f}
    \addplot    table [y=B] {performance.data};
    \addlegendentry{40 f}
    \addplot    table [y=C] {performance.data};
    \addlegendentry{60 f}
    \addplot    table [y=D] {performance.data};
    \addlegendentry{100 f}
    \addplot    table [y=E] {performance.data};
    \addlegendentry{150 f}
    \addplot    table [y=F] {performance.data};
    \addlegendentry{200 f}
    \end{axis}
    \end{tikzpicture}
\end{document}
