Tikz 圈子幫助

Question

我正在使用 TikZ 繪製分支定界樹，我需要一些幫助。

這是我的程式碼：

\documentclass[
    12pt,
    oneside,
    a4paper,
    english,
    french,
    spanish,
    brazil
    ]{abntex2}
\usepackage{graphicx}
\usepackage{float}
\usepackage{tikz}
\usetikzlibrary{calc, shapes}

\begin{document}

\begin{figure}[H]
\centering
\tikzset{thick,
         tree node/.style = {align=center, inner sep=0pt, font = \scriptsize},
every label/.append style = {font=\scriptsize},
                 S/.style = {draw, circle, minimum size = 20mm, inner sep=0pt,
                             top color=white, bottom color=blue!20},
               ENL/.style = {% edge node left
                             font=\footnotesize, left=1pt},
               ENR/.style = {% edge node right
                             font=\footnotesize, right=1pt},
                     grow = down,
         sibling distance = 2.8cm,
           level distance = 3cm
           }
\begin{tikzpicture}
\node [S, label= 2:Some text here] {$PL0$}
    child{node [S] {$PL1$}
            child{node [S] {$PL3$}
            edge from parent node[ENL] {$x2 \leq 2$}}
            child{node [S] {$PL4$}
                 child{node [S] {$PL5$}
                     child{node [S] {$PL7$}
                     edge from parent node[ENL] {$x2 \leq 3$}}
                     child{node [S, label = 2:More text here] {$PL8$}
                     edge from parent node[ENR] {$x2 \geq 4$}}
          edge from parent node[ENL] {$x1 \leq 3$}}
          child{node [S, label = 2:Another text here] {$PL6$}
          edge from parent node[ENR] {$x1 \geq 4$}}
            edge from parent node[ENR] {$x2 \geq 3$}}
    edge from parent node[ENL] {$x1 \leq 4$}}
    child{node [S, label = 2:Last text here] {$PL2$}
    edge from parent node[ENR] {$x1 \geq 5$}};
\end{tikzpicture}
        \caption{My Figure.}
\end{figure}

\end{document}

結果，您應該得到這個數字：

嗯，我需要幫忙解決兩件事：

1. 即使使用該\centering命令，圖形也不居中。我在這裡缺少什麼？

2. 我需要在這些圈子內寫更多資訊。例如，在第一個 (PL0) 中，它應該具有以下附加資訊：

我嘗試了很多東西，但無法使這些資訊符合圓圈。

Answer 1

1. 圖是居中。為了驗證這一點，我在文字區域和tikzpicture.
2. 如果您想在圈子中添加更多內容，則需要將其添加到節點內容中。如果要允許多行文本，則需要添加適當的對齊（或text width）鍵，例如align=center。

\documentclass[
    12pt,
    oneside,
    a4paper,
    english,
    french,
    spanish,
    brazil
    ]{abntex2}
\usepackage[showframe]{geometry}
\usepackage{float}
\usepackage{tikz}
\usetikzlibrary{calc, shapes}

\begin{document}

\begin{figure}[H]
\centering
\tikzset{thick,
         tree node/.style = {align=center, inner sep=0pt, font = \scriptsize},
every label/.append style = {font=\scriptsize},
                 S/.style = {draw, circle, minimum size = 20mm, inner sep=0pt,
                             top color=white, bottom color=blue!20,
                             align=center}, %<-
               ENL/.style = {% edge node left
                             font=\footnotesize, left=1pt},
               ENR/.style = {% edge node right
                             font=\footnotesize, right=1pt},
                     grow = down,
         sibling distance = 2.8cm,
           level distance = 3cm
           }
\begin{tikzpicture}
\node [S, label= 2:Some text here] {$PL0$}
    child{node [S] {$PL0$\\ $x_1 = 4,333$ e\\ $x_2 = 2$ \\ $f = 42$}
            child{node [S] {$PL3$}
            edge from parent node[ENL] {$x2 \leq 2$}}
            child{node [S] {$PL4$}
                 child{node [S] {$PL5$}
                     child{node [S] {$PL7$}
                     edge from parent node[ENL] {$x2 \leq 3$}}
                     child{node [S, label = 2:More text here] {$PL8$}
                     edge from parent node[ENR] {$x2 \geq 4$}}
          edge from parent node[ENL] {$x1 \leq 3$}}
          child{node [S, label = 2:Another text here] {$PL6$}
          edge from parent node[ENR] {$x1 \geq 4$}}
            edge from parent node[ENR] {$x2 \geq 3$}}
    edge from parent node[ENL] {$x1 \leq 4$}}
    child{node [S, label = 2:Last text here] {$PL2$}
    edge from parent node[ENR] {$x1 \geq 5$}};
\draw (current bounding box.south west) rectangle (current bounding box.north east);
\end{tikzpicture}
        \caption{My Figure.}
\end{figure}

\end{document}

我還建議您查看forest包裝。
