TikZ 圖片水平居中

我有一些想要使用的圖形，但由於第一個圖形比第二個圖形大，因此第二個圖形相對於第一個圖形的下緣放置。我的程式碼：

\begin{figure}[h]
\centering
\begin{tikzpicture}[scale=0.9]
    \draw[->] (0, 0) -- (6, 0) node[right] {$z$};
    \draw[->] (0, 0) -- (0, 6) node[above] {$x$};
    \coordinate (a) at (5, 1);
    \node[fill=red, circle, scale=0.3, label=above:{$s$}] (s) at (5, 5) {};
    \node[fill=red, circle, scale=0.3, label=below:{$e$}] (e) at (1, 1) {};
    \draw (s) -- (e);
    \node[fill=red, circle, scale=0.3, label=above:{$m^*$}] (m*) at (2.293, 3.707) {};
    \node[fill=red, circle, scale=0.3, label=right:{$m$}] (m) at (3, 3) {};
    \draw (m) -- (m*);
    \draw[dashed] (s) -- (a) node[pos=0.5, label=right:{$\Delta x$}] -- (e) node[pos=0.5, label=below:{$\Delta z$}] {};
\end{tikzpicture}
\hspace{10mm}
\begin{tikzpicture}
    \coordinate (ayy) at (4.293, 1);
    \coordinate (mstar) at (4.293, 3.707);
    \coordinate (emm) at (7, 1);
    \node[fill=red, circle, scale=0.3, label=above:{$m^*$}] (m*) at (mstar) {};
    \node[fill=red, circle, scale=0.3, label=right:{$m$}] (m) at (emm) {};
    \node[fill=none, inner sep=0, outer sep=0] (a) at (ayy) {};
    \draw (m) -- (m*) node[pos=0.6, label=right:{$d$}] {};
    \draw[dashed] (a) -- (m*) node[pos=0.5, label=left:{$d\cos\alpha$}] {};
    \draw[dashed] (a) -- (m) node[pos=0.5, label=below:{$d\sin\alpha$}] {};
    \pic[draw, "$\alpha$", angle eccentricity=1.2, angle radius=7mm] {angle=ayy--mstar--emm};
\end{tikzpicture}
\caption{Calculating $m^*$ (Case 1)}
\end{figure}

我目前擁有的： 我擁有的

我想得到什麼： 我想得到什麼:

答案1

歡迎！方法有很多，我舉兩個例子：

  1. 使用\vcenter。也許最簡單的使用方法是將其置於數學模式。
  2. 僅使用一張圖片並使用範圍。

在第二個範例中，我透過使用極座標、使用解析器解析座標、組合路徑等稍微簡化了程式碼。

\documentclass{article}
\usepackage{tikz}
\usetikzlibrary{angles,quotes}
\begin{document}
\begin{figure}[h]
\centering
$\vcenter{\hbox{\begin{tikzpicture}[scale=0.9]
    \draw[->] (0, 0) -- (6, 0) node[right] {$z$};
    \draw[->] (0, 0) -- (0, 6) node[above] {$x$};
    \coordinate (a) at (5, 1);
    \node[fill=red, circle, scale=0.3, label=above:{$s$}] (s) at (5, 5) {};
    \node[fill=red, circle, scale=0.3, label=below:{$e$}] (e) at (1, 1) {};
    \draw (s) -- (e);
    \node[fill=red, circle, scale=0.3, label=above:{$m^*$}] (m*) at (2.293, 3.707) {};
    \node[fill=red, circle, scale=0.3, label=right:{$m$}] (m) at (3, 3) {};
    \draw (m) -- (m*);
    \draw[dashed] (s) -- (a) node[pos=0.5, label=right:{$\Delta x$}]{}
     -- (e) node[pos=0.5, label=below:{$\Delta z$}] {};
\end{tikzpicture}}}
\hspace{10mm}
\vcenter{\hbox{\begin{tikzpicture}
    \coordinate (ayy) at (4.293, 1);
    \coordinate (mstar) at (4.293, 3.707);
    \coordinate (emm) at (7, 1);
    \node[fill=red, circle, scale=0.3, label=above:{$m^*$}] (m*) at (mstar) {};
    \node[fill=red, circle, scale=0.3, label=right:{$m$}] (m) at (emm) {};
    \node[fill=none, inner sep=0, outer sep=0] (a) at (ayy) {};
    \draw (m) -- (m*) node[pos=0.6, label=right:{$d$}] {};
    \draw[dashed] (a) -- (m*) node[pos=0.5, label=left:{$d\cos\alpha$}] {};
    \draw[dashed] (a) -- (m) node[pos=0.5, label=below:{$d\sin\alpha$}] {};
    \pic[draw, "$\alpha$", angle eccentricity=1.2, angle radius=7mm] {angle=ayy--mstar--emm};
\end{tikzpicture}}}$
\end{figure}

\begin{figure}[h]
\centering
\begin{tikzpicture}[bullet/.style={fill=red, circle, scale=0.3, label=#1}]
  \begin{scope}[scale=0.9]
    \draw[<->] (0, 6) node[above] {$x$} |- (6, 0) node[right] {$z$};
    \coordinate (a) at (5, 1);
    \node[bullet=above:{$s$}] (s) at (5, 5) {};
    \node[bullet=below:{$e$}] (e) at (1, 1) {};
    \draw (s) -- node[fill=red, circle, scale=0.3, label=right:{$m$}] (m){}  (e)
        (m) ++ (135:1)
        node[fill=red, circle, scale=0.3, label=above:{$m^*$}] (m*) {};
    \draw (m) -- (m*);
    \draw[dashed] (s) |- (e) node[pos=0.75,below] {$\Delta z$}
    node[pos=0.25,right](dx){$\Delta x$};
  \end{scope}
  \begin{scope}
    \path (dx)  ++ (3,{-1-1/sqrt(8)})  coordinate (a)
        ++ (0,{2+1/sqrt(2)})
        node[bullet=above:{$m^*$}] (m*) {}
        (a) ++ ({2+1/sqrt(2)},0)
        node[bullet=right:{$m$}] (m){};
    \draw (m) -- (m*);
    \draw[dashed] (m*)  --  node[left] (dc){$d\cos\alpha$} (a)
        -- node[below]{$d\sin\alpha$} (m);
    \pic[draw, "$\alpha$", angle eccentricity=1.2, angle radius=7mm]
    {angle=a--m*--m};
  \end{scope}
\end{tikzpicture}
\end{figure}
\end{document}

在此輸入影像描述

順便說一句，網站的通常格式是提供完整的最小工作範例（MWE）。這些程式碼包含需要編譯的所有內容，通常\documentclass以\end{document}.就您而言，我不知道您正在使用什麼文檔類，所以我必須猜測，以及您正在加載哪些包（超出了運行您的程式碼片段所需的套件）。您很可能已經加載了一些具有以另一種方式解決您的問題的工具的東西。

答案2

另一種可能性是在選定的基線處對齊影像。例如，稍微修改一下圖像程式碼，MWE 為：

\documentclass{article}
\usepackage{tikz}
\usetikzlibrary{angles,
                calc, % new
                quotes}

\begin{document}
    \begin{figure}[h]
    \tikzset{dot/.style = {circle, fill=red, minimum size=3pt, inner sep=0pt}}% new
\begin{tikzpicture}[baseline=(X.center)] % <---
% caxes
    \draw[->] (0,0) -- (6, 0) node[right] {$z$};
    \draw[->] (0,0) -- (0, 6) node[above] {$x$};
% triangle
\node (s) [dot, label=$s$]          at (5,5) {};
\node (e) [dot, label=below:{$e$}]  at (1,1) {};
\draw (s) -- node (m) [dot, label=right:$m$] {} (e);
\node (m*) [dot, label=$m^*$] at ($(m)!10mm!90:(s)$) {};
    \node[fill=red, circle, scale=0.3, label=right:{$m$}] (m) at (3, 3) {};
\draw (m) -- (m*);
\draw[dashed] (e) -| (s) node[pos=0.25, label=below:$\Delta z$] {}
                         node (X) [pos=0.75, label=right:$\Delta x$] {}; % <---
\end{tikzpicture}
    \hfill
\begin{tikzpicture}[baseline=(X.center)] % <---
\node (m*) [dot, label=above:$m^*$] {};
\node (m)  [dot, label=right:$m$]   at (3,-3) {};
\draw (m*) -- node[label=right:$d$] {} (m);
\draw[dashed] (m*) |- (m)   node (X) [pos=0.25, label=left:$d\cos\alpha$] {} % <---
                            coordinate[pos=0.5] (a)  % <---
                            node[pos=0.75, label=below:$d\sin\alpha$] {};
\pic[draw, "$\alpha$", angle eccentricity=1.2, angle radius=7mm] {angle=a--m*--m};
\end{tikzpicture}
\end{figure}
\caption{Calculating $m^*$ (Case 1)}
\end{document}

在此輸入影像描述
