如何在報告文件中加入 IEEE 風格的參考書目和新章節?

如何在報告文件中加入 IEEE 風格的參考書目和新章節?

我目前正在寫論文,我想要一個準備好的範本來專注於寫作。我的問題是我必須使用 IEEE 風格將參考文獻放入我的文件中,但我在實現這一點時遇到了問題。我看過一些使用 bibtext 文件解釋這一點的視頻,但是當我嘗試這樣做時,它根本不起作用。順便說一句,我有一個 bibtext 文件,其中包含一些已編寫的參考文獻,名為 biblio_MT。另外,我想在文件中新增一個新章節並在目錄中引用它。新的章節應該叫“Anexos”,這個我也做不到。我的程式碼如下:

\documentclass[letterpaper,openright,12pt]{report}
\usepackage[spanish]{babel} %Defino idioma como español
\usepackage{graphicx} % Para Añadir imagenes
\usepackage{subfigure} %Para las subfiguras
\usepackage{caption}
\usepackage[spanish]{babel}
\selectlanguage{spanish}
\usepackage[utf8]{inputenc}
\usepackage[usenames, dvipsnames]{color}
%\usepackage{hyperref} % Para que el pdf referencie directamente las referencias
\usepackage{amssymb,amsmath,amsfonts} %para \textbf y otras cosas
\usepackage{setspace} %sirve para espaciado del documento entre otras cosas
\usepackage{dsfont}% para conjunto entero, reales.
\usepackage{stackrel}%paquete matematico para algunos simbolos
\usepackage{comment}
\usepackage{natbib}
\usepackage{float}
\usepackage[utf8]{inputenc}
\usepackage{enumerate} % enumerados
\usepackage{hyperref}
%\usepackage[latin1]{inputenc}
%\usepackage[sort&compress]{natbib}

%%%%%%%%% TABLAS %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\usepackage{longtable}
\usepackage{multirow} % para las tablas
\usepackage{multicol}% Para separar columnas
\usepackage{booktabs}
%\usepackage{babelbib} %para que las referencias esten en español
\usepackage{listings} %Para agregar codigos
\usepackage{algorithm} %Para escribir pseudocodigos
\usepackage[noend]{algpseudocode} %Para escribir pseudocodigos


%FORMATOS ESPECIFICOS MEMORIA
\setlength{\parindent}{0cm} %0 sangria
\spacing{1.15} %Espaciado
%\usepackage{times} %Letra times new Roman
\usepackage{Helvet}
\usepackage{anysize}% Para definir margenes
\marginsize{2.5cm}{2cm}{2.5cm}{2cm}% Controla los márgenes {izquierda}{derecha}{arriba}{abajo}
% IMAGEN DE FONDO
%La opción pages puede ser all (para todo el documento) o some, para algunas partes del documento
%\usepackage[pages=all]{background}
% configuración
%\%backgroundsetup{
%   scale=.2, %escala de la imagen, es recomendable que sea del mismo tamaño que el pdf
%   color=black, %fondo a usar para transparencia
%   opacity=0.2, %nivel de transparencia
%   angle=0, %en caso de querer una rotación
%   contents={%
%       \includegraphics[width=\paperwidth,height=\paperheight]{Figuras/Logo_Udec.jpg} %nombre de la imagen a utilizar como fondo
%   }}

%%Tratando de poner python
\definecolor{mygreen}{rgb}{0,0.6,0}
\definecolor{mygray}{rgb}{0.5,0.5,0.5}
\definecolor{mymauve}{rgb}{0.58,0,0.82}

\lstset{ %
  backgroundcolor=\color{white},   % choose the background color
  basicstyle=\footnotesize,        % size of fonts used for the code
  breaklines=true,                 % automatic line breaking only at whitespace
  captionpos=b,                    % sets the caption-position to bottom
  commentstyle=\color{mygreen},    % comment style
  escapeinside={\%*}{*)},          % if you want to add LaTeX within your code
  keywordstyle=\color{blue},       % keyword style
  stringstyle=\color{mymauve},     % string literal style
}





%Formato del titulo de los capitulos
\usepackage{titlesec} %paquete para cambiar el formato de los titulos

\newcommand{\bigrule}{\titlerule[0.5mm]}
{\vspace{-5cm}
    \titleformat{\chapter}[display] % cambiamos el formato de los capítulos
    {\bfseries\Huge} % por defecto se usarán caracteres de tamaño \Huge en negrita
    {% contenido de la etiqueta
        %\titlerule % línea horizontal
        \filright % texto alineado a la derecha
        \Large\chaptertitlename\ % "Capítulo" o "Apéndice" en tamaño \Large en lugar de \Huge
        \Large\thechapter} % número de capítulo en tamaño \Large
    {0mm} % espacio mínimo entre etiqueta y cuerpo
    {\filright} % texto del cuerpo alineado a la derecha
    [\vspace{0.5mm} \bigrule] % después del cuerpo, dejar espacio vertical y trazar línea horizontal gruesa

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%Numeracion de paginas en esquina superior derecha
\usepackage{fancyhdr}
% primera pagina de un capitulo
\fancypagestyle{plain}{
    \fancyhead[L]{}
    \fancyhead[C]{}
    \fancyhead[R]{\thepage}
    \fancyfoot[L]{}
    \fancyfoot[C]{}
    \fancyfoot[R]{}
    \renewcommand{\headrulewidth}{0pt}
    \renewcommand{\footrulewidth}{0pt}
}
\fancyhead[R]{\thepage}
\fancyhead[L]{}
\fancyhead[C]{}
\fancyfoot[L]{}
\fancyfoot[C]{}
\fancyfoot[R]{}
\renewcommand{\headrulewidth}{0 pt}
\pagestyle{fancy}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

%\usepackage{hyperref}
\begin{document}
\renewcommand{\contentsname}{Índice General}
\renewcommand{\listfigurename}{Índice de Figuras}

%Redefino algunos casos como tablas, referencias
\renewcommand{\tablename}{Tabla}
\renewcommand{\listtablename}{\'Indice de Tablas}
\renewcommand{\bibname}{ \text{\Large Cap\'itulo 7} \\ Referencias}
%\renewcommand{\bibname}{}
\newcommand{\source}[1]{\caption*{Fuente: {#1}} } % Para poderle añadir la fuente a las figuras

%    \NoBgThispage % para evitar el logo udec de fondo en la primera pagina
    \begin{titlepage}
        \begin{center}
        \sffamily{\LARGE \textbf{UNIVERSIDAD DE CONCEPCIÓN}} %\\[-240pt]
        \\
        \sffamily{\normalsize FACULTAD DE INGENIER\'IA}
        \\
        \sffamily{\normalsize DEPARTAMENTO DE INGENIER\'IA INDUSTRIAL}
        \vfill
        %\scalebox{0.37}{\includegraphics{Figuras/Logo_Udec.jpg}} % Para añadir el logo de la escuela
        \sffamily{\normalsize \hfill Profesor Patrocinante: $\hspace{2.25cm}$ \\ \hfill \textbf{Maichel M. Aguayo} $\hspace{2.65cm}$ }\\[-35pt]
        \scalebox{0.37}{\includegraphics{Logo_Udec.jpg}} % Para añadir el logo de la escuela
        \vfill
        \sffamily{ \hfill Informe de Memoria de T\'itulo $\hspace{.9cm}$ \\ \hfill Para optar al T\'itulo de: $\hspace{2.165cm}$}\\[-20pt]
        \vfill
        \sffamily{\normalsize  \hfill \textbf{Ingeniero Civil Industrial} $\hspace{1.5cm}$ }\\[50pt]
        \vfill
        \sffamily{\LARGE Problema de Ruteo de Veh\'iculos con Múltiples Depósitos, Múltiples Productos, Split Delivery y Fixed Destination}\\[100pt]
        \end{center}
        \vfill
        \sffamily{Concepci\'on, Agosto del 2018 \hfill Gonzalo Gálvez Bobadilla}

\newpage

\thispagestyle{empty}
\ \\
\vspace{5cm}

        \newpage
        \thispagestyle{empty}
        \sffamily{UNIVERSIDAD DE CONCEPCI\'ON \hfill Profesor Patrocinante:}\textmd
        \\
        \sffamily{Facultad de Ingenier\'ia \hfill Maichel M. Aguayo}
        \\
        \sffamily{Departamento de Ingenier\'ia Industrial}
        \vfill
        \begin{center}
            %\scalebox{0.37}{\includegraphics{IPN.eps}} % Para añadir el logo de la escuela
            \vfill
            % Genera un espacio
            \sffamily{\LARGE Problema de Ruteo de Veh\'iculos con Múltiples Depósitos, Múltiples Productos, Split Delivery y Fixed Destination}\\[60pt]
            \vfill
            \text{\Large Gonzalo Eduardo Gálvez Bobadilla}
            \vfill
            \sffamily{Informe de Memoria de T\'itulo \\ Para optar al T\'itulo de}\\[-40pt]
            \vfill
            \sffamily{\Large{Ingeniero Civil Industrial}}\\[50pt]
            \vfill
            \sffamily{\Large{Agosto 2018}}\\[10pt]
        \end{center}
    \end{titlepage}




\newpage
\chapter*{Agradecimientos}
\thispagestyle{empty}
%\setcounter{page}{1}
%\addcontentsline{toc}{chapter}{Agradecimientos}
\begin{quotation}
    \thispagestyle{empty}
    \noindent \textit{En primer lugar, quiero agradecer a mi madre por todo su amor incondicional y por siempre haberse mantenido firme, incluso en los momentos más difíciles.}\\ \\
    \noindent \textit{A mis hermanas, por todo lo que han hecho por mí, que es imposible explicar en palabras.}\\

    \noindent \textit{A mi cuñado, por guiarme desde pequeño en el basto mundo de la ingeniería industrial.}\\

    \noindent \textit{A mi profesor guía, por todo los conocimientos que me entregó y por jugársela por mí.}\\

    \noindent \textit{A mis amigos, por estar siempre ahí, en las buenas y en las malas.}




\end{quotation}
\newpage
\chapter*{Resumen}
\thispagestyle{empty}
%\addcontentsline{toc}{chapter}{Resumen}
\begin{quotation}
    El presente trabajo aborda un problema de ruteo de vehículos con múltiples productos, múltiples depósitos, \emph{split delivery} y \emph{fixed destination}. Para este problema se plantea un modelo de programación matemática, el cual fue resuelto en \emph{IBM Cplex Studio IDE 12.7.1} y una heurística diseñada en \emph{Python 3.5}. Se utilizaron instancias de \emph{Coredeaus}, obtenidas desde el sitio web \emph{Networking and Emerging Optimization}, para probar el funcionamiento tanto del modelo como de la heurística. Además de propone una instancia real basada en logística humanitaria, la cual es resuelta con el modelo matemático.\\

Al comparar las soluciones encontradas por el modelo matemático, con las encontradas por la heurística, se observa que esta última encuentra soluciones 13\% peores, sin embargo su tiempo de respuesta es un 98.6\% más rápido. Esto caracteriza a la heurística como un buen método para encontrar soluciones de rápidas.\\

En futuros temas de investigación, se puede analizar la posibilidad de modelar este problema siendo de tipo multi-objetivo, considerando por ejemplo, maximizar la satisfacción de los clientes.
\end{quotation}
\newpage
\pagenumbering{roman}
%\pagenumbering{Roman}
\tableofcontents
\cleardoublepage
\addcontentsline{toc}{chapter}{\'Indice de Figuras} % para que aparezca en el indice de contenidos
\newpage
\listoffigures
\newpage
\cleardoublepage
\addcontentsline{toc}{chapter}{\'Indice de Tablas} % para que aparezca en el indice de contenidos
\listoftables % Genera el Índice de tablas
\newpage

\pagenumbering{arabic}
\chapter{Introducción}
Hola como estas, esto es un test a ver si se pueden inclutir las referencias \cite{varela}
\chapter{Revisión literatura}
%\include{Descripcion_Problema}
\chapter{Modelos matematicos}
\chapter{Heuristica}
\chapter{Resultados}
\chapter{Conclusiones}

\addcontentsline{toc}{chapter}{7.\hspace{0.5cm }Referencias}
\bibliographystyle{IEEEtran}
\bibliography{biblio_MT}


\end{document}

答案1

這個答案顯示了使用類別的最小程式碼report(使用其他類article,例如memoir,,沒有太大不同)。從這個答案基本上可以知道如何:

  1. 建立目錄
  2. 建立參考文獻的引文
  3. 為章節、章節等建立引用。

程式碼(例如main.tex)

\documentclass{report}
\usepackage[backend=bibtex, style=ieee]{biblatex} % using biblatex with style style=ieee
\addbibresource{reference.bib} % file inside which references are stored
\usepackage[hidelinks, colorlinks=true]{hyperref}
\usepackage{cleveref} % optional for adding suitable perfix to citations of chapters, sections, figures ...etc
%
\begin{document}
%
\tableofcontents % Creating table of contents
%
\chapter{Reference and Citation} \label{ch:reference}
%
\section{Introduction} \label{sec:intro}
In order to cite one reference, you can use cite command like this \cite{Doe_2020}. You can also cite two references like this \cite{Doe_2020,Tenis_2000}.
%
\section{Citing previous sections} \label{sec:citing}
This is to show how to cite previous sections. The references can be found in section \ref{sec:intro}.

\section{Using cleveref package} \label{sec:using}
In section \ref{sec:intro}, you had to write "section" before ref command. Using cleveref, you can cite directly like this \cref{sec:intro} and \cref{sec:citing}. You can even cite two sections directly like this \cref{sec:intro,sec:citing} or even multiple sections in the same time like this \cref{sec:intro,sec:citing,sec:using}.

The same apply for chapters and figures. For example, the first chapter can be cited like this \cref{ch:reference}.

\printbibliography % list of references is printed here
\end{document}

\label{something}正如您所看到的,引用章節、章節,甚至圖表等,與在每個章節、章節之後創建我們稍後要引用的內容有關。然後,在您想要新增引用的地方,您只需使用命令\ref{something}或更高級的\cref{something}.

章節是透過該命令添加的\chapter{name of chapter},並且它們會與章節一起自動引用到目錄中文件中所需位置的命令\tableofcontents,通常位於報告標題之後的開頭。

對於此處解釋的範例,您應該bib在同一工作資料夾中建立一個文件,其中包含reference.bib使用以下內容呼叫的 tex 文件

@Book{Doe_2020,
  author    = {John Doe},
  publisher = {John Wiley},
  title     = {Differential equations : an introduction to modern methods and applications},
  year      = {2020},
  address   = {New Jersey},
  isbn      = {9780471651413},
  keywords  = {Differential equations},
  language  = {In English},
}

@Article{Tenis_2000,
  author  = {Michael Tenis},
  journal = {Jounal of Energy},
  title   = {New article about something},
  year    = {2000},
  month   = aug,
  number  = {7},
  pages   = {66--88},
  volume  = {2},
}

如上所示,對於透過命令在主tex檔案中使用的引用參考文獻或(參考書目)\cite{ref-key},您需要先建立一個單獨的bib文件,其中包含要新增至報告中的所需參考文獻清單。請注意,您可以新增多種類型的參考文獻(例如書籍、文章、會議等),每種參考文獻都有正確的類型格式。一些書目管理器可以幫助您建立書目文件(例如賈布參考)。

編譯得到的輸出是這樣的

在此輸入影像描述 在此輸入影像描述 在此輸入影像描述
