我是一個新的 LaTeX 用戶，也是這個 Stack Exchange 的新手，所以請放輕鬆！
我的使用手冊有大量邊界框問題，因為目前 2.9 版本的 MiKTeX (basic-miktex-2.9.7386-x64.exe) 似乎比編寫 LaTeX 程式碼的舊版 MiKTeX 2.1 更嚴格。
我找到了一組應該可以使其工作的說明，但它仍然不適合我。以下是說明：
以下是複製 MikTex 2.1 設定的過程。
1) 將 \[...Network_Location...]\LATEX\MiKTeX 2.1\texmf.zip 中的 zip 檔案複製
到本機 PC。2) 將其解壓縮到根層級的啟動磁碟機（C: 而非 C:\texm）。
如果您提取到 c:\texmf，您將創建一個額外的級別，並且 MikTex 將無法按照當前配置正常運作。
3）新增路徑規範：
c:\texmf\miktex\bin to the Windows PATH environmental variable.打開 CMD 視窗並驗證您可以啟動 Latex 應用程式：
D:\PAWSUA_UG2_5>latex 這是 TeX，版本 3.14159 (MiKTeX 2.1) **
現在您應該能夠編譯並產生具有正確大小圖像的 PDF 檔案。
當我按照上述指示操作時，它位於目前 MiKTeX 2.9 安裝之上。
我已遵循所有指示，包括驗證 Latex 是否運行並顯示版本 2.1。
然後我嘗試使用 TeXworks，但圖像仍然混亂。我甚至直接從 LaTeX 2.1 命令列介面產生了 .DVI。兩個版本之間似乎有一些互動！
我真的仍然想在 TeXworks 中工作，只是不知道它是否可以與舊版本 2.1 而不是當前的 2.9 一起工作。是否可以？我不想根據較新的 2.9 版本重新格式化整個數百頁的手冊。幫助！
編輯：這是一些原始程式碼和日誌文件，可幫助診斷和取得幫助。
在向您展示程式碼中的邊界框問題之前，我必須向您展示我在生成的 PDF 中直觀地體驗到的情況。下面是 MiKTeX 2.9 中左側表現不佳的圖片與 MiKTeX 2.1 中渲染的右側圖片（由其他人提供）的並排比較。圖片已被稍微模糊和/或遮擋（用灰色矩形），以防止洩露任何專有資訊。
我希望這可以清楚地表明我在邊界框方面遇到了問題。也許它們之前被鬆散地指定，並且在某個時候，什麼“邊界框”會接受被收緊和“糾正”？無論如何，真正的問題不是邊界框問題，真正的問題是如何成功地使用舊版本，而不會讓公司在「更新內容」方面付出太多成本。
這是第一個邊界框問題：
\begin{figure}[!hbt]
\begin{center}
\includegraphics[bb = 0.00in 0.0in 6.0in 7.5in,
width=0.95\textwidth,keepaspectratio,clip, trim = 0 0 0
230,scale=1.5]{PAWS_RunScreen.jpg}
\caption{Run Screen}
\label{fig:runscreen}
\end{center}
\end{figure}
及其日誌訊息：
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 481.
<PAWS_RunScreen.jpg, id=62, 832.61063pt x 565.36218pt>
File: PAWS_RunScreen.jpg Graphic file (type jpg)
<use PAWS_RunScreen.jpg>
Package pdftex.def Info: PAWS_RunScreen.jpg used on input line 481.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[10 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_RunScreen.jpg>]
和第二個邊界框錯誤：
\vspace{0.70in}
\begin{figure}[!hbt]
\begin{center}
\includegraphics[bb = 0.00in 0.0in 6.0in 7.5in,
width=0.95\textwidth,keepaspectratio,clip, trim = 0 0 0
230,scale=2.3]{PAWS_RunSetupScreen.jpg}
\vspace{-1.2in}
\caption{Run Setup Screen}
\label{runsetup}
\end{center}
\end{figure}
及其日誌訊息：
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 515.
<PAWS_RunSetupScreen.jpg, id=68, 578.16pt x 462.22687pt>
File: PAWS_RunSetupScreen.jpg Graphic file (type jpg)
<use PAWS_RunSetupScreen.jpg>
Package pdftex.def Info: PAWS_RunSetupScreen.jpg used on input line 515.
(pdftex.def) Requested size: 1329.7665pt x 532.13614pt.
和第三個邊界框錯誤：
\vspace{0.05in}
\begin{figure}
\begin{center}
\includegraphics[bb = 0.00in 0.0in 6.0in 7.5in,
width=0.95\textwidth,keepaspectratio,clip, trim = 0 0 0
230,scale=1.5]{PAWS_MethodScreen.jpg}
\caption{Method Editor Screen}
\label{fig:me}
\end{center}
\end{figure}
\vspace{-0.3in}
及其相關的日誌訊息：
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 581.
<PAWS_MethodScreen.jpg, id=78, 832.61063pt x 565.36218pt>
File: PAWS_MethodScreen.jpg Graphic file (type jpg)
<use PAWS_MethodScreen.jpg>
Package pdftex.def Info: PAWS_MethodScreen.jpg used on input line 581.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
日誌檔案有很多這種模式，我必須刪除它們以使其適合：
Overfull \hbox (4.27394pt too wide) in paragraph at lines 561--562
[][]
[]
以下是從 TeXworks 產生 PDF 產生的最完整的日誌文件，經過修改以使其適合：
This is pdfTeX, Version 3.1415926-2.4-1.40.13 (MiKTeX 2.9)
(preloaded format=pdflatex 2019.6.4) 27 APR 2020 13:48
entering extended mode
**C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/pawsua_ug2_5.tex
(C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/pawsua_ug2_5.tex
LaTeX2e <2011/06/27>
Babel <v3.8m> and hyphenation patterns for english, ..., welsh, loaded.
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\specification.cls
Document Class: specification 2001/12/20 v1.4 Custom LaTeX document class
\@sbcurrent=\count79
(C:\MikTeX\tex\latex\base\size11.clo
File: size11.clo 2007/10/19 v1.4h Standard LaTeX file (size option)
)
\tempa=\dimen102
\c@part=\count80
\c@Section=\count81
\c@section=\count82
\c@sectionpage=\count83
\c@subsection=\count84
\c@subsubsection=\count85
\c@paragraph=\count86
\c@subparagraph=\count87
\c@table=\count88
\c@figure=\count89
\headrulewidth=\dimen103
\footrulewidth=\dimen104
\headwidth=\dimen105
\EpsFig=\box26
)
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\testplan.sty)
(C:\MikTeX\tex\latex\graphics\graphicx.sty
Package: graphicx 1999/02/16 v1.0f Enhanced LaTeX Graphics (DPC,SPQR)
(C:\MikTeX\tex\latex\graphics\keyval.sty
Package: keyval 1999/03/16 v1.13 key=value parser (DPC)
\KV@toks@=\toks14
)
(C:\MikTeX\tex\latex\graphics\graphics.sty
Package: graphics 2009/02/05 v1.0o Standard LaTeX Graphics (DPC,SPQR)
(C:\MikTeX\tex\latex\graphics\trig.sty
Package: trig 1999/03/16 v1.09 sin cos tan (DPC)
)
(C:\MikTeX\tex\latex\00miktex\graphics.cfg
File: graphics.cfg 2007/01/18 v1.5 graphics configuration of teTeX/TeXLive
)
Package graphics Info: Driver file: pdftex.def on input line 91.
(C:\MikTeX\tex\latex\pdftex-def\pdftex.def
File: pdftex.def 2011/05/27 v0.06d Graphics/color for pdfTeX
(C:\MikTeX\tex\generic\oberdiek\infwarerr.sty
Package: infwarerr 2010/04/08 v1.3 Providing info/warning/error messages (HO)
)
(C:\MikTeX\tex\generic\oberdiek\ltxcmds.sty
Package: ltxcmds 2011/11/09 v1.22 LaTeX kernel commands for general use (HO)
)
\Gread@gobject=\count90
))
\Gin@req@height=\dimen106
\Gin@req@width=\dimen107
)
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\rotating.sty
Package: rotating 1997/09/26, v2.13 Rotation package
(C:\MikTeX\tex\latex\base\ifthen.sty
Package: ifthen 2001/05/26 v1.1c Standard LaTeX ifthen package (DPC)
)
\c@r@tfl@t=\count91
\rot@float@box=\box27
)
(C:\MikTeX\tex\latex\multirow\multirow.sty
\bigstrutjot=\dimen108
)
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\comment.sty
\CommentStream=\write3
Excluding comment 'comment') (C:\MikTeX\tex\latex\tools\tabularx.sty
Package: tabularx 1999/01/07 v2.07 `tabularx' package (DPC)
(C:\MikTeX\tex\latex\tools\array.sty
Package: array 2008/09/09 v2.4c Tabular extension package (FMi)
\col@sep=\dimen109
\extrarowheight=\dimen110
\NC@list=\toks15
\extratabsurround=\skip41
\backup@length=\skip42
)
\TX@col@width=\dimen111
\TX@old@table=\dimen112
\TX@old@col=\dimen113
\TX@target=\dimen114
\TX@delta=\dimen115
\TX@cols=\count92
\TX@ftn=\toks16
) (C:\MikTeX\tex\latex\graphics\lscape.sty
Package: lscape 2000/10/22 v3.01 Landscape Pages (DPC)
) (C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.aux)
LaTeX Font Info: Checking defaults for OML/cmm/m/it on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for T1/cmr/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for OT1/cmr/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for OMS/cmsy/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for OMX/cmex/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: Checking defaults for U/cmr/m/n on input line 32.
LaTeX Font Info: ... okay on input line 32.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <12> on input line 72.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <8> on input line 72.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <6> on input line 72.
LaTeX Font Info: Try loading font information for OMS+cmr on input line 72.
(C:\MikTeX\tex\latex\base\omscmr.fd
File: omscmr.fd 1999/05/25 v2.5h Standard LaTeX font definitions
)
LaTeX Font Info: Font shape `OMS/cmr/m/n' in size <9> not available
(Font) Font shape `OMS/cmsy/m/n' tried instead on line 72.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <9> on input line 72.
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <5> on input line 72.
[1
{C:/Users/dev/AppData/Local/MiKTeX/2.9/pdftex/config/pdftex.map}]
LaTeX Font Info: Font shape `OMS/cmr/m/n' in size <10> not available
(Font) Font shape `OMS/cmsy/m/n' tried instead on line 74.
[2
]
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.toc
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <10.95> on input line 2.
[1
] [2])
\tf@toc=\write4
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.lot)
\tf@lot=\write5
(C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.lof [3])
\tf@lof=\write6
[4]
[1
]
2: Station Overview
[4]
LaTeX Font Info: Font shape `OMS/cmr/m/n' in size <10.95> not available
(Font) Font shape `OMS/cmsy/m/n' tried instead on line 270.
[5] [6]
[9]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 481.
<PAWS_RunScreen.jpg, id=62, 832.61063pt x 565.36218pt>
File: PAWS_RunScreen.jpg Graphic file (type jpg)
<use PAWS_RunScreen.jpg>
Package pdftex.def Info: PAWS_RunScreen.jpg used on input line 481.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[10 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_RunScreen.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 515.
<PAWS_RunSetupScreen.jpg, id=68, 578.16pt x 462.22687pt>
File: PAWS_RunSetupScreen.jpg Graphic file (type jpg)
<use PAWS_RunSetupScreen.jpg>
Package pdftex.def Info: PAWS_RunSetupScreen.jpg used on input line 515.
(pdftex.def) Requested size: 1329.7665pt x 532.13614pt.
[12]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 581.
<PAWS_MethodScreen.jpg, id=78, 832.61063pt x 565.36218pt>
File: PAWS_MethodScreen.jpg Graphic file (type jpg)
<use PAWS_MethodScreen.jpg>
Package pdftex.def Info: PAWS_MethodScreen.jpg used on input line 581.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[13
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_MethodScreen.jpg>]
[14] [15]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 697.
<PAWS_ProductScreen_VelocityLength.jpg, id=91, 832.61063pt x 565.36218pt>
File: PAWS_ProductScreen_VelocityLength.jpg Graphic file (type jpg)
<use PAWS_ProductScreen_VelocityLength.jpg>
Package pdftex.def Info: PAWS_ProductScreen_VelocityLength.jpg used on input li
ne 697.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[16
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_ProductScreen_VelocityLength.jpg
>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 836.
<PAWS_ProductScreen_VelocityMotion.jpg, id=103, 832.61063pt x 565.36218pt>
File: PAWS_ProductScreen_VelocityMotion.jpg Graphic file (type jpg)
<use PAWS_ProductScreen_VelocityMotion.jpg>
Package pdftex.def Info: PAWS_ProductScreen_VelocityMotion.jpg used on input li
ne 836.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 881.
<PAWS_ProductScreen_Force.jpg, id=105, 832.61063pt x 565.36218pt>
File: PAWS_ProductScreen_Force.jpg Graphic file (type jpg)
<use PAWS_ProductScreen_Force.jpg>
Package pdftex.def Info: PAWS_ProductScreen_Force.jpg used on input line 881.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[19] [20 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_ProductScreen_VelocityM
otion.jpg>] [21 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_ProductScreen_For
ce.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 907.
<PAWS_DataScreen.jpg, id=119, 832.61063pt x 565.36218pt>
File: PAWS_DataScreen.jpg Graphic file (type jpg)
<use PAWS_DataScreen.jpg>
Package pdftex.def Info: PAWS_DataScreen.jpg used on input line 907.
(pdftex.def) Requested size: -1174.89139pt x -1442.13919pt.
[22
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_DataScreen.jpg>]
[25]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 1040.
<PAWS_CalibrationScreen.jpg, id=135, 832.61063pt x 565.36218pt>
File: PAWS_CalibrationScreen.jpg Graphic file (type jpg)
<use PAWS_CalibrationScreen.jpg>
Package pdftex.def Info: PAWS_CalibrationScreen.jpg used on input line 1040.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[26
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_CalibrationScreen.jpg>]
[27]
Missing character: There is no ’ in font cmti10!
[28]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 1149.
<PAWS_UtilitiesScreen.jpg, id=148, 832.61063pt x 565.36218pt>
File: PAWS_UtilitiesScreen.jpg Graphic file (type jpg)
<use PAWS_UtilitiesScreen.jpg>
Package pdftex.def Info: PAWS_UtilitiesScreen.jpg used on input line 1149.
(pdftex.def) Requested size: 1248.91289pt x 501.74745pt.
[29
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_UtilitiesScreen.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 1167.
<PAWS_DiagnosticsScreen.jpg, id=154, 578.16pt x 462.22687pt>
File: PAWS_DiagnosticsScreen.jpg Graphic file (type jpg)
<use PAWS_DiagnosticsScreen.jpg>
Package pdftex.def Info: PAWS_DiagnosticsScreen.jpg used on input line 1167.
(pdftex.def) Requested size: 867.23787pt x 347.04485pt.
[30
<C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_DiagnosticsScreen.jpg>]
[31
]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1229.
<MT_SAG285_BalanceScreen.jpg, id=164, 786.94pt x 468.75125pt>
File: MT_SAG285_BalanceScreen.jpg Graphic file (type jpg)
<use MT_SAG285_BalanceScreen.jpg>
Package pdftex.def Info: MT_SAG285_BalanceScreen.jpg used on line 1229.
(pdftex.def) Requested size: 1180.40712pt x 356.83138pt.
[32 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/MT_SAG285_BalanceScreen.jpg>]
[33
]
LaTeX Font Info: External font `cmex10' loaded for size
(Font) <7> on input line 1253.
LaTeX Warning: Float too large for page by 37.16692pt on line 1296.
[34]
Missing character: There is no – in font cmr10!
[35
]
Overfull \hbox (8.62225pt too wide) in parag @ lines 1366--1373
\OT1/cmr/m/n/10.95 Run re-ports can be re-viewed/approved by
se-lect-ing the \O T1/cmr/bx/n/10.95 Mark as Re-viewed/Approved
[]
[36
] [37]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) - using `viewport' instead on line 1411.
<PAWS_reviewscreen.jpg, id=186, 452.4403pt x 328.22626pt>
File: PAWS_reviewscreen.jpg Graphic file (type jpg)
<use PAWS_reviewscreen.jpg>
Package pdftex.def Info: PAWS_reviewscreen.jpg used on input line 1411.
(pdftex.def) Requested size: 678.65881pt x 146.04442pt.
[38 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_reviewscreen.jpg>]
[39] [40
] [41] [42] [43]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1583.
<PAWS_methodrpt2.jpg, id=208, 1946.02031pt x 1219.55624pt>
File: PAWS_methodrpt2.jpg Graphic file (type jpg)
<use PAWS_methodrpt2.jpg>
Package pdftex.def Info: PAWS_methodrpt2.jpg used on input line 1583.
(pdftex.def) Requested size: 486.50389pt x 247.17268pt.
[44 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_methodrpt2.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1602.
<PAWS_productrpt.jpg, id=214, 434.37282pt x 556.32843pt>
File: PAWS_productrpt.jpg Graphic file (type jpg)
<use PAWS_productrpt.jpg>
Package pdftex.def Info: PAWS_productrpt.jpg used on input line 1602.
(pdftex.def) Requested size: 651.55762pt x 488.19685pt.
[45]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1622.
<PAWS_calhistoryrpt.jpg, id=219, 437.38406pt x 336.50719pt>
File: PAWS_calhistoryrpt.jpg Graphic file (type jpg)
<use PAWS_calhistoryrpt.jpg>
Package pdftex.def Info: PAWS_calhistoryrpt.jpg used on line 1622.
(pdftex.def) Requested size: 656.07446pt x 158.46579pt.
[46 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_productrpt.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1638.
<PAWS_curcalrpt.jpg, id=225, 435.12563pt x 519.44063pt>
File: PAWS_curcalrpt.jpg Graphic file (type jpg)
<use PAWS_curcalrpt.jpg>
Package pdftex.def Info: PAWS_curcalrpt.jpg used on input line 1638.
(pdftex.def) Requested size: 652.68683pt x 432.86528pt.
[47 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_calhistoryrpt.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1657.
<PAWS_runrptp1.jpg, id=231, 438.13687pt x 551.81157pt>
File: PAWS_runrptp1.jpg Graphic file (type jpg)
<use PAWS_runrptp1.jpg>
Package pdftex.def Info: PAWS_runrptp1.jpg used on input line 1657.
(pdftex.def) Requested size: 657.20367pt x 481.42159pt.
[48 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_curcalrpt.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1671.
<PAWS_runrptp2.jpg, id=237, 391.4625pt x 552.56438pt>
File: PAWS_runrptp2.jpg Graphic file (type jpg)
<use PAWS_runrptp2.jpg>
Package pdftex.def Info: PAWS_runrptp2.jpg used on input line 1671.
(pdftex.def) Requested size: 587.19229pt x 482.55077pt.
[49 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_runrptp1.jpg>]
Package pdftex.def Warning: Option `bb' does not make sense,
(pdftex.def) using `viewport' instead on line 1684.
<PAWS_runrptp3.jpg, id=244, 403.5075pt x 551.05875pt>
File: PAWS_runrptp3.jpg Graphic file (type jpg)
<use PAWS_runrptp3.jpg>
Package pdftex.def Info: PAWS_runrptp3.jpg used on input line 1684.
(pdftex.def) Requested size: 605.25977pt x 480.29234pt.
[50 <C:/VIDEOS_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_runrptp2.jpg>] [51 <C:/VIDEOS
_DESKTOP_CAPTURES/PAWSUA_UG2_5/PAWS_runrptp3.jpg>]
F: Service
Underfull \hbox (badness 10000) in parag @ lines 1711--1720
[]
Underfull \hbox (badness 10000) in parag @ lines 1711--1720
[]
Underfull \hbox (badness 10000) in parag @ lines 1711--1720
[]
[52
] [53] (C:\VIDEOS_DESKTOP_CAPTURES\PAWSUA_UG2_5\pawsua_ug2_5.aux) )
Here is how much of TeX's memory you used:
1399 strings out of 493921
18919 string characters out of 3154507
80525 words of memory out of 3000000
4673 multiletter control sequences out of 15000+200000
11650 words of font info for 40 fonts, out of 3000000 for 9000
841 hyphenation exceptions out of 8191
29i,15n,29p,442b,310s stack positions out of 5000i,500n,10000p,200000b,50000s
<C:/MikTeX/f
onts/type1/public/amsfonts/cm/cmbx10.pfb><C:/MikTeX/fonts/type1/public/amsfonts
/cm/cmbx12.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmcsc10.pfb><C:/MikTeX
/fonts/type1/public/amsfonts/cm/cmmi10.pfb><C:/MikTeX/fonts/type1/public/amsfon
ts/cm/cmmi6.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmmi9.pfb><C:/MikTeX/
fonts/type1/public/amsfonts/cm/cmr10.pfb><C:/MikTeX/fonts/type1/public/amsfonts
/cm/cmr12.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmr17.pfb><C:/MikTeX/fo
nts/type1/public/amsfonts/cm/cmr6.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm
/cmr9.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmsl12.pfb><C:/MikTeX/fonts
/type1/public/amsfonts/cm/cmsy10.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/
cmsy9.pfb><C:/MikTeX/fonts/type1/public/amsfonts/cm/cmti10.pfb>
Output written on pawsua_ug2_5.pdf (59 pages, 2500488 bytes).
PDF statistics:
309 PDF objects out of 1000 (max. 8388607)
0 named destinations out of 1000 (max. 500000)
210 words of extra memory for PDF output out of 10000 (max. 10000000)
