\盒裝文字作為下標

\盒裝文字作為下標

我們已經將\boxed內容設定為下標,

在此輸入影像描述

但下標大小未更新,請建議如何使用\boxed定義設定腳本大小。

請找到MWE檔案:

\documentclass{book}
\usepackage{amsmath}


\makeatletter
\renewcommand{\boxed}[1]{\fboxsep1pt\arraycolsep1pt\fbox{\m@th$#1$}}
\makeatother

\begin{document}

the passenger moving with a velocity of +11 m/s, due in part to the walking motion and in part to the train's motion. As  $\boxed{\begin{array}{c}
{PT}\\
{AT}\\
{CT}\\
\end{array}}$ the passenger moving with a velocity of +11 m/s, due in part to the walking motion and in part to the train's motion. As

$$\vec{\mathbf{V}}_{\boxed{\begin{array}{c}
{PT}\\
{AT}\\
{CT}\\
\end{array}}}$$

\end{document}

答案1

使用 TABstacks 的方法:

\documentclass{book}
\usepackage{amsmath,scalerel,tabstackengine}
\TABstackMath
\TABstackMathstyle{\SavedStyle}

\renewcommand{\boxed}[1]{\ThisStyle{\fboxsep1pt\fbox{%
  \setstackgap{L}{12\LMpt}\tabbedCenterstack{#1}}}}

\begin{document}

the passenger moving with a velocity of +11 m/s, due in part to the walking
motion and in part to the train's motion. As  $\boxed{PT\\AT\\CT}$ the
passenger moving with a velocity of +11 m/s, due in part to the walking
motion and in part to the train's motion. As
\[
\vec{\mathbf{V}}_{\boxed{PT\\AT\\CT}}
\]
\end{document}

在此輸入影像描述

答案2

您可以使用\textfrom amsmath,但您需要在基線方面提供協助。

\documentclass{book}
\usepackage{amsmath}
\usepackage{array}
\usepackage{siunitx}

\sisetup{retain-explicit-plus}

\makeatletter
\newcommand{\boxedarray}[2][c]{%
  \begingroup
  \let\current@f@size\f@size
  \setlength\fboxsep{1pt}%
  \text{\fbox{\fix@baseline$\begin{array}[#1]{c}#2\end{array}$}}%
  \endgroup
}
\newcommand{\fixbaseline}{%
  \ifx\f@size\current@f@size\else\ifx\f@size\sf@size\linespread{0.7}\else\linespread{0.5}\fi\fi
  \selectfont
}
\makeatother

\begin{document}

The passenger moving with a velocity of \SI{+11}{m/s}, due in part to the
walking motion and in part to the train's motion. As
$\boxedarray{ PT \\ AT \\ CT }$
the passenger moving with a velocity of \SI{+11}{m/s}, due in part to the
walking motion and in part to the train's motion. As
\[
\vec{\mathbf{V}}_{\boxedarray{ PT \\ AT \\ CT }}
\]

\end{document}

對於單位,正如已經建議的那樣,使用siunitx設施。

在此輸入影像描述

答案3

我提出了一個非常簡單的\subboxed命令,它確保數學將在 \scriptstyle 中並且 的值\boxsep被調整。在正文中,我只需使用盒裝\Vectorstackstackengine.

與問題無關:我使用了 中的可擴展向量箭頭,它看起來比粗體 V esvec更好。\vec

\documentclass{book}
\usepackage{amsmath}
\usepackage{siunitx}
\usepackage[b]{esvect}
\usepackage[usestackEOL]{stackengine}

\newcommand{\subboxed}[1]{{\setlength{\fboxsep}{1pt}\boxed{\everymath{\scriptstyle}#1}}}

\begin{document}

The passenger moving with a velocity of \SI{+11}{\meter/\second}, due in part to the walking
motion and in part to the train's motion. As $\boxed{\Vectorstack{PT \\ AT \\ CT}}$ the passenger moving with a velocity of \SI{+11}{\meter/\second},
due in part to the walking motion and in part to the train's motion. As
\[\vv{\mathbf{V}}_{\subboxed{\substack{PT\\ AT \\ CT}}}
\]

\end{document}

在此輸入影像描述

答案4

這可能太天真了,但您不需要任何複雜的\makeatletter東西來裝箱數組。

\documentclass{book}
\usepackage{amsmath}
\usepackage{siunitx}

\begin{document}

The passenger moving with a velocity of \SI{+11}{\meter/\second}, due in part to the walking
motion and in part to the train's motion.  As  $\begin{array}{|@{\,}c@{\,}|}
\hline
{PT}\\
{AT}\\
{CT}\\
\hline
\end{array}$ the passenger moving with a velocity of \SI{+11}{\meter/\second},
due in part to the walking motion and in part to the train's motion. As
\[\vec{\mathbf{V}}_{\begin{array}{|@{\,}c@{\,}|}
\hline
{PT}\\
{AT}\\
{CT}\\
\hline
\end{array}}\]

\end{document}

在此輸入影像描述

當然,問題是讀者是否想要這樣的盒子。 (至少我添加siunitx並替換$$ ... $$\[ ... \]所以這可能不是完全沒有意義的。)
