多個 \pic 物件的水平對齊

Question

pic我想將一些 tikz 繪圖分組在一起，並為此使用 a 。我還希望像使用普通節點一樣使用這些圖片，並繪製一些連接箭頭。如何沿著邊界框的中心水平對齊圖片？我想避免指定數字座標。我的程式碼的精簡版本如下。

看來指定right = of X將圖片的邊界框(0,0)座標放在該點，但我寧願(0, 0.5 * bounding box height)在該點放置。我嘗試添加一些anchor選項，但這似乎沒有任何效果——我猜圖片定位時不知道圖片邊界框的大小。

\documentclass[tikz,border=5mm]{standalone}
\usetikzlibrary{positioning}
\begin{document}
\begin{tikzpicture}[
    inner sep=0mm,
    stack/.pic={
        \foreach \i in {#1}
            \draw [pic actions] (0+\i,0+\i) rectangle (1+\i,1+\i);
    },
    squares/.style={
        black,
        fill=orange!75,
    },
    edge/.style={
        ->,
        black,
        ultra thick,
        shorten <=1mm,
        shorten >=1mm,
    },
]
\pic [
    squares,
    local bounding box=A,
] {stack={0,0.2,...,1}};
\pic [
    squares,
    local bounding box=B,
    scale=0.5,
    right= of A,
] {stack={0,0.2,...,1}};
\pic [
    squares,
    local bounding box=C,
    scale=0.25,
    right= of B,
] {stack={0,0.2,...,1}};
\draw [edge] (A) -- (B);
\draw [edge] (B) -- (C);
\end{tikzpicture}
\end{document}

Answer 1

如果您需要在繪製某物之前計算其大小，則需要使用保存箱。要嘛這樣，要嘛畫兩次。

使用保存箱時請注意替換[tikz]為。\usepackage{tikz}

\documentclass[border=5mm]{standalone}
\usepackage{tikz}
\usetikzlibrary{positioning}

\newsavebox{\boxa}
\newsavebox{\boxb}
\newsavebox{\boxc}

\begin{document}

\savebox{\boxa}{\begin{tikzpicture}[
    inner sep=0mm,
    stack/.pic={
        \foreach \i in {#1}
            \draw [pic actions] (0+\i,0+\i) rectangle (1+\i,1+\i);
    },
    squares/.style={
        black,
        fill=orange!75,
    },
]
\pic [
    squares,
] {stack={0,0.2,...,1}};
\end{tikzpicture}}%
\savebox{\boxb}{\begin{tikzpicture}[
    inner sep=0mm,
    stack/.pic={
        \foreach \i in {#1}
            \draw [pic actions] (0+\i,0+\i) rectangle (1+\i,1+\i);
    },
    squares/.style={
        black,
        fill=orange!75,
    },
]
\pic [
    squares,
    scale=0.5,
] {stack={0,0.2,...,1}};
\end{tikzpicture}}%
\savebox{\boxc}{\begin{tikzpicture}[
    inner sep=0mm,
    stack/.pic={
        \foreach \i in {#1}
            \draw [pic actions] (0+\i,0+\i) rectangle (1+\i,1+\i);
    },
    squares/.style={
        black,
        fill=orange!75,
    },
]
\pic [
    squares,
    scale=0.25,
] {stack={0,0.2,...,1}};
\end{tikzpicture}}%
\begin{tikzpicture}[
    inner sep=0mm,
    edge/.style={
        ->,
        black,
        ultra thick,
        shorten <=1mm,
        shorten >=1mm,
    },
]
\node (A) {\usebox\boxa};
\node[right=of A] (B) {\usebox\boxb};
\node[right=of B] (C) {\usebox\boxc};

\draw [edge] (A) -- (B);
\draw [edge] (B) -- (C);
\end{tikzpicture}
\end{document}

Answer 2

事實證明，人們可以將 tikz 繪圖（\tikz \pic ...在本例中）放置在 .txt 檔案的「文字」部分內\node。也許 tikz 已經將節點的文本內容保存到一個框中（否則 tikz 如何知道如何將節點錨定在其中心？），所以我們可以重複使用它以避免做我們自己的\savebox舞蹈。

\documentclass[tikz,border=1mm]{standalone}
\usetikzlibrary{positioning}
\begin{document}
\begin{tikzpicture}[
    inner sep=0mm,
    stack/.pic={
        \foreach \i in {#1}
            \draw [pic actions] (0+\i,0+\i) rectangle (1+\i,1+\i);
    },
    squares/.style={
        fill=orange!75,
    },
    edge/.style={
        ->,
        ultra thick,
        shorten <=1mm,
        shorten >=1mm,
    },
]

\node (A) { \tikz \pic[squares] {stack={0,0.2,...,1}}; };
\node [right=of A] (B) { \tikz \pic[squares, scale=0.5] {stack={0,0.2,...,1}}; };
\node [right=of B] (C) { \tikz \pic[squares, scale=0.25] {stack={0,0.2,...,1}}; };
\draw [edge] (A) -- (B);
\draw [edge] (B) -- (C);
\end{tikzpicture}
\end{document}
