智慧圖水平流程圖

Question

我想將我的 DT 區塊連接到下圖中的 LL

下面的程式碼是：

\begin{center}
\begin{figure}


\smartdiagramset{set color list={blue!10, blue!30,blue!50},back arrow disabled=true,
additions={
additional item offset=0.4cm,
additional arrow color=blue!30,
additional arrow tip=stealth,
additional arrow line width=1pt,
additional item border color=gray,
additional item shape=rounded corners,
additional item bottom color=blue!30,
additional item shadow=drop shadow
}
}
\smartdiagramadd[flow diagram:horizontal]{WRA, LL, CM}{
above of module2/DT
}
%\smartdiagramconnect{->}{module2/additional-module2n}
\end{figure}
\end{center

}

但是，當我嘗試將新區塊連接到模組 2 時，出現錯誤。聲明“additional-module2”未知。有什麼提示嗎？

Answer 1

編輯： 您的問題可以透過兩種方式解決：

• 新增到additions程式碼行additional connections disabled=false,：
• 或在圖表代碼中添加\smartdiagramconnect{to-}{module2/additional-module1}

第一個例子：

\documentclass[rgb]{article}
\usepackage{smartdiagram}
\usesmartdiagramlibrary{additions}

\begin{document}
    \begin{figure}
    \centering
\smartdiagramset{set color list={blue!10, blue!30,blue!50},back arrow disabled=true,
additions={
additional item offset=0.4cm,
additional connections disabled=false,  % NEW
additional arrow color=red,             % changed color ...
additional arrow tip=stealth,
additional arrow line width=2pt,        % changed thickness
additional item border color=gray,
additional item shape=rounded corners,
additional item bottom color=blue!30,
additional item shadow=drop shadow
}
}
\smartdiagramadd[flow diagram:horizontal]%
    {WRA, LL, CM}%
    {above of module2/EDT}
%
\caption{Smart diagram}
\label{fig:smartdiagram}
    \end{figure}
\end{document}

第二種情況：

\documentclass[rgb]{article}
\usepackage{smartdiagram}
\usesmartdiagramlibrary{additions}

\begin{document}
    \begin{figure}
    \centering
\smartdiagramset{set color list={blue!10, blue!30,blue!50},back arrow disabled=true,
additions={
additional item offset=0.4cm,
additional arrow color=red,             % changed color ...
additional arrow tip=stealth,
additional arrow line width=2pt,        % changed thickness
additional item border color=gray,
additional item shape=rounded corners,
additional item bottom color=blue!30,
additional item shadow=drop shadow
}
}
\smartdiagramadd[flow diagram:horizontal]%
    {WRA, LL, CM}%
    {above of module2/EDT}
\smartdiagramconnect{to-}{module2/additional-module1}
%
\caption{Smart diagram}
\label{fig:smartdiagram}
    \end{figure}
\end{document}

在這兩種情況下，結果是相同的：
