使用森林樹和 pgfplots 將節點顏色和節點形狀新增至 tikz-picture 中的圖例

Question

我想將樹的元素新增到圖例中（有關說明，請參閱圖例）。我發現這和這答案，但他們沒有解釋如何為圖例添加其他形狀。我在 pgfplots-docs 中沒有找到任何有用的東西。我不限於圖例的 pgfplots，如果您有其他解決方案，我將很樂意使用它。

\documentclass{standalone}
\usepackage[dvipsnames,fixpdftex]{xcolor}
\usepackage{forest}
\usetikzlibrary{calc,shadings}

\usepackage{pgfplots}
\pgfplotsset{compat=1.15}

% Code from Christian Feuersänger
% https://tex.stackexchange.com/questions/54794/using-a-pgfplots-style-legend-in-a-plain-old-tikzpicture#54834

% argument #1: any options
\newenvironment{customlegend}[1][]{%
    \begingroup
    % inits/clears the lists (which might be populated from previous
    % axes):
    \csname pgfplots@init@cleared@structures\endcsname
    \pgfplotsset{#1}%
}{%
    % draws the legend:
    \csname pgfplots@createlegend\endcsname
    \endgroup
}%

% makes \addlegendimage available (typically only available within an
% axis environment):
\def\addlegendimage{\csname pgfplots@addlegendimage\endcsname}

%%--------------------------------

% definition to insert numbers
\pgfkeys{/pgfplots/number in legend/.style={%
        /pgfplots/legend image code/.code={%
            \node at (0.295,-0.0225){#1};
        },%
    },
}
\begin{document}

\begin{forest}
for tree={circle,draw,minimum size = 2.25em, l sep=15pt, s sep=3.0em}
[0, fill=Apricot
    [1, fill=SpringGreen, shape=diamond, for tree={s sep = 3.0em}
      [$\dots$, draw=none]
    ]
    [2, fill=SpringGreen, shape=star, for tree={s sep = 3.0em}
      [$\dots$, draw=none]
      [8]
    ]
    [3, fill=SpringGreen, shape=diamond
      [$\dots$, draw=none]
    ]
    [4, fill=Apricot
      [$\dots$, draw=none]
    ]
    [5, fill=SpringGreen, shape=regular polygon
      [$\dots$, draw=none]
    ]
]
\begin{customlegend}[
  legend entries={ % <= in the following there are the entries
  Green circle/node here,
  Red circle/node here,
  White Star here,
  White Diamond here,
  White Polygon here
  },
  legend style={at={(4.5,3.5)},font=\footnotesize}] % <= to define position and font legend
  % the following are the "images" and numbers in the legend
      \addlegendimage{mark=ball,ball color=SpringGreen, draw=white}
      \addlegendimage{mark=ball,ball color=Apricot, draw=white}
      \addlegendimage{stealth-stealth,red,opacity=0.4}
      \addlegendimage{number in legend=1,blue}
      \addlegendimage{number in legend=0,red}
  \end{customlegend}
\end{forest}

\end{document}

Answer 1

您可以在圖例中新增與目前樣式類似的形狀樣式number in legend，例如稱為shape in legend。可以使用 定義形狀的樣式以接受兩個參數：形狀和顏色.style 2 args。這被稱為shape in legend={arg1}{arg2}（參見如何使用 pgfplots 繪製來自多個過濾器的數據）。該樣式本身繪製一個使用形狀和填滿顏色作為參數的普通節點。

微量元素：

\documentclass{standalone}
\usepackage[dvipsnames]{xcolor}
\usepackage{forest}
\usetikzlibrary{calc,shadings}

\usepackage{pgfplots}
\pgfplotsset{compat=1.15}

% Code from Christian Feuersänger
% https://tex.stackexchange.com/questions/54794/using-a-pgfplots-style-legend-in-a-plain-old-tikzpicture#54834

% argument #1: any options
\newenvironment{customlegend}[1][]{%
    \begingroup
    % inits/clears the lists (which might be populated from previous
    % axes):
    \csname pgfplots@init@cleared@structures\endcsname
    \pgfplotsset{#1}%
}{%
    % draws the legend:
    \csname pgfplots@createlegend\endcsname
    \endgroup
}%

% makes \addlegendimage available (typically only available within an
% axis environment):
\def\addlegendimage{\csname pgfplots@addlegendimage\endcsname}

%%--------------------------------

% definition to insert numbers and shapes
\pgfkeys{/pgfplots/number in legend/.style={%
        /pgfplots/legend image code/.code={%
            \node at (0.295,-0.0225){#1};
        },%
        },
        /pgfplots/shape in legend/.style 2 args={%
        /pgfplots/legend image code/.code={%
            \node[draw,#1,fill=#2,minimum width=3mm] at (0.295,-0.0225){};
        },%
        },
}
\begin{document}

\begin{forest}
for tree={circle,draw,minimum size = 2.25em, l sep=15pt, s sep=3.0em}
[0, fill=Apricot
    [1, fill=SpringGreen, shape=diamond, for tree={s sep = 3.0em}
      [$\dots$, draw=none]
    ]
    [2, fill=SpringGreen, shape=star, for tree={s sep = 3.0em}
      [$\dots$, draw=none]
      [8]
    ]
    [3, fill=SpringGreen, shape=diamond
      [$\dots$, draw=none]
    ]
    [4, fill=Apricot
      [$\dots$, draw=none]
    ]
    [5, fill=SpringGreen, shape=regular polygon
      [$\dots$, draw=none]
    ]
]
\begin{customlegend}[
  legend entries={ % <= in the following there are the entries
  Green circle/node here,
  Red circle/node here,
  White Star here,
  White Diamond here,
  White Polygon here
  },
  legend style={at={(4.5,3.5)},font=\footnotesize}] % <= to define position and font legend
  % the following are the "images" and numbers in the legend
      \addlegendimage{shape in legend={circle}{SpringGreen}}
      \addlegendimage{shape in legend={circle}{red}}
      \addlegendimage{shape in legend={star}{white}}
      \addlegendimage{shape in legend={diamond}{white}}
      \addlegendimage{shape in legend={regular polygon}{white}}
  \end{customlegend}
\end{forest}

\end{document}

結果：
