一張圖中包含多個子圖

我想將 81 個子圖放入一張帶有一個標題的圖中，每個子圖都用一個數字標記。每個子圖的大小都相同（所以可能我不需要tabularx這個）。我想要一行 4 個子圖，如下圖，

SUFIG1 & SUFIG2 & SUFIG3 & SUFIG4

..

SUFIG77 & SUFIG78 & SUFIG79 & SUFIG80

子圖81

圖片說明：XXX

在每個子圖下面，我想要一個括號內的數字，例如在 SUFIG1 下面，我想要 (1) 等等。

在乳膠中做到這一點的最佳方法是什麼？我已經嘗試過tabular環境

\documentclass{report}
\usepackage{subcaption}
\begin{figure}
\begin{tabular}{cccc}
\subfloat[(1)]{\includegraphics[width=2cm]{SUBFIG1.eps}}
    & \subfloat[(2)]{\includegraphics[width=2cm]{SUBFIG2.eps}}
    &  \subfloat[(3)]{\includegraphics[width=2cm]{SUBFIG3.eps}}
    & \subfloat[(4)]{\includegraphics[width=2cm]{SUBFIG4.eps}} \\
\subfloat[(5)]{\includegraphics[width=2cm]{SUBFIG5.eps}}
    & \subfloat[(6)]{\includegraphics[width=2cm]{SUBFIG6.eps}}
 ...
\end{tabular}
\caption{XXX}
\label{xxx}
\end{figure}

但這裡subfloat有 az 作為計數分隔符，一旦我到達 24 個子圖，它就會離開頁面（即不會在新頁面上開始子圖 25）。謝謝！

答案1

由於所有圖像都具有相同的寬度，因此不需要表格類型的方法。只需使用\subfloat指令來放置它們，每行四個。

由於您載入了subcaption標題（因此也載入了套件），因此您可以在每個連續環境的頂部caption使用指令。\ContinuedFloatfigure

figure下面的螢幕截圖顯示了下面的程式碼產生的最後一個環境。

在此輸入影像描述

\documentclass{report}
\usepackage[margin=2.5cm]{geometry} % set page parameters suitably
\usepackage[demo]{graphicx} % remove 'demo' option in real document

\usepackage{subcaption}
\renewcommand\thesubfigure{\arabic{subfigure}} % arabic numerals
\captionsetup[figure]{skip=0.5\baselineskip}
\captionsetup[subfigure]{skip=0.25\baselineskip,position=below}

\begin{document}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\caption{XXX}\label{fig:xxx}

\subfloat[]{\includegraphics{SUBFIG01}}\hfill
\subfloat[]{\includegraphics{SUBFIG02}}\hfill
\subfloat[]{\includegraphics{SUBFIG03}}\hfill
\subfloat[]{\includegraphics{SUBFIG04}}

\medskip
\subfloat[]{\includegraphics{SUBFIG05}}\hfill
\subfloat[]{\includegraphics{SUBFIG06}}\hfill
\subfloat[]{\includegraphics{SUBFIG07}}\hfill
\subfloat[]{\includegraphics{SUBFIG08}}

\medskip
\subfloat[]{\includegraphics{SUBFIG09}}\hfill
\subfloat[]{\includegraphics{SUBFIG10}}\hfill
\subfloat[]{\includegraphics{SUBFIG11}}\hfill
\subfloat[]{\includegraphics{SUBFIG12}}

\medskip
\subfloat[]{\includegraphics{SUBFIG13}}\hfill
\subfloat[]{\includegraphics{SUBFIG14}}\hfill
\subfloat[]{\includegraphics{SUBFIG15}}\hfill
\subfloat[]{\includegraphics{SUBFIG16}}

\medskip
\subfloat[]{\includegraphics{SUBFIG17}}\hfill
\subfloat[]{\includegraphics{SUBFIG18}}\hfill
\subfloat[]{\includegraphics{SUBFIG19}}\hfill
\subfloat[]{\includegraphics{SUBFIG20}}

\medskip
\subfloat[]{\includegraphics{SUBFIG21}}\hfill
\subfloat[]{\includegraphics{SUBFIG22}}\hfill
\subfloat[]{\includegraphics{SUBFIG23}}\hfill
\subfloat[]{\includegraphics{SUBFIG24}}

\end{figure}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG25}}\hfill
\subfloat[]{\includegraphics{SUBFIG26}}\hfill
\subfloat[]{\includegraphics{SUBFIG27}}\hfill
\subfloat[]{\includegraphics{SUBFIG28}}

\medskip
\subfloat[]{\includegraphics{SUBFIG29}}\hfill
\subfloat[]{\includegraphics{SUBFIG30}}\hfill
\subfloat[]{\includegraphics{SUBFIG31}}\hfill
\subfloat[]{\includegraphics{SUBFIG32}}

\medskip
\subfloat[]{\includegraphics{SUBFIG33}}\hfill
\subfloat[]{\includegraphics{SUBFIG34}}\hfill
\subfloat[]{\includegraphics{SUBFIG35}}\hfill
\subfloat[]{\includegraphics{SUBFIG36}}

\medskip
\subfloat[]{\includegraphics{SUBFIG37}}\hfill
\subfloat[]{\includegraphics{SUBFIG38}}\hfill
\subfloat[]{\includegraphics{SUBFIG39}}\hfill
\subfloat[]{\includegraphics{SUBFIG40}}

\medskip
\subfloat[]{\includegraphics{SUBFIG41}}\hfill
\subfloat[]{\includegraphics{SUBFIG42}}\hfill
\subfloat[]{\includegraphics{SUBFIG43}}\hfill
\subfloat[]{\includegraphics{SUBFIG44}}

\medskip
\subfloat[]{\includegraphics{SUBFIG45}}\hfill
\subfloat[]{\includegraphics{SUBFIG46}}\hfill
\subfloat[]{\includegraphics{SUBFIG47}}\hfill
\subfloat[]{\includegraphics{SUBFIG48}}

\end{figure}

\begin{figure}[p]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG49}}\hfill
\subfloat[]{\includegraphics{SUBFIG50}}\hfill
\subfloat[]{\includegraphics{SUBFIG51}}\hfill
\subfloat[]{\includegraphics{SUBFIG52}}

\medskip
\subfloat[]{\includegraphics{SUBFIG53}}\hfill
\subfloat[]{\includegraphics{SUBFIG54}}\hfill
\subfloat[]{\includegraphics{SUBFIG55}}\hfill
\subfloat[]{\includegraphics{SUBFIG56}}

\medskip
\subfloat[]{\includegraphics{SUBFIG57}}\hfill
\subfloat[]{\includegraphics{SUBFIG58}}\hfill
\subfloat[]{\includegraphics{SUBFIG59}}\hfill
\subfloat[]{\includegraphics{SUBFIG60}}

\medskip
\subfloat[]{\includegraphics{SUBFIG61}}\hfill
\subfloat[]{\includegraphics{SUBFIG62}}\hfill
\subfloat[]{\includegraphics{SUBFIG63}}\hfill
\subfloat[]{\includegraphics{SUBFIG64}}

\medskip
\subfloat[]{\includegraphics{SUBFIG65}}\hfill
\subfloat[]{\includegraphics{SUBFIG66}}\hfill
\subfloat[]{\includegraphics{SUBFIG67}}\hfill
\subfloat[]{\includegraphics{SUBFIG68}}

\medskip
\subfloat[]{\includegraphics{SUBFIG69}}\hfill
\subfloat[]{\includegraphics{SUBFIG70}}\hfill
\subfloat[]{\includegraphics{SUBFIG71}}\hfill
\subfloat[]{\includegraphics{SUBFIG72}}

\end{figure}

\begin{figure}[ht!]
\setkeys{Gin}{width=0.22\textwidth,height=0.125\textheight,keepaspectratio}
\ContinuedFloat
\caption{XXX, continued}

\subfloat[]{\includegraphics{SUBFIG73}}\hfill
\subfloat[]{\includegraphics{SUBFIG74}}\hfill
\subfloat[]{\includegraphics{SUBFIG75}}\hfill
\subfloat[]{\includegraphics{SUBFIG76}}

\medskip
\subfloat[]{\includegraphics{SUBFIG77}}\hfill
\subfloat[]{\includegraphics{SUBFIG78}}\hfill
\subfloat[]{\includegraphics{SUBFIG79}}\hfill
\subfloat[]{\includegraphics{SUBFIG80}}

\medskip
\subfloat[]{\includegraphics{SUBFIG81}}\hfill

\end{figure}


\end{document}

答案2

也許，如果您將數字放在表格中，然後使用\ContinuedFloat.儘管在這種方法中，您必須手動分割圖形，這當然不是很優雅。

\documentclass{scrreprt}
\usepackage{graphicx}
\usepackage{subcaption}

\DeclareCaptionSubType*{figure}\renewcommand\thesubfigure{\arabic{subfigure}}
\newcommand{\sub}[1]{\begin{minipage}{.2\linewidth}\includegraphics[width=\linewidth]{#1}\subcaption{}\end{minipage}}
\newcommand{\tabfig}[4]{\sub{#1} & \sub{#2} & \sub{#3} & \sub{#4}\\}

\begin{document}
\begin{figure}[ht]
   \begin{tabular}{cccc}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
   \end{tabular}
\end{figure}
\begin{figure}[ht]\ContinuedFloat
   \begin{tabular}{cccc}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
       \tabfig{example}{example}{example}{example}
   \end{tabular}
\end{figure}
\end{document}
