我想將五個子圖放入一個圖中。第一個是一個寬矩形。其他四個更接近正方形。 [
]
\documentclass[12pt]{scrreport}
\usepackage{graphicx}
\graphicspath{ {images/} }
\usepackage{framed}
\usepackage{float}
begin{document}
\begin{figure}
\centering
\begin{subfigure}[t]{1\textwidth}
\centering
\includegraphics[width=0.35\linewidth, angle =90 ]{a}
\caption{a}
\label{fig:a}
\end{subfigure}
\begin{subfigure}[b]{.5\textwidth}
\centering
\includegraphics[width=.6\linewidth,cfbox=green 1pt 1pt]{b}\quad
\caption{b}
\label{b}
\end{subfigure}
\begin{subfigure}[c]{0.5\textwidth}
\centering
\includegraphics[width=.6\linewidth,cfbox=red 1pt 1pt]{c}
\caption{c}
\label{fig:c}
\end{subfigure}
\begin{subfigure}[d]{0.5\textwidth}
\centering
\includegraphics[width=.7\linewidth,cfbox=green 1pt 1pt]{d}
\caption{d}
\label{d}
\end{subfigure}
\begin{subfigure}[e]{0.5\textwidth}
\centering
\includegraphics[width=.7\linewidth,cfbox=red 1pt 1pt]{e}
\caption{e}
\label{fig:e}
\end{subfigure}
\caption{blabla}
\end{minipage}
\end{figure}
\end{document}
答案1
也許以下範例程式碼可以幫助您入門。只需將filename佔位符替換為實際文件名，從包[demo]中刪除graphicx，編譯並查看它是否適合您的需求：
\documentclass[12pt]{scrreport}
\usepackage[demo]{graphicx} % remove the demo option in your actual document!
\usepackage{subcaption}
\begin{document}
\begin{figure}
\centering
\begin{subfigure}{1\textwidth}
\centering
\includegraphics[width=\linewidth]{filename}
\caption{}
\label{fig:a}
\end{subfigure}
\begin{subfigure}[b]{.45\textwidth}
\centering
\includegraphics[width=\linewidth]{filename}
\caption{}
\label{b}
\end{subfigure}
\hfill
\begin{subfigure}[b]{0.45\textwidth}
\centering
\includegraphics[width=\linewidth]{filename}
\caption{}
\label{fig:c}
\end{subfigure}
\begin{subfigure}[b]{.45\textwidth}
\centering
\includegraphics[width=\linewidth]{filename}
\caption{}
\label{d}
\end{subfigure}
\hfill
\begin{subfigure}[b]{0.45\textwidth}
\centering
\includegraphics[width=\linewidth]{filename}
\caption{}
\label{fig:e}
\end{subfigure}
\caption{blabla}
\label{figurelabel}
\end{figure}
\end{document}
