Tikz圖片不顯示多個填充之間

Question

我在投影機簡報中有以下程式碼：

\begin{frame}[c]{ }
\frametitle{Section 5.2: Definite Integral}


\begin{center}
\begin{tikzpicture}[scale =1]
  \begin{axis}[
    axis lines=center,
    grid=major,
    xmin=-12.5,
    xmax=12.5,
    ymin=-10.5,
    ymax=10.5,
    xtick = {-12,-10,...,12},
    ytick = {-10,-8,...,10},
    yticklabel style = {font=\tiny,xshift=0.5ex},
    xticklabel style = {font=\tiny,yshift=0.5ex},
    no marks,
    axis line style={thick, <->},
    ]
\addplot+[-, samples = 200, thin, black, domain = -12:12 , name path=A] {0};
\addplot+[<-, samples = 200, thick, blue, domain = -11:-4 , name path=B] {0.5*(x + 4) + 4};
\addplot+[-, samples = 200, thick, blue, domain = -4:-0 , name path=C] {4};
\addplot+[-, samples = 200, thick, blue, domain = 0:6, name path=D] {-2*x+4};
\addplot+[->, samples = 200, thick, blue, domain = 6:10.25, name path=E] {4*(x - 6)-8};
\addplot+[red, opacity = 0.3] fill between[of=A and B,soft clip={domain=-8:-4}]; % filling
\addplot+[red, opacity = 0.3] fill between[of=A and C,soft clip={domain=-4:-0}]; % filling
\addplot+[red, opacity = 0.3] fill between[of=A and D,soft clip={domain=0:6}]; % filling
\addplot+[red, opacity = 0.3] fill between[of=A and E,soft clip={domain=6:10}]; % filling
\node[blue] at (axis cs:7,7){{\tiny$y = g(t)$}};
\end{axis}
\end{tikzpicture}
\end{center}
\end{frame}

產生以下圖片：

我想要填充曲線下從 t = -8 到 t = 10 的整個區域，但它只填充第一部分。我怎樣才能解決這個問題？

Answer 1

我建議你使用一個plot盡可能使用單一座標，我使用相同的座標複製了您的座標（對於不精確的路徑，我將它們疊加並且它們完美匹配）。我也會為您提供解決方案和程式碼，以便您選擇。

你的程式碼

\documentclass[tikz, margin=10pt]{standalone}
\usepackage{pgfplots}

\pgfplotsset{compat=1.17}
\usepgfplotslibrary{fillbetween}

\begin{document}
\begin{tikzpicture}[scale =1]
    \begin{axis}[
      axis lines=center,
      grid=major,
      xmin=-12.5,
      xmax=12.5,
      ymin=-10.5,
      ymax=10.5,
      xtick = {-12,-10,...,12},
      ytick = {-10,-8,...,10},
      yticklabel style = {font=\tiny,xshift=0.5ex},
      xticklabel style = {font=\tiny,yshift=0.5ex},
      no marks,
      axis line style={thick, <->},
      ]
      \path[name path=axis] (axis cs:-10,0) -- (axis cs:12,0);
    \addplot+[-, samples = 200, thin, black, domain = -12:12 , name path=A] {0};
    \addplot+[<-, samples = 200, thick, blue, domain = -11:-4 , name path=B] {0.5*(x + 4) + 4};
    \addplot+[-, samples = 200, thick, blue, domain = -4:-0 , name path=C] {4};
    \addplot+[-, samples = 200, thick, blue, domain = 0:6, name path=D] {-2*x+4};
    \addplot+[->, samples = 200, thick, blue, domain = 6:10.25, name path=E] {4*(x - 6)-8};
    \addplot+[red, opacity = 0.3] fill between[of=A and B,soft clip={domain=-8:-4}]; % filling
    \addplot+[red, opacity = 0.3] fill between[of=A and C,soft clip={domain=-4:-0}]; % filling
    \addplot+[red, opacity = 0.3] fill between[of=A and D,soft clip={domain=0:6}]; % filling
    \addplot+[red, opacity = 0.3] fill between[of=A and E,soft clip={domain=6:10}]; % filling
  \node[blue] at (axis cs:7,7){{\tiny$y = g(t)$}};
  \end{axis}
  \end{tikzpicture}
\end{document}

單塊地塊

\documentclass[tikz, margin=10pt]{standalone}
\usepackage{pgfplots}

\pgfplotsset{compat=1.17}
\usepgfplotslibrary{fillbetween}

\begin{document}
\begin{tikzpicture}
    \begin{axis}[
      axis lines=center,
      grid=major,
      xmin=-12.5,
      xmax=12.5,
      ymin=-10.5,
      ymax=10.5,
      xtick = {-12,-10,...,12},
      ytick = {-10,-8,...,10},
      yticklabel style = {font=\tiny,xshift=0.5ex},
      xticklabel style = {font=\tiny,yshift=0.5ex},
      no marks,
      axis line style={thick, <->},
      ]
    \addplot+[<->, samples=200, thick, blue, name path=myplot] coordinates {
        (-11,.5) (-4,4) (0,4) (6,-8) (10.25,9)
    };
    \path[name path=axis] (axis cs:-10,0) -- (axis cs:12,0);
    \addplot+[red, opacity = 0.3] fill between[of=myplot and axis,soft clip={domain=-8:10}]; % filling
\node[blue] at (axis cs:7,7){{\tiny$y = g(t)$}};
\end{axis}
\end{tikzpicture}
\end{document}

兩種情況的結果都是：
