將太長的方程式移至中心並擴大 LaTeX 中文字的寬度？

tag-icon • tag-icon equations align width
將太長的方程式移至中心並擴大 LaTeX 中文字的寬度？

我製作的公式太長，因此它顯示不居中。我希望將其移動到中心並僅針對此公式擴展文字寬度，因此在此公式之後，我希望文字寬度恢復為預設值。

\documentclass{article}
\usepackage{amsmath}
\usepackage[version=4]{mhchem}
\usepackage{mathtools}
\begin{document}
\centering
\begin{align}
      \label{eq:MgSO4}
     \left( \ce{MgSO4}\right)&=-\frac{10^{\text{pH}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{29441213}{5000000}}}
      {
        \splitfrac{-10^{\frac{16393 t^2}{25000 (20 t+5463)}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
        \left(10^{\text{pH}}+10^{\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}\\
      \label{eq:CaSO4}
      \left(\ce{CaSO4}\right)&=-\frac{10^{\frac{16393 t^2}{25000 (20 t+5463)}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}
      {
        \splitfrac{-10^{\frac{16393 t^2}{25000 (20 t+5463)}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
        \left(10^{\text{pH}}+10^{\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}\\
      \label{eq:CaMg(CO3)2}
      \left(\ce{CaMg(CO3)2}\right)&=-\frac{10^{2 \text{pH}+\frac{58880041}{10000000}}}
      {
        \splitfrac{-10^{\frac{16393 t^2}{25000 (20 t+5463)}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
        \left(10^{\text{pH}}+10^{\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}
   \end{align}
\end{document}

在此輸入影像描述 由於分母已分為兩部分，有沒有辦法為分母添加背景，以便讀者知道這兩部分應該一起閱讀？

答案1

當然，從風格上來說，有點黑客行為，但這是有效的：

\documentclass{article}
\usepackage{amsmath}
\usepackage[version=4]{mhchem}
\usepackage{mathtools}
%\UseTblrLibrary{booktabs, siunitx}  % throws an error
\usepackage{chngpage}
\begin{document}
%\centering  % why is this here?
\begin{adjustwidth}{-2.5cm}{-2.5cm}
\begin{align}
      \label{eq:MgSO4}
     \left( \ce{MgSO4}\right)&=-\frac{10^{\text{pH}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{29441213}{5000000}}}
      {
        \splitfrac{-10^{\frac{16393 t^2}{25000 (20 t+5463)}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
        \left(10^{\text{pH}}+10^{\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}\\
      \label{eq:CaSO4}
      \left(\ce{CaSO4}\right)&=-\frac{10^{\frac{16393 t^2}{25000 (20 t+5463)}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}
      {
        \splitfrac{-10^{\frac{16393 t^2}{25000 (20 t+5463)}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
        \left(10^{\text{pH}}+10^{\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}\\
      \label{eq:CaMg(CO3)2}
      \left(\ce{CaMg(CO3)2}\right)&=-\frac{10^{2 \text{pH}+\frac{58880041}{10000000}}}
      {
        \splitfrac{-10^{\frac{16393 t^2}{25000 (20 t+5463)}+\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
        \left(10^{\text{pH}}+10^{\frac{47580 t^2+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}
   \end{align}
\end{adjustwidth}
\end{document}

這使用了chngpage環境包adjustwidth。

答案2

一個可能的解決方案，結合了 加載geometry，以獲得更體面的利潤，fleqn環境和中等大小的分數 來自nccmath和\mathrlap來自mathtools：

    \documentclass{article}
    \usepackage{amsmath}
    \usepackage[version=4]{mhchem}
    \usepackage{nccmath, mathtools}
    \usepackage[showframe]{geometry}

    \begin{document}

    \begin{fleqn}
    \begin{align}
          \label{eq:MgSO4}
         \left( \ce{MgSO4}\right)&=-\mathrlap{\mfrac{10^{\text{pH}+\frac{47580 t²+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{29441213}{5000000}}}
          {
            \splitfrac{-10^{\frac{16393 t²}{25000 (20 t+5463)}+\frac{47580 t²+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
            \left(10^{\text{pH}}+10^{\frac{47580 t²+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}}\\
          \label{eq:CaSO4}
          \left(\ce{CaSO4}\right)&=-\mathrlap{\mfrac{10^{\frac{16393 t²}{25000 (20 t+5463)}+\frac{47580 t²+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}
          {
            \splitfrac{-10^{\frac{16393 t²}{25000 (20 t+5463)}+\frac{47580 t²+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
            \left(10^{\text{pH}}+10^{\frac{47580 t²+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}}\\
          \label{eq:CaMg(CO3)2}
          \left(\ce{CaMg(CO3)2}\right)&=-\mathrlap{\mfrac{10^{2 \text{pH}+\frac{58880041}{10000000}}}
          {
            \splitfrac{-10^{\frac{16393 t²}{25000 (20 t+5463)}+\frac{47580 t²+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{89554959 t}{500000 (20 t+5463)}+\frac{340471}{5 (20 t+5463)}+\frac{477}{2000000}}}{-10^{\text{pH}+\frac{58880041}{10000000}}
            \left(10^{\text{pH}}+10^{\frac{47580 t²+12996477 t+5804780000}{100000 (20 t+5463)}+\frac{477}{2000000}}\right)}}}
       \end{align}
    \end{fleqn}

    \end{document}

在此輸入影像描述

答案3

增加文字區塊的寬度可能會略有幫助。然而，我認為最好專注於識別三個方程式的分子和分母項中的共同“塊”或“塊”。例如，人們可能會注意到不僅所有三個分母都相同，而且第二個方程中分數的分子出現在所有三個大分母中。因此，第二個方程式的 RHS 可以寫成\frac{U}{U+V}。經過更多的常用術語收集後，我們得出以下結論：

在此輸入影像描述

\documentclass{article}
\usepackage[version=4]{mhchem}
\usepackage{mathtools}
\DeclareMathOperator{\ten}{ten}
\newcommand\pH{\mathrm{pH}}
\begin{document}
\noindent
Put $\ten(x)\equiv 10^{x}$. Then
\begin{align}
( \ce{MgSO4})    &= A/D \label{eq:MgSO4} \\
(\ce{CaSO4})     &= B/D \label{eq:CaSO4} \\
(\ce{CaMg(CO3)2})&= C/D \label{eq:CaMg(CO3)2}
\end{align}
where
\begin{align*}
A&=\ten(\pH+H+N) \\
B&=\ten(G+H+J+K+L) \\
C&=\ten(2\pH+M) \\
D&=B + \ten(\pH+M) [\ten(\pH)+\ten(H+L)] \\
\shortintertext{and}
G&= \frac{16393 t^2}{25000 (20t+5463)} \\[\jot]
H&= \frac{47580 t^2+12996477 t+5804780000}{100000 (20t+5463)} \\[\jot]
J&= \frac{89554959 t}{500000 (20t+5463)} \\[\jot]
K&= \frac{340471}{5 (20t+5463)} \\[\jot]
L&= \frac{477}{2000000} \\[\jot]
M&= \frac{58880041}{10000000} \\[\jot]
N&= \frac{29441213}{5000000} \,.
\end{align*}
\end{document}
