如果與其他尺寸的圖像和文字混合在一起，如何確保不同頁面上相同尺寸的文字在頁面頂部的距離相同

tag-icon • tag-icon spacing vertical-alignment margins geometry
如果與其他尺寸的圖像和文字混合在一起，如何確保不同頁面上相同尺寸的文字在頁面頂部的距離相同

THIS TEXT NEEDS TO BE ALIGNED我的一頁上只有文本book，前面有一些vspace值。另一個頁面上還有一些WITH THIS TEXT文本，前面有一些vspace值、TEXT BEFORE TEXT THAT NEEDS TO BE ALIGNED不同大小的文本和example-image-c圖像。
我需要THIS TEXT NEEDS TO BE ALIGNED和WITH THIS TEXT與頁面頂部的距離完全相同，因此，如果兩個頁面堆疊在一起，兩個文字將彼此正確對齊。
在我當前的程式碼中，我分配ex values給文本，vspaces甚至分配給圖像的高度。我希望透過等於兩個文字之前的所有元素的垂直值總數，我將正確對齊所需的文字（與頁面頂部的距離相同），但事實並非如此！我究竟做錯了什麼？\begin{titlepage}其中一頁是否增加了一些我不知道的空間？

% !TEX TS-program = LuaLaTeX
\documentclass[11pt,twoside,openany]{book}
\pagestyle{plain}
\usepackage[english, russian]{babel}
\usepackage{fontspec}
\setmainfont{EB Garamond}[
  SmallCapsFont={EB Garamond SC},
  SmallCapsFeatures={Letters=SmallCaps},
  Ligatures=TeX,
]
\usepackage{microtype}
\usepackage[shortcuts]{extdash}
\usepackage[pagewise]{lineno}
\usepackage[
  paperwidth=6in,
  paperheight=9in,
  inner=15mm,
  top=15mm,
  outer=20mm,
  bottom=22mm,
  heightrounded,
]{geometry}

\usepackage{lipsum}
\setlength{\parskip}{0pt}
\usepackage{graphicx}
\usepackage[dvipsnames]{xcolor}
\usepackage{titlesec}

\titleclass{\chapter}{straight}
\titleformat{\chapter}[display]{\filcenter\normalfont\large}{\thechapter.}{6pt}{}
\titlespacing*{\chapter}{0pt}{30pt}{10pt plus 10pt}

\begin{document}
\pagenumbering{gobble}
\frontmatter

% PAGE1
\vspace*{14ex}
\begin{center}
        {\fontsize{4ex}{4ex}\bfseries{THIS TEXT NEEDS TO BE ALIGNED}\par} % TEXT THAT NEEDS TO BE ALIGNED
\end{center}
        \vspace{9ex}
\AddToHook{shipout/background}{%
\put(0mm,-240mm){\ifnum\value{page}=0 \includegraphics[width=200mm,height=250mm,keepaspectratio]{example-image-a}\fi}
\put(60mm,-200mm){\ifnum\value{page}=0 \includegraphics[width=60mm,height=60mm,keepaspectratio]{example-image-b}\fi}
 }
\clearpage

% TITLE PAGE
\begin{titlepage}
        \centering
        \vspace*{6ex}
         {\scshape\fontsize{6ex}{6ex}{TEXT BEFORE TEXT THAT NEEDS TO BE ALIGNED}\par}
  \begin{center}
    \includegraphics[height=2ex,keepaspectratio]{example-image-c}
  \end{center}
        {\fontsize{4ex}{4ex}\bfseries{WITH THIS TEXT}\par} % TEXT THAT NEEDS TO BE ALIGNED
        \vspace{9ex}
        {\scshape\footnotesize{SOME RANDOM TEXT}\par}
        \vspace{3ex}
         {\scshape\footnotesize{SOME RANDOM TEXT}\par}
        \vspace{9ex}
        {\large SOME RANDOM TEXT\par}
        \vspace{50ex}
        {\footnotesize SOME RANDOM TEXT\par}
        \vspace{0ex}
        {\footnotesize SOME RANDOM TEXT\par}
        \vspace{0ex}
        {\footnotesize SOME RANDOM TEXT\par}
        \vspace{0ex}
        \vfill
 \title{SOME TITLE}
 \author{SOME AUTHOR}
\date{}
\end{titlepage}
\clearpage

\mainmatter

\pagenumbering{arabic}

\chapter{CHAPTER ONE}
\lipsum[1-1]

\end{document}

答案1

此方法使用包含「WITH THIS TEXT」上方材料的方塊來計算「THIS TEXT NEEDS TO BE ALIGNED」之前所需的垂直空間，以對齊兩個句子。

C

（ \documentclass[11pt,oneside,openany]{book}僅用於開啟 pdf 檔案時並排顯示兩頁。）

更新後續問題之後。

\documentclass[11pt,oneside,openany]{book}

\usepackage[english, russian]{babel}
\usepackage{fontspec}
\setmainfont{EB Garamond}

\usepackage{microtype}
\usepackage[shortcuts]{extdash}
\usepackage[pagewise]{lineno}

\usepackage[
paperwidth=6in,
paperheight=9in,
inner=15mm,
top=15mm,
outer=20mm,
bottom=22mm,
heightrounded,
showframe % added showframe to display the margins
]{geometry}

\usepackage{lipsum}
\setlength{\parskip}{0pt}
\usepackage{graphicx}
\usepackage[dvipsnames]{xcolor}
\usepackage{titlesec}

\titleclass{\chapter}{straight}
\titleformat{\chapter}[display]{\filcenter\normalfont\large}{\thechapter.}{6pt}{}
\titlespacing*{\chapter}{0pt}{30pt}{10pt plus 10pt}

% ************************************* added <<<<<<
\newsavebox{\upperspace}
    \savebox{\upperspace}{%
    \begin{minipage}[b][][t]{\textwidth}
        \begin{titlepage}
            \centering
            \vspace*{6ex}
            {\scshape\fontsize{2ex}{2ex}\selectfont TEXT BEFORE TEXT THAT NEEDS TO BE ALIGNED\par}
            \begin{center}
                \includegraphics[height=2ex,keepaspectratio]{example-image-c}
            \end{center}
        \end{titlepage}
    \end{minipage}
}

\newlength{\hhbox}
\settoheight{\hhbox}{\usebox{\upperspace}}
% *************************************

\begin{document}

\pagenumbering{gobble}
\frontmatter

% PAGE1
\vspace*{\dimexpr\the\hhbox-1em}% changed <<<<<<<<<
{\centering

{\fontsize{4ex}{4ex}\selectfont\bfseries THIS TEXT NEEDS TO BE ALIGNED\par}% TEXT THAT NEEDS TO BE ALIGNED

\AddToHook{shipout/background}{%
\put(0mm,-0mm){\ifnum\value{page}=0 \includegraphics[width=200mm,height=250mm,keepaspectratio]{example-image-a}\fi}
\put(60mm,-0mm){\ifnum\value{page}=0 \includegraphics[width=60mm,height=60mm,keepaspectratio]{example-image-b}\fi}
}}

\clearpage

% TITLE PAGE
\begin{titlepage}
    \centering
    \usebox{\upperspace}

    {\fontsize{4ex}{4ex}\selectfont\bfseries WITH THIS TEXT\par} % TEXT THAT NEEDS TO BE ALIGNED
    \vspace{9ex}
    {\scshape\footnotesize{SOME RANDOM TEXT}\par}
    \vspace{3ex}
    {\scshape\footnotesize{SOME RANDOM TEXT}\par}
    \vspace{9ex}
    {\large SOME RANDOM TEXT\par}
    \vspace{50ex}
    {\footnotesize SOME RANDOM TEXT\par}
    \vspace{0ex}
    {\footnotesize SOME RANDOM TEXT\par}
    \vspace{0ex}
    {\footnotesize SOME RANDOM TEXT\par}
    \vspace{0ex}
    \vfill
    \title{SOME TITLE}
    \author{SOME AUTHOR}
    \date{}
\end{titlepage}
\clearpage

\mainmatter

\pagenumbering{arabic}

\chapter{CHAPTER ONE}
\lipsum[1-1]

\end{document}

在群組內使用時\fontsize{}{}\selectfont，需要在關閉群組之前結束段落。

\selectfont雖然字體大小在發布新版本時更新，baselineskip但僅在段落使用 , 或空白行結束時更新\par。

看\fontsize{}{} 如何運作？
