在群組圖物件中間包含文字

Question

我試圖在組圖的中間包含一個 \vdots ，為此，我試圖插入一個沒有邊界軸的圖，但一直無法這樣做。

微量元素：

\documentclass[border=5pt, multi, tikz]{standalone}
\usepackage{pgfplots} \usetikzlibrary{quotes,arrows.meta}
\usetikzlibrary{decorations.pathreplacing,intersections}
\usetikzlibrary{shapes.misc}
\usetikzlibrary{calc,fit}
\usetikzlibrary{pgfplots.groupplots}
\begin{document}
\begin{tikzpicture}[every edge quotes/.append style={auto, text=blue}]
    \begin{groupplot}[
    group style=
        {group size=1 by 4,
        vertical sep=0pt,
        group name = myplots},
        height=2cm,
        width=5cm,
        xtick=\empty,
        ytick=\empty,
        ]
        \nextgroupplot
        \addplot[blue, title=Multichannel Audio] table [col sep=comma] {audio1.csv} coordinate (ax1);
        \nextgroupplot
        \addplot[red] table [col sep=comma] {audio1.csv} coordinate[near start] (ax2) ;
        \nextgroupplot
        \addplot[hide axis, draw=none, no markers, axis line style={draw=none},
         tick style={draw=none}] {0} node[midway, draw=none, align=center] (ax3) {$\vdots$};
        \nextgroupplot
        \addplot[green] table [col sep=comma] {audio1.csv} coordinate[near start] (ax2) ;
        \end{groupplot}

    \end{tikzpicture}
\end{document}

在紅色和綠色圖之間，我希望有一個 \vdots 來表示多個通道，而圖中沒有邊界框。

Answer 1

所以，經過一番修改，我找到了一個方法：

\documentclass[border=5pt, multi, tikz]{standalone}
\usepackage{pgfplots}
\usetikzlibrary{quotes,arrows.meta}
\usetikzlibrary{decorations.pathreplacing,intersections}
\usetikzlibrary{shapes.misc}
\usetikzlibrary{calc,fit}
\usetikzlibrary{pgfplots.groupplots}
\begin{document}
    \begin{tikzpicture}[every edge quotes/.append style={auto, text=blue}]
        \begin{groupplot}[
            group style=
            {group size=1 by 4,
                vertical sep=0pt,
                group name = myplots},
            height=2cm,
            width=5cm,
            xtick=\empty,
            ytick=\empty,
            ]
            \nextgroupplot
            \addplot[blue, title=Multichannel Audio] table [col sep=comma] {audio1.csv} coordinate (ax1);
            \nextgroupplot
            \addplot[red] table [col sep=comma] {audio1.csv} coordinate[near start] (ax2) ;
            \nextgroupplot[hide axis, draw=none, no markers, axis line style={draw=none},
            tick style={draw=none}]
            \addplot[white] {0} node[black, midway, draw=none, align=center, yshift=3] (ax3) {$\vdots$};
            \nextgroupplot
            \addplot[green] table [col sep=comma] {audio1.csv} coordinate[near start] (ax2) ;

        \end{groupplot}

\end{tikzpicture}
\end{document}

這導致出現以下圖像：

這就是我想要實現的目標。
