在 TikZ 中繪製一條帶有文字描述的數軸

Question

我想知道如何使用 TikZ 建立以下數軸：

https://i.stack.imgur.com/oQtaD.jpg

我嘗試閱讀這裡的其他問題，但我遇到的主要挑戰是：（1）在數軸中間創建三個點“...”，以及（2）將大括號分成兩個(3) 將文字放在一些捲線的上方和下方。

謝謝你！

Answer 1

• 在您的問題中，您沒有顯示所需圖像的草圖，僅顯示不可訪問的連結。
• 我希望 @Tom 答案中的圖像與您所追求的足夠接近。
• 我會稍微不同地畫這張圖，因為我喜歡這樣：

• 我嘗試寫出盡可能簡潔且結構清晰的MWE：

\documentclass[border=3.141592]{standalone}
\usepackage{amsmath}
\usepackage{tikz}
\usetikzlibrary{arrows.meta,
                decorations.pathreplacing,%
                    calligraphy,% had to be after decorations.pathreplacing
                calc}

\begin{document}
    \begin{tikzpicture}[
             > = Straight Barb,
BC/.style args = {#1/#2}{
        decorate,
        decoration={calligraphic brace, amplitude=6pt,
                    pre =moveto, pre  length=1pt,
                    post=moveto, post length=1pt,
                    raise=#1,
                    #2,% for mirroring of brace
                    },
            ultra thick},
                        ]
\draw [ultra thick,->] (-7.5,0) -- (7.5,0);
    \foreach \i [count=\x from -6] in  {-23,-22,-21,-20,-19,\dotsm,1,2,...,6}
\draw[thick] (\x,3mm) -- ++ (0,-6mm) node (n\x) [below] {$\i$};
%
\draw[BC=4mm/]          (-6,0) -- node[above=6mm] {other text} (-2,0);
\draw[BC=8mm/mirror]    ( 0,0) -- coordinate[below=11mm] (aux)  (5,0);
\draw[<->, semithick, densely dashed, rounded corners]
    (n-6) -- node[fill=white] {some text} ++ (0,-1.3) -| (aux);
    \end{tikzpicture}
\end{document}

Answer 2

這是一個解決方案。有沒有辦法讓程式碼更簡潔呢？有什麼建議嗎？

\documentclass[border=1cm]{standalone}
\usepackage{tikz}
\usetikzlibrary{arrows.meta, decorations.pathreplacing,calc}

\begin{document}
\begin{tikzpicture}
\draw [line width=5pt,-{Triangle[length=0.5cm,width=0.5cm]}] (-7.5,0) -- (7.5,0);
\foreach \x in {-6,...,-2} {
\draw [line width=2pt] (\x,-0.5) node (bx\x) [font=\Large,xshift=-6pt,below=0.5cm] {\pgfmathparse{\x-17}$\mathbf{\pgfmathprintnumber{\pgfmathresult}}$} -- (\x,0.5) coordinate (tx\x);}
\draw [line width=2pt] (-1,-0.5) node (bx-1)  [font=\bfseries\Large,below=0.75cm] {\dots} -- (-1,0.5) coordinate (tx-1);
\foreach \x in {0,...,6} {
\draw [line width=2pt] (\x,-0.5) node (bx\x) [font=\Large,below=0.5cm] {\pgfmathparse{\x+1}$\mathbf{\pgfmathprintnumber{\pgfmathresult}}$} -- (\x,0.5) coordinate (tx\x);}
\draw [decorate,decoration={brace,raise=10pt,amplitude=20pt}] (tx-6) -- (tx-1) node (TB) [midway,above=1.2cm,font=\large] {\textbf{Other Text}};
\draw [decorate,decoration={brace,raise=10pt,amplitude=20pt,mirror}] (bx0.south) -- (bx6.south) node (BB) [midway,below=1cm] {};
\draw [{[scale=2]Triangle}-] ($(bx-6)+(6pt,-10pt)$) -- ++(0,-0.7) node (ST) [below=4pt,font=\large] {\textbf{Some Text}};
\draw [shorten <=6pt,shorten >=6pt,-{[scale=2]Triangle}] (ST.south) .. controls +(-80:1.5cm) and +(200:1.5cm) .. (BB.south west);
\end{tikzpicture}
\end{document}
