在兩個向量之間畫一個角度？

我想畫兩個向量之間的角度：

\documentclass{article}
\usepackage{tikz}
\usetikzlibrary{angles,quotes,babel,plotmarks}
\usetikzlibrary{decorations.pathreplacing}
\usetikzlibrary{calc}

\begin{document}
\begin{tikzpicture}[decoration=brace]


% orthogonal ground line
\draw[thick] (-3,0) -- (3,0);

% Origin
\draw[fill=black] (0,0) node(O)[anchor=north] {$O$};

% vector a
\draw[thick,->] (0,0) -- (-2,2) node(a)[anchor=north east] {$a$};

% vector b
\draw[thick,->] (0,0) -- (2.5,1.5) node(b)[anchor=west] {$b$};


\pic [draw, -, angle eccentricity=1.2, angle radius=1cm,, "$\gamma$"] {angle=b--O--a};

\end{tikzpicture}
\end{document}

由於某些原因，角度畫得比預期大？

在此輸入影像描述

有什麼建議如何正確執行此操作嗎？

答案1

原因是您錯誤地定義了角度的座標。如果您編寫\draw (0,0) -- (-2,2) node (a) [anchor=north east] {$a$};，則定義(a)為對標籤 的節點的引用$a$，按照您的定義，其中心是north east座標(-2,2)。但這是(-2,2)您實際需要的角度座標。

所以，你應該這樣做：

\documentclass[border=10pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{angles,quotes}

\begin{document}
\begin{tikzpicture}

% orthogonal ground line
\draw[thick] (-3,0) -- (3,0);

% Origin
\draw[fill=black] (0,0) coordinate (O) node [anchor=north] {$O$};

% vector a
\draw[thick,->] (0,0) -- (-2,2) coordinate (a) node[anchor=north east] {$a$};

% vector b
\draw[thick,->] (0,0) -- (2.5,1.5) coordinate (b) node[anchor=west] {$b$};

\pic[draw, angle eccentricity=1.2, angle radius=1cm,, "$\gamma$"] {angle=b--O--a};

\end{tikzpicture}
\end{document}

作為替代方案，您可以使用labels：

\documentclass[border=10pt]{standalone}
\usepackage{tikz}
\usetikzlibrary{angles,quotes}

\begin{document}
\begin{tikzpicture}

% orthogonal ground line
\draw[thick] (-3,0) -- (3,0);

% Origin
\draw[fill=black] (0,0) coordinate[label={below:$0$}] (O);

% vector a
\draw[thick,->] (0,0) -- (-2,2) coordinate[label={below left:$a$}] (a);

% vector b
\draw[thick,->] (0,0) -- (2.5,1.5) coordinate[label={right:$b$}] (b);

\pic [draw, angle eccentricity=1.2, angle radius=1cm,, "$\gamma$"] {angle=b--O--a};

\end{tikzpicture}
\end{document}

在此輸入影像描述

答案2

這很容易做到pstricks——更具體地說pst-eucl：

    \documentclass[pstricks, border=6pt]{standalone}
    \usepackage{pst-eucl}

    \begin{document}

    \begin{pspicture}(-3,-1)(3,3)
    \psset{arrowinset=0.12,labelsep=3pt}
    \pstGeonode[PointSymbol=none, PosAngle={-90,135, 45}](0,0){O}(-2,2){a}(2.5,1.5){b}
    % orthogonal ground line
    \psline (-3,0)(3,0)
    \ncline{->}{O}{a}\ncline{->}{O}{b}
    \pstMarkAngle[linewidth=0.3pt, LabelSep=0.6]{b}{O}{a}{$\gamma$}%
    \end{pspicture}

    \end{document}

在此輸入影像描述

答案3

節點不在端點處，而是在旁邊，您需要像這樣指定座標

\begin{tikzpicture}[decoration=brace]
% orthogonal ground line
\draw[thick] (-3,0) -- (3,0);

% Origin
\coordinate (O) at (0,0);
\draw[fill=black] (O) node[anchor=north] {$O$};

% vector a
\coordinate (a) at (-2,2);
\draw[thick,->] (O) -- (a) node[anchor=south east] {$a$};

% vector b
\coordinate (b) at (2.5,1.5);
\draw[thick,->] (O) -- (b) node[anchor=south west] {$b$};

\pic [draw, -, angle eccentricity=1.2, angle radius=1cm,, "$\gamma$"] {angle=b--O--a};
\end{tikzpicture}
