圖片的定位

Question

我想畫兩張圖，第二張圖應該在第一張圖的下面。這就是我目前所擁有的：

第二張圖片如何獲得與第一張圖片相同的 x 座標？

代碼：

\documentclass[tikz,border=2mm]{standalone}
\usetikzlibrary{positioning}
\usetikzlibrary{fit}
\begin{document}

\tikzset{
    pics/vhsplit/.style n args = {3}{
        code = {
        \node (A) at (0,0) {#1};
        \node[anchor=south west] (B) at (A.east) {#2};
        \node[anchor=north west] (C) at (A.east) {#3};
        \node[inner sep=0pt, outer sep=0pt, draw, rounded corners, fit=(A)(B)(C)] (-box) {};
        \draw (B.north west) -- (C.south west)
              (B.south west) -- (C.north east);
        }
    }
}

\begin{tikzpicture}
\pic (a) {vhsplit={a}{2.0}{6.0}};
\pic[below=10mm of a-box.south] (b) {vhsplit={b}{-3.0}{-4.0}};
\end{tikzpicture}

\end{document}

Answer 1

圖片不像節點那麼聰明。圖片的原點始終放置在指定位置。

如果這就是您所需要的，那麼使用帶有 tabular節點內部的普通節點可能會更容易。以下是三種方法：

1. 普通文字和兩行一列的表格
   →vhsplit
2. 一張兩行兩列的表格，#1放在\multirow
   →vhsplit'
3. Arectangle split形狀從shapes.multipart庫中再次使用表格，如 1 所示
   。vhsplit''

由於表格的線條需要接觸節點的邊框，因此我將 s inner sep（預設為 0.3333em）設為零，並再次在適當的位置插入該空格。

左側部分的垂直放置有點可變，選擇最適合您的用例的一個（解決方案按此順序著色為紅色/綠色/藍色，並用 彼此疊放opacity=.3333）：

程式碼

\documentclass[tikz,border=2mm]{standalone}
\usepackage{hhline}
\usepackage{multirow}
\usetikzlibrary{positioning}
\tikzset{
  vhsplit/.style n args={3}{% text and a tabular
    shape=rectangle, draw, rounded corners, inner sep=+0pt,
    node contents={%
      \setlength{\tabcolsep}{.3333em}%
      \hspxsep#1\hspxsep
      \begin{tabular}{|l@{\hspxsep}}
        \vstysep$#2$\\\hhline{|-}
        \vstysep$#3$%
      \end{tabular}}},
  vhsplit'/.style n args={3}{
    shape=rectangle, draw, rounded corners, inner sep=+0pt,
    node contents={% multirow in a tabular
      \setlength{\tabcolsep}{.3333em}%
      \begin{tabular}{l|l@{\hspxsep}}
        \multirow{2}{*}{#1} &
        \vstysep$#2$\\\hhline{~|-}
        & \vstysep$#3$%
      \end{tabular}}}}
\usetikzlibrary{shapes.multipart}
\tikzset{
  vhsplit''/.style n args={3}{
    shape=rectangle split, rectangle split horizontal, rectangle split parts=2,
    draw, rounded corners, inner sep=+0pt,
    node contents={% two nodeparts and a tabular
      \hspxsep#1\hspxsep\null
      \nodepart{two}\setlength{\tabcolsep}{.3333em}%
      \begin{tabular}{l}
        \vstysep$#2$\\\hline
        \vstysep$#3$
      \end{tabular}}}}
\newcommand*\hspxsep{\hspace{.3333em}}
\newcommand*\vstysep{\rule{0pt}{1.0333em}}
\begin{document}
\begin{tikzpicture}
\node             (a) [vhsplit={a}{ 2.0} {6.0}];
\node[below=of a] (b) [vhsplit={b}{-3.0}{-4.0}];

\tikzset{xshift=2cm}
\node (a)         (a) [vhsplit'={a} {2.0} {6.0}];
\node[below=of a] (b) [vhsplit'={b}{-3.0}{-4.0}];

\tikzset{xshift=2cm}
\node             (a) [vhsplit''={a} {2.0} {6.0}];
\node[below=of a] (b) [vhsplit''={b}{-3.0}{-4.0}];
\end{tikzpicture}
\end{document}

輸出

Answer 2

嘗試這個：

\documentclass[tikz,border=2mm]{standalone}
\usetikzlibrary{positioning}
\usetikzlibrary{fit}
\begin{document}

    \tikzset{
        pics/vhsplit/.style n args = {3}{
            code = {
                \node (A) at (0,0) {#1};
                \node[anchor=south west] (B) at (A.east) {#2};
                \node[anchor=north west] (C) at (A.east) {#3};
                \node[inner sep=0pt, outer sep=0pt, draw, rounded corners, fit=(A)(B)(C)] (-box) {};
                \draw (B.north west) -- (C.south west)
                (B.south west) -- (C.north east);
            }
        }
    }

    \begin{tikzpicture}{scale=3} % <-- changed
        \pic (a) {vhsplit={a}{2.0}{6.0}};
        \pic[xshift=0cm,yshift=-1cm] (b) {vhsplit={b}{-3.0}{-4.0}};
    \end{tikzpicture}

\end{document}

輸出：
