LaTeX3 - 要重複使用的資料結構

LaTeX3 - 要重複使用的資料結構

我想儲存幾條數據,每種數據類型如下,以便我可以操縱它們進行格式化和計算。在使用者程式碼中分析的行數並不是預先固定的。

我已經製作了提取這些值的解析器。

LINE: 1
    CTXT: xvals
    LABEL: t
    VAL: 1, 20, 300, 4000

LINE: 2
    CTXT: imgs
    LABEL: f(t)
    VAL: a , b, bb, ccc, dddd

LINE: 3
    CTXT: imgs
    LABEL: g(t)
    VAL: U, V, VV, WWW, XXXX

我將在這種簡單的情況下產生以下輸出,請參見表格nicematrix,但這只是第一個功能。例如,我想計算f文檔後面的最大值。為此,我需要恢復上下文,imgs例如查找標籤f(t)及其關聯值。

\documentclass[11pt, a4paper]{article}

\usepackage{nicematrix}

\begin{document}

\section{What the user types}

\begin{verbatim}
\begin{functable}
    xvals =    t : 1 , 20 , 300 , 4000 ;
    imgs  = f(t) : a , bb , ccc , dddd ;
            g(t) : U , VV , WWW , XXXX
\end{functable}
\end{verbatim}


\section{What the user sees}

$\begin{NiceArray}[cell-space-limits = 3pt]{c*{4}{|c}}
    t    & 1 & 20 & 300 & 4000
\\ \hline
    f(t) & a & bb & ccc & dddd
\\ \hline
    g(t) & U & VV & VVV & WWW
\end{NiceArray}$


\section{What can be do after}

The user can ask for example to rebuild the 1st table
with something like this.

\begin{verbatim}
\begin{functable}[rebuild=1]
\end{functable}
\end{verbatim}

The user can also ask to calculate the maximum value
of $f(t)$ via something like \verb+\calcfunctable{max=f(t)}+.

\end{document}

我看到兩種可能性。

  1. 要么使用這個starray包,但我擔心這個項目不會長期維護。

  2. 或者我可以嘗試實作一個自製的解決方案,它看起來像一個屬性清單清單。

預期類似 JSON 的結構 [2024-03-09.v1]

這個想法是讓一個變數與每個表關聯,這個變數可以逐個字典迭代,對於由此獲得的每個字典,我們將可以存取不同類型的值。

[
    {
        'CTX'  : 'xvals',
        'VAL'  : ['1', '20', '300', '4000'],
        'LABEL': 't',
        'LINE' : '1'
    },
    {
        'CTX'  : 'imgs',
        'VAL'  : ['a' , 'b', 'bb', 'ccc', 'dddd'],
        'LABEL': 'f(t)',
        'LINE' : '2'
    },
    {
        'CTX'  : 'imgs',
        'VAL'  : ['U', 'V', 'VV', 'WWW', 'XXXX'],
        'LABEL': 'g(t)',
        'LINE' : '3'
    }
]

一些附加資訊 [2024-01-17.v1]

  1. 解析器給出l3-token 列表。

  2. 鍵的值VAL可以用作逗號分隔的列表,也可以用作L3函數的序列。第二個選擇應該會更好。

  3. 這些值將用於不同的情況,有時用於列印表格,有時用於執行計算。這應該類似於這個答案

簡化的概念驗證 [2024-03-09.v1]

\documentclass[12pt]{article}

\ExplSyntaxOn

% -- FUNCTABLE ENV. -- %

\NewDocumentEnvironment{ functable }{ b }{%
  \tns_functab_functable:n { #1 }
}{}


\cs_new:Npn \tns_functab_functable:n #1 {
  \tns_core_DSL_ctxt_parser:nn { functable } { #1 }

  \bigskip\par
  NEW ~ DATA ~ \int_use:N \g_tns_functab_id_int

  \par
  TODO
}


% -- DSL - L3 -- %

\tl_new:N   \g_tns_functab_semicolon_tl
\tl_gset:Nn \g_tns_functab_semicolon_tl { ; }

\tl_new:N   \g_tns_functab_colon_tl
\tl_gset:Nn \g_tns_functab_colon_tl { : }

\cs_generate_variant:Nn \seq_set_split:Nnn { NV }

\AtBeginDocument {
  \tl_gset_rescan:NnV \g_tns_functab_semicolon_tl
                      {}
                      \g_tns_functab_semicolon_tl

  \tl_gset_rescan:NnV \g_tns_functab_colon_tl
                      {}
                      \g_tns_functab_colon_tl
}


% :: AGNOSTIC PARSERS :: %

\int_new:N   \g_tns_functab_id_int
\int_gset:Nn \g_tns_functab_id_int { 0 }

\int_new:N \l_tns_core_ctxt_nb_line_int
\seq_new:N \l_tns_core_ctxts_seq
\tl_new:N  \l_tns_core_current_ctxt_tl


\cs_new:Npn \tns_core_DSL_ctxt_parser:nn #1#2 {
% The ID nb. of the env.
  \int_gincr:N \g_tns_functab_id_int

% Line by line parsing.
%
% Lines are semi-colon separated.
  \seq_set_split:NVn \l_tns_core_ctxts_seq
                      \g_tns_functab_semicolon_tl
                      { #2 }

  \int_zero:N \l_tns_core_ctxt_nb_line_int

  \seq_map_inline:Nn \l_tns_core_ctxts_seq {
    \bigskip\par

    \int_incr:N \l_tns_core_ctxt_nb_line_int

    Line ~ \int_use:N \l_tns_core_ctxt_nb_line_int
    \par

% Get the context and its content.
    \seq_set_split:Nnn \l_tmpa_seq { = } { ##1 }

    \int_set:Nn \l_tmpa_int {\seq_count:N \l_tmpa_seq}

    \quad
    \int_case:nnF { \int_use:N \l_tmpa_int } {
      { 1 } {
        LAST - CTXT: ~
        (\tl_use:N \l_tns_core_current_ctxt_tl)
      }
      { 2 } {
        \seq_pop_left:NN \l_tmpa_seq \l_tns_core_current_ctxt_tl

        NEW - CTXT: ~
        (\tl_use:N \l_tns_core_current_ctxt_tl)
      }
    }{
      ILLEGAL!
    }

% Get the optional label and its content.
    \seq_pop_left:NN \l_tmpa_seq \l_tmpa_tl

    \seq_set_split:NVV \l_tmpa_seq
                       \g_tns_functab_colon_tl
                       \l_tmpa_tl

    \int_set:Nn \l_tmpa_int {\seq_count:N \l_tmpa_seq}

    \par\quad
    \int_case:nnF { \int_use:N \l_tmpa_int } {
      { 1 } {
        NO LABEL
      }
      { 2 } {
        \seq_pop_left:NN \l_tmpa_seq \l_tmpa_tl

        LABEL: ~
        $(\tl_use:N \l_tmpa_tl)$
      }
    }{
      ILLEGAL!
    }

    \par\quad

    \seq_pop_left:NN \l_tmpa_seq \l_tmpa_tl

    VAL: ~
    $(\tl_use:N \l_tmpa_tl)$
  }
}

\ExplSyntaxOff


\begin{document}

\begin{functable}
    xvals =    t : 1 , 20 , 300 , 4000 ;
    imgs  = f(t) : a , bb , ccc , dddd ;
            g(t) : U , VV , WWW , XXXX
\end{functable}

\end{document}

答案1

更新

代碼分為環境savefunctable和命令\usefunctable。兩者都將名稱作為第一個參數。環境的內容savefunctable儲存在內部,稍後可以\usefunctable透過指定適當的名稱與命令一起使用。

在此輸入影像描述

\documentclass[border=6pt,varwidth]{standalone}
\usepackage{nicematrix}
\usepackage{pgfplots}
\pgfplotsset{compat=1.18}
\ExplSyntaxOn
\cs_generate_variant:Nn \seq_map_indexed_inline:Nn { cn }
\cs_generate_variant:Nn \seq_gset_from_clist:Nn { ce }
\seq_new:N \l__projetmbc_functable_seq
\seq_new:N \l__projetmbc_key_name_list_seq
\tl_new:N \l__projetmbc_coordinates_tl
\tl_new:N \l__projetmbc_key_tl
\tl_new:N \l__projetmbc_name_tl
\NewDocumentEnvironment { savefunctable } { m +b }
  {
    \seq_set_split:Nnn \l__projetmbc_functable_seq { ; } {#2}
    \seq_map_inline:Nn \l__projetmbc_functable_seq
      {
        \seq_set_split:Nnn \l__projetmbc_key_name_list_seq { = } {##1}
        \int_compare:nNnT { \seq_count:N \l__projetmbc_key_name_list_seq } = { 2 }
          {
            \seq_pop_left:NN \l__projetmbc_key_name_list_seq \l__projetmbc_key_tl
            \seq_gclear_new:c { g__projetmbc_#1_key_\l__projetmbc_key_tl _seq }
          }
        \seq_set_split:Nee \l__projetmbc_key_name_list_seq { \c_colon_str } { \seq_item:Nn \l__projetmbc_key_name_list_seq { 1 } }
        \seq_pop_left:NN \l__projetmbc_key_name_list_seq \l__projetmbc_name_tl
        \seq_gput_right:cV { g__projetmbc_#1_key_\l__projetmbc_key_tl _seq } \l__projetmbc_name_tl
        \seq_gclear_new:c { g__projetmbc_#1_key_\l__projetmbc_key_tl _name_\l__projetmbc_name_tl _seq }
        \seq_gset_from_clist:ce { g__projetmbc_#1_key_\l__projetmbc_key_tl _name_\l__projetmbc_name_tl _seq } { \seq_item:Nn \l__projetmbc_key_name_list_seq { 1 } }
      }
  }
  {}
\NewDocumentCommand \usefunctable { m m }
  {
    \str_case:nnF {#2}
      {
        { list~of~imgs }
          {
            \seq_use:cn { g__projetmbc_#1_key_imgs_seq } { , ~ }
          }
        { maximum~of~xvals }
          {
            \fp_eval:n { max ( \seq_use:cn { g__projetmbc_#1_key_xvals_name_\seq_item:cn { g__projetmbc_#1_key_xvals_seq } { 1 }_seq } { , } ) }
          }
        { NiceArray }
          {
            $
              \begin { NiceArray }
                [ cell-space-limits = 3pt ]
                { c * { \seq_count:c { g__projetmbc_#1_key_xvals_name_\seq_item:cn { g__projetmbc_#1_key_xvals_seq } { 1 }_seq } } { | c } }
                \seq_item:cn { g__projetmbc_#1_key_xvals_seq } { 1 } & \seq_use:cn { g__projetmbc_#1_key_xvals_name_\seq_item:cn { g__projetmbc_#1_key_xvals_seq } { 1 }_seq } { & } \\ \hline
                \seq_map_indexed_inline:cn { g__projetmbc_#1_key_imgs_seq }
                  {
                    ##2 & \seq_use:cn { g__projetmbc_#1_key_imgs_name_##2_seq } { & }
                    \int_compare:nNnF {##1} = { \seq_count:c { g__projetmbc_#1_key_imgs_seq } }
                      { \\ \hline }
                  }
              \end { NiceArray }
            $
          }
        { plot }
          {
            \tl_build_begin:N \l__projetmbc_coordinates_tl
            \seq_map_indexed_inline:cn { g__projetmbc_#1_key_xvals_name_\seq_item:cn { g__projetmbc_#1_key_xvals_seq } { 1 }_seq }
              {
                \tl_build_put_right:Ne \l__projetmbc_coordinates_tl
                  { ( ##2 , \seq_item:cn { g__projetmbc_#1_key_imgs_name_\seq_item:cn { g__projetmbc_#1_key_imgs_seq } { 1 }_seq } {##1} ) }
              }
            \tl_build_end:N \l__projetmbc_coordinates_tl
            \begin { tikzpicture }
              \begin { axis }
                [
                  ymin = 0
                ]
                \addplot coordinates
                  { \l__projetmbc_coordinates_tl }
                ;
              \end { axis }
            \end { tikzpicture }
          }
      }
      { \errmessage { wrong~option~for~functable~environment } }
  }
\ExplSyntaxOff
\begin{document}
\begin{savefunctable}{example 1}
    xvals =    t : 1 , 20 , 300 , 4000 ;
    imgs  = f(t) : a , bb , ccc , dddd ;
            g(t) : U , VV , WWW , XXXX
\end{savefunctable}
\begin{savefunctable}{example 2}
    xvals =    t : 1 , 2 , 3 , 4 ;
    imgs  = f(t) : 8 , 5 , 7 , 6 ;
\end{savefunctable}

Using \texttt{example 1} with \texttt{NiceArray}: \usefunctable{example 1}{NiceArray}

The maximum of the \texttt{xvals} of \texttt{example 2}: \usefunctable{example 2}{maximum of xvals}

The list of \texttt{imgs} of \texttt{example 1}: \usefunctable{example 1}{list of imgs}

A \texttt{plot} for \texttt{example 2}: \usefunctable{example 2}{plot}
\end{document}

原答案

functable定義了一個環境。它需要一個強制參數,然後是正文。

身體首先被;分裂\seq_set_split:Nnn。然後項目被拆分=。諸如xvals或 之類的密鑰imgs儲存在 中\l__projetmbc_key_tl

t類似地,諸如或 之類的名稱f(t)儲存在 中\l__projetmbc_name_tl

環境functable取決於第一個強制參數。以下是NiceArraymaximum of xvalslist of imgs的範例plot

在此輸入影像描述

\documentclass[border=6pt,varwidth]{standalone}
\usepackage{nicematrix}
\usepackage{pgfplots}
\pgfplotsset{compat=1.18}
\ExplSyntaxOn
\cs_generate_variant:Nn \seq_map_indexed_inline:Nn { cn }
\cs_generate_variant:Nn \seq_set_from_clist:Nn { ce }
\seq_new:N \l__projetmbc_functable_seq
\seq_new:N \l__projetmbc_key_name_list_seq
\tl_new:N \l__projetmbc_coordinates_tl
\tl_new:N \l__projetmbc_key_tl
\tl_new:N \l__projetmbc_name_tl
\NewDocumentEnvironment { functable } { m +b }
  {
    \seq_set_split:Nnn \l__projetmbc_functable_seq { ; } {#2}
    \seq_map_inline:Nn \l__projetmbc_functable_seq
      {
        \seq_set_split:Nnn \l__projetmbc_key_name_list_seq { = } {##1}
        \int_compare:nNnT { \seq_count:N \l__projetmbc_key_name_list_seq } = { 2 }
          {
            \seq_pop_left:NN \l__projetmbc_key_name_list_seq \l__projetmbc_key_tl
            \seq_clear_new:c { l__projetmbc_key_\l__projetmbc_key_tl _seq }
          }
        \seq_set_split:Nee \l__projetmbc_key_name_list_seq { \c_colon_str } { \seq_item:Nn \l__projetmbc_key_name_list_seq { 1 } }
        \seq_pop_left:NN \l__projetmbc_key_name_list_seq \l__projetmbc_name_tl
        \seq_put_right:cV { l__projetmbc_key_\l__projetmbc_key_tl _seq } \l__projetmbc_name_tl
        \seq_clear_new:c { l__projetmbc_key_\l__projetmbc_key_tl _name_\l__projetmbc_name_tl _seq }
        \seq_set_from_clist:ce { l__projetmbc_key_\l__projetmbc_key_tl _name_\l__projetmbc_name_tl _seq } { \seq_item:Nn \l__projetmbc_key_name_list_seq { 1 } }
      }
    \str_case:nnF {#1}
      {
        { list~of~imgs }
          {
            \seq_use:Nn \l__projetmbc_key_imgs_seq { , ~ }
          }
        { maximum~of~xvals }
          {
            \fp_eval:n { max ( \seq_use:cn { l__projetmbc_key_xvals_name_\seq_item:Nn \l__projetmbc_key_xvals_seq { 1 }_seq } { , } ) }
          }
        { NiceArray }
          {
            $
              \begin { NiceArray }
                [ cell-space-limits = 3pt ]
                { c * { \seq_count:c { l__projetmbc_key_xvals_name_\seq_item:Nn \l__projetmbc_key_xvals_seq { 1 }_seq } } { | c } }
                \seq_item:Nn \l__projetmbc_key_xvals_seq { 1 } & \seq_use:cn { l__projetmbc_key_xvals_name_\seq_item:Nn \l__projetmbc_key_xvals_seq { 1 }_seq } { & } \\ \hline
                \seq_map_indexed_inline:Nn \l__projetmbc_key_imgs_seq
                  {
                    ##2 & \seq_use:cn { l__projetmbc_key_imgs_name_##2_seq } { & }
                    \int_compare:nNnF {##1} = { \seq_count:N \l__projetmbc_key_imgs_seq }
                      { \\ \hline }
                  }
              \end { NiceArray }
            $
          }
        { plot }
          {
            \tl_build_begin:N \l__projetmbc_coordinates_tl
            \seq_map_indexed_inline:cn { l__projetmbc_key_xvals_name_\seq_item:Nn \l__projetmbc_key_xvals_seq { 1 }_seq }
              {
                \tl_build_put_right:Ne \l__projetmbc_coordinates_tl
                  { ( ##2 , \seq_item:cn { l__projetmbc_key_imgs_name_\seq_item:Nn \l__projetmbc_key_imgs_seq { 1 }_seq } {##1} ) }
              }
            \tl_build_end:N \l__projetmbc_coordinates_tl
            \begin { tikzpicture }
              \begin { axis }
                [
                  ymin = 0
                ]
                \addplot coordinates
                  { \l__projetmbc_coordinates_tl }
                ;
              \end { axis }
            \end { tikzpicture }
          }
      }
      { \errmessage { wrong~option~for~functable~environment } }
  }
  {}
\ExplSyntaxOff
\begin{document}
Using \texttt{NiceArray}:

\begin{functable}{NiceArray}
    xvals =    t : 1 , 20 , 300 , 4000 ;
    imgs  = f(t) : a , bb , ccc , dddd ;
            g(t) : U , VV , WWW , XXXX
\end{functable}

The maximum of the \texttt{xvals}:
\begin{functable}{maximum of xvals}
    xvals =    t : 1 , 20 , 300 , 4000 ;
    imgs  = f(t) : a , bb , ccc , dddd ;
            g(t) : U , VV , WWW , XXXX
\end{functable}

The list of \texttt{imgs}:
\begin{functable}{list of imgs}
    xvals =    t : 1 , 20 , 300 , 4000 ;
    imgs  = f(t) : a , bb , ccc , dddd ;
            g(t) : U , VV , WWW , XXXX
\end{functable}

A plot:
\begin{functable}{plot}
    xvals =    t : 1 , 2 , 3 , 4 ;
    imgs  = f(t) : 8 , 5 , 7 , 6 ;
\end{functable}
\end{document}
