tikz圖片不適合文檔

Question

我有一個程式碼，我使用一些範圍來繪製一些 3D 圖形。
但輸出不適合獨立文檔。
\hbox{*}並\vbox{*}沒有幫助。

我需要做什麼？

應該看起來像這樣：

\documentclass[margin=5pt]{standalone}
%\documentclass{article}
%\usepackage[margin=15mm]{geometry}
\usepackage{tikz}

\begin{document}

\def\a{1}
\def\h{0.2}
%%%%%%%%%%%%%%%%%%%%%%%%%%
\hbox{\vbox{%%%%%%%%%%%%%%%%%%%%
%%%%%%%%%%%%%%%%%%%%%%%%%%

\begin{tikzpicture}[font=\footnotesize,
very thin,
%line cap=round,
x={(1,0,0)}, z={(0,1,0)}, y={(0.5,0.5)},
every label/.style={text=black!1},
]

\coordinate[label=below:A] (A1) at (0,0,0);
\coordinate[label=below:B] (B1) at (\a,0,0);
\coordinate[label=below:C] (C1) at (\a,\a,0);
\coordinate[label=below:D] (D1) at (0,\a,0);
\coordinate[label=below:A] (A2) at (0,0,\h);
\coordinate[label=below:B] (B2) at (\a,0,\h);
\coordinate[label=below:C] (C2) at (\a,\a,\h);
\coordinate[label=below:D] (D2) at (0,\a,\h);

%% straight %%%%%%%%%%%%%%%%%%%%%
\foreach \n in {0,...,9}{%%
\begin{scope}[transform canvas={shift={(0,0,\n*\h)}}]
\draw[] (A1) -- (B1) -- (C1);

\ifnum\n=9 \draw[fill=white] (A2) -- (B2) -- (C2) -- (D2) --cycle;
\else \draw[fill=white] (A2) -- (B2) -- (C2);  \fi
\foreach \P in {A,B,C} \draw[] (\P1) -- (\P2);
\end{scope}
}%%

%% skew  %%%%%%%%%%%%%%%%%%%%%
\begin{scope}[transform canvas={shift={(12*\h+\a,0,0)}}]
\foreach \n in {0,...,9}{%%
\begin{scope}[transform canvas={shift={(-\n*\h,0,\n*\h)}}]
\draw[] (A1) -- (B1) -- (C1);

\ifnum\n=9 \draw[fill=white] (A2) -- (B2) -- (C2) -- (D2) --cycle;
\else \draw[fill=white] (A2) -- (B2) -- (C2) -- (D2);  \fi
\foreach \P in {A,B,C}{  \draw[] (\P1) -- (\P2);  }
\draw[fill=white] (B1) -- (C1) -- (C2) -- (B2) --cycle;
\end{scope}
}%%
\end{scope}
\end{tikzpicture}

%%%%%%%%%%%%%%%%%%%%%%%%%%
}}%%%%%%%%%%%%%%%%%%%%%%%%%
%%%%%%%%%%%%%%%%%%%%%%%%%%
\end{document}

Answer 1

這是一種避免transform canvas每次使用座標時添加變換的方法。

\documentclass[margin=5pt]{standalone}
\usepackage{tikz}
% ateb: https://tex.stackexchange.com/a/707241/ addaswyd o gwestiwn cis: https://tex.stackexchange.com/q/707215/
\begin{document}

\begin{tikzpicture}[font=\footnotesize,
    very thin,
    x={(1,0,0)}, z={(0,1,0)}, y={(0.5,0.5)},
  ]
  \def\a{1}
  \def\h{0.2}
  \def\makecoords{%
    \coordinate (A1) at (0,0,0);
    \coordinate (B1) at (\a,0,0);
    \coordinate (C1) at (\a,\a,0);
    \coordinate (D1) at (0,\a,0);
    \coordinate (A2) at (0,0,\h);
    \coordinate (B2) at (\a,0,\h);
    \coordinate (C2) at (\a,\a,\h);
    \coordinate (D2) at (0,\a,\h);}
  %% straight %%%%%%%%%%%%%%%%%%%%%
  \foreach \n in {0,...,9}{%%
    \begin{scope}[shift={(0,0,\n*\h)}]
      \makecoords
      \draw (A1) -- (B1) -- (C1);
      \ifnum\n=9 \draw[fill=white] (A2) -- (B2) -- (C2) -- (D2) -- cycle;
      \else \draw[fill=white] (A2) -- (B2) -- (C2);  \fi
      \foreach \P in {A,B,C} \draw[] (\P1) -- (\P2);
    \end{scope}
  }
  %% skew  %%%%%%%%%%%%%%%%%%%%%
  \begin{scope}[shift={(12*\h+\a,0,0)}]
    \foreach \n in {0,...,9}{%%
      \begin{scope}[shift={(-\n*\h,0,\n*\h)}]
        \makecoords
        \draw[] (A1) -- (B1) -- (C1);
        \ifnum\n=9 \draw[fill=white] (A2) -- (B2) -- (C2) -- (D2) --cycle;
        \else \draw[fill=white] (A2) -- (B2) -- (C2) -- (D2);  \fi
        \foreach \P in {A,B,C}{  \draw[] (\P1) -- (\P2);  }
        \draw[fill=white] (B1) -- (C1) -- (C2) -- (B2) --cycle;
      \end{scope}
    }
  \end{scope}
\end{tikzpicture}
\end{document}

我不確定\vboxin an 的\hbox用途，所以我將其刪除，因為它似乎沒有任何功能。
