我可以將 pgfplots 中的節點錨定到哪些實體？

Question

我發現很難閱讀pgfplots 手冊，我可以參考哪些實體，例如具有更多資訊的錨節點。

例如，在下面的範例中，我可以引用哪些部分或全部實體？

\documentclass[10pt,border=3mm,tikz]{standalone}
\usepackage{pgfplots}

\begin{document}
 \begin{tikzpicture}
    \begin{axis}[
        title=hello,
        xlabel=x,
     ]
        \addplot[domain=-1:1]   {(x-.2)^3 + 1};

        \addplot[domain=-1:1]   {x+1.5};
    \end{axis}
 \end{tikzpicture}
\end{document}

Answer 1

簡而言之，您至少可以參考：

• 實體，您可以透過命名name=
• 預定義實體，例如current axis和current plot begincurrent plot end

請參閱下面的範例。筆記節點的順序和位置可能是相關的，請參閱current plot ...範例。筆記與節點一起使用的不同樣式選項。我建議在中查找更多詳細信息pgfplots-手冊。

% ~~~ 10.04.2024: Where can I name things like a node? ~~~~~~~~~

\documentclass[10pt,border=3mm,tikz]{standalone}
\usepackage{pgfplots}

\begin{document}
 \begin{tikzpicture}
    \begin{axis}[
        name=AX,                    % <<<
        title=hello,                % not here
        title style={name=TS},      % <<<
        xlabel=x,                   % not here
        xlabel style={name=XL},     % <<<
        ylabel=y,                   % not here
        ylabel style={name=YL},     % <<<
     ]
     \addplot[
        domain=-1:1,
        %name path=CRV, % needs fill between
        %name=AP,       % no
     ]{(x-.2)^3 + 1};

     \addplot[domain=-1:1,]{x+1.5};

    \end{axis}

    % ~~~ current axis ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    \node[anchor=west,red,circle,draw]  at (current axis.east)  {CA};

    % ~~~ current plot ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    \node[red,circle,draw]              at (current plot begin) {CPb};
    \node[red,circle,draw]              at (current plot end)   {CPe};

    % ~~~ named axis, see above ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    \node[anchor=west,teal]     at (AX.south east)      {AX};
    \node[anchor=east,teal]     at (AX.north west)      {AX};
    \node[teal]                 at (AX.outer north west){AX};
    \node[teal]                 at (AX.origin)          {AXorg};
    \node[teal]                 at (AX.center)          {AXcnt};

    % ~~~ named styles ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
    \node[anchor=west,purple,draw]  at (TS.east)    {TS};
    \node[anchor=west,purple,draw]  at (XL.east)    {XL};
    \node[anchor=west,purple,draw]  at (YL.east)    {YL};
 \end{tikzpicture}
\end{document}
