cref 方程式的不同顏色

cref 方程式的不同顏色

我正在研究一些方程式,並希望將它們設置為與我在\hypersetup.現在看來,這郵政做我正在尋找的事情,如果不是為了排除方程式 ()部分連結仍保持原始顏色設定\hypersetup

有沒有辦法讓整個文字變成青色(或任何其他顏色)?提前致謝,以下是 MWE 和相關輸出:

\documentclass[12pt]{report}


\usepackage[letterpaper,margin=1in]{geometry}
\usepackage[utf8]{inputenc}
\usepackage[T1]{fontenc}
\usepackage{subcaption}
\usepackage{caption}
\usepackage{amsmath}
\usepackage{xcolor}
\usepackage{float}

\usepackage{hyperref}

\hypersetup{
    colorlinks,
    citecolor=electricultramarine,
    filecolor=.,
    linkcolor=maroon,
    urlcolor=smokyblack,
    linktoc=all
}
\definecolor{teal}{rgb}{0.0, 0.5, 0.5}
\definecolor{cobalt}{rgb}{0.0, 0.28, 0.67}
\definecolor{maroon}{rgb}{0.69, 0.19, 0.38}
\definecolor{coolblack}{rgb}{0.0, 0.18, 0.39}
\definecolor{lightgray}{rgb}{0.83, 0.83, 0.83}
\definecolor{smokyblack}{rgb}{0.06, 0.05, 0.03}
\definecolor{ceruleanblue}{rgb}{0.16, 0.32, 0.75}
\definecolor{electricultramarine}{rgb}{0.25, 0.0, 1.0}

\usepackage[noabbrev,nameinlink]{cleveref}
\crefname{subsection}{subsection}{subsections}
\creflabelformat{equation}{#2\textup{(\textcolor{teal}{#1})}#3}

\begin{document}
\chapter{Methods}
\dots
\section{Population genetics and Demographic Inference}
\dots
\subsection{PCA and other exploratory population genetic analyses} \label{exploratory}

This is the method subsection for exploratory analyses.

\chapter{Results}
\dots
\section{Exploratory population genetics analyses}

\dots This value, known as Watterson estimator (or $\theta$ Watterson) <citation>, is expressed by the following equation with the number of polymorphic sites set as K:
\begin{equation} \label{equation:1}
\widehat{\theta}_w = \frac{K}{a_n} \text{, with } a_n = \sum_{i=1}^{n-1} \frac{1}{i}
\end{equation}

When I use a normal \texttt{cleveref} I get the expected output in: \textbf{\Cref{exploratory}}; on the other hand, even following the example in the post, I cannot get rid of the maroon hyperlink color for the equation and brackets part of the text when linking an equation: \textbf{\cref{equation:1}}.

\end{document}

在此輸入影像描述

答案1

使用\crefformat帶有前綴的整個參考,而不僅僅是標籤:

\documentclass[12pt]{report}

\usepackage[letterpaper,margin=1in]{geometry}
\usepackage[utf8]{inputenc}
\usepackage[T1]{fontenc}
\usepackage{subcaption}
\usepackage{caption}
\usepackage{amsmath}
\usepackage{xcolor}
\usepackage{float}

\usepackage{hyperref}

\hypersetup{
    colorlinks,
    citecolor=electricultramarine,
    filecolor=.,
    linkcolor=maroon,
    urlcolor=smokyblack,
    linktoc=all
}
\definecolor{teal}{rgb}{0.0, 0.5, 0.5}
\definecolor{cobalt}{rgb}{0.0, 0.28, 0.67}
\definecolor{maroon}{rgb}{0.69, 0.19, 0.38}
\definecolor{coolblack}{rgb}{0.0, 0.18, 0.39}
\definecolor{lightgray}{rgb}{0.83, 0.83, 0.83}
\definecolor{smokyblack}{rgb}{0.06, 0.05, 0.03}
\definecolor{ceruleanblue}{rgb}{0.16, 0.32, 0.75}
\definecolor{electricultramarine}{rgb}{0.25, 0.0, 1.0}

\usepackage[noabbrev,nameinlink]{cleveref}
\crefname{subsection}{subsection}{subsections}
\crefformat{equation}{\textcolor{teal}{equation~#2\textcolor{teal}{(#1)}#3}}

\begin{document}
\chapter{Methods}
\dots
\section{Population genetics and Demographic Inference}
\dots
\subsection{PCA and other exploratory population genetic analyses} \label{exploratory}

This is the method subsection for exploratory analyses.

\chapter{Results}
\dots
\section{Exploratory population genetics analyses}

\dots This value, known as Watterson estimator (or $\theta$ Watterson) <citation>, is expressed by the following equation with the number of polymorphic sites set as K:
\begin{equation} \label{equation:1}
\widehat{\theta}_w = \frac{K}{a_n} \text{, with } a_n = \sum_{i=1}^{n-1} \frac{1}{i}
\end{equation}

When I use a normal \texttt{cleveref} I get the expected output in: \textbf{\Cref{exploratory}}; o[![enter image description here][1]][1]n the other hand, even following the example in the post, I cannot get rid of the maroon hyperlink color for the equation and brackets part of the text when linking an equation: \textbf{\cref{equation:1}}.

\end{document}

在此輸入影像描述

外部\textcolor更改了整體顏色,但這會被和hyperref生成的連結覆蓋。要再次變更該顏色,還需要和之間的內部顏色。前綴和連結之間有一個不可分割的空格。#2#3\textcolor#2#3~

如果您希望前綴成為連結的一部分,您可以使用:

\crefformat{equation}{#2\textcolor{teal}{equation~(#1)}#3}

cleveref有關工作原理的更多信息,請參閱手冊\crefformat
