使用與列寬度相符的自訂底線將表格條目置中

我有一個包含 3 列的簡單表格，我將其用作資料標題。我定義了一個自訂底線規則（具有自訂厚度、顏色和深度），用於為每個表條目添加下劃線。

我正在使用的標記是：

\documentclass[letterpaper,11pt]{article}
\usepackage{kpfonts}
\RequirePackage{fix-cm}
\setlength{\parskip}{\baselineskip}%
\setlength{\parindent}{0pt}%
\usepackage{xcolor}
\definecolor{smokyblack}{rgb}{0.06, 0.05, 0.03}
\definecolor{mygrey}{rgb}{0.1, 0.14, 0.12}
\definecolor{darkjunglegreen}{rgb}{0.0, 0.26, 0.15}
\usepackage[
top    = 0.608cm,
bottom = 1.1cm,
left   = 1.20cm,
right  = 1.10cm]{geometry}
\usepackage{titlesec}
\usepackage{ulem}
\renewcommand{\ULdepth}{5.8pt}
\renewcommand{\ULthickness}{1.35pt}
\makeatletter
\newcommand\semiLarge{\@setfontsize\semiLarge{13.22}{17.38}}
\makeatother
\newcommand{\greenuline}[1]{{\color{darkjunglegreen}\uline{{\color{black}#1}}}}
\titleformat{\section}
{\normalfont\Large\bfseries}{\thesection}
{1em}{}[\color{darkjunglegreen}{\titlerule[2pt]}]
\titlespacing\section{0pt}{1pt plus 4pt minus 2pt}{-3pt plus 2pt minus 2pt}

\begin{document}
\sloppy
\begin{tabular*}{\linewidth}{@{}l@{\extracolsep{\fill}}r@{}}
\textbf{\LARGE \textcolor{mygrey}{REAL NAME}}  & \large{[email protected]}\\
\colorbox{mygrey!11}{\textbf{\semiLarge \textcolor{smokyblack}{Employed Professional}}} &  \large{555-555-5555 - New York, NY}
\end{tabular*}

\section*{Section Heading}

\begin{tabular} {@{}p{6cm} p{8cm} p{7cm}}
\large{\textbf{\greenuline{Category}}} & \large{\textbf{\greenuline{Word}}} & \large{\textbf{\greenuline{Much Longer word}}}
\end{tabular}

\end{document}

它產生如下所示的輸出：

在此輸入影像描述

目前一切都如預期進行。我想將每個表格條目放在列中居中，並讓下劃線規則填入表格列的寬度，如下圖所示：

在此輸入影像描述

這個問題最簡單的解決方案是什麼？

答案1

\cmidrule使用套件中的幫助booktabs並tabular*確保表格保持在文字寬度內。可使用可選參數 來控制線條粗細\cmidrule。

在此輸入影像描述

\documentclass[letterpaper,11pt]{article}
\usepackage{kpfonts}
\RequirePackage{fix-cm}
\setlength{\parskip}{\baselineskip}%
\setlength{\parindent}{0pt}%
\usepackage[table]{xcolor}
\definecolor{smokyblack}{rgb}{0.06, 0.05, 0.03}
\definecolor{mygrey}{rgb}{0.1, 0.14, 0.12}
\definecolor{darkjunglegreen}{rgb}{0.0, 0.26, 0.15}
\usepackage[
top    = 0.608cm,
bottom = 1.1cm,
left   = 1.20cm,
right  = 1.10cm]{geometry}
\usepackage{titlesec}
\usepackage{ulem}
\renewcommand{\ULdepth}{5.8pt}
\renewcommand{\ULthickness}{1.35pt}
\makeatletter
\newcommand\semiLarge{\@setfontsize\semiLarge{13.22}{17.38}}
\makeatother
\newcommand{\greenuline}[1]{{\color{darkjunglegreen}\uline{{\color{black}#1}}}}
\titleformat{\section}
{\normalfont\Large\bfseries}{\thesection}
{1em}{}[\color{darkjunglegreen}{\titlerule[2pt]}]
\titlespacing\section{0pt}{1pt plus 4pt minus 2pt}{-3pt plus 2pt minus 2pt}

\usepackage{booktabs}
\usepackage{array}
\usepackage{calc}
\newcolumntype{C}[1]{>{\centering\arraybackslash}p{#1}}
\begin{document}
\sloppy
\begin{tabular*}{\linewidth}{@{}l@{\extracolsep{\fill}}r@{}}
\textbf{\LARGE \textcolor{mygrey}{REAL NAME}}  & \large{[email protected]}\\
\colorbox{mygrey!11}{\textbf{\semiLarge \textcolor{smokyblack}{Employed Professional}}} &  \large{555-555-5555 - New York, NY}
\end{tabular*}

\section*{Section Heading}
\arrayrulecolor{darkjunglegreen}

\begin{tabular*}{\textwidth}{@{\extracolsep{\fill}}*{3}{C{0.3\textwidth-2\tabcolsep}}}
\large\textbf{Category} & \large\textbf{Word} & \large\textbf{Much Longer word}\\
\cmidrule[1pt](r){1-1} \cmidrule[1pt](lr){2-2} \cmidrule[1pt](l){3-3}
\end{tabular*}

\end{document}

答案2

可以使用 來設定寬度，而不是使用 p 列\makebox。

BTW<\large沒有參數。它是一個開關，應該放在大括號內。

\documentclass[letterpaper,11pt]{article}
\usepackage{kpfonts}
\RequirePackage{fix-cm}
\setlength{\parskip}{\baselineskip}%
\setlength{\parindent}{0pt}%
\usepackage{xcolor}
\definecolor{smokyblack}{rgb}{0.06, 0.05, 0.03}
\definecolor{mygrey}{rgb}{0.1, 0.14, 0.12}
\definecolor{darkjunglegreen}{rgb}{0.0, 0.26, 0.15}
\usepackage[
top    = 0.608cm,
bottom = 1.1cm,
left   = 1.20cm,
right  = 1.10cm]{geometry}
\usepackage{titlesec}
\usepackage{ulem}
\renewcommand{\ULdepth}{5.8pt}
\renewcommand{\ULthickness}{1.35pt}
\makeatletter
\newcommand\semiLarge{\@setfontsize\semiLarge{13.22}{17.38}}
\makeatother
\newcommand{\greenuline}[1]{{\color{darkjunglegreen}\uline{{\color{black}#1}}}}
\titleformat{\section}
{\normalfont\Large\bfseries}{\thesection}
{1em}{}[\color{darkjunglegreen}{\titlerule[2pt]}]
\titlespacing\section{0pt}{1pt plus 4pt minus 2pt}{-3pt plus 2pt minus 2pt}

\begin{document}
\sloppy
\begin{tabular*}{\linewidth}{@{}l@{\extracolsep{\fill}}r@{}}
\textbf{\LARGE \textcolor{mygrey}{REAL NAME}}  & \large{[email protected]}\\
\colorbox{mygrey!11}{\textbf{\semiLarge \textcolor{smokyblack}{Employed Professional}}} &  \large{555-555-5555 - New York, NY}
\end{tabular*}

\section*{Section Heading}

\begin{tabular*}{\textwidth} {@{\extracolsep{\fill}}lll@{}}
\textbf{\large\greenuline{\makebox[6cm]{Category}}} & \textbf{\large\greenuline{\makebox[6cm]{Word}}}
  & \textbf{\large\greenuline{\makebox[6cm]{Much Longer word}}}
\end{tabular*}

\end{document}
