pgfplotstable：在保持樣式的同時變更字串類型儲存格內容的顏色

擴展所涵蓋的主題pgfplotstable：如何在保持樣式的同時變更儲存格內容的顏色？，正確解決了@弗魯岡，我需要更改中單一單元格的顏色string style，我siunitx在string styleusing中使用對數字進行舍入type column={S}。

\documentclass{scrbook}
\usepackage[table]{xcolor}
\usepackage{pgfplotstable}
\usepackage{booktabs}
\usepackage{siunitx}
\sisetup{
  round-mode          = places,
  round-precision     = 2, % precisión
}

\begin{filecontents*}{my-data.csv}
c1     & c2      & c3
Story4 & 33.7835 & 33.7878
Story3 & 38.4334 & 38.4334
Story2 & 37.7156 & 37.7156
Story1 & 38.4056 & 38.4034
\end{filecontents*}

\pgfplotstableread[col sep=&]{my-data.csv}\myLoadedTable

\begin{document}

\begin{table}
\pgfplotstabletypeset[
            display columns/0/.style={column type={c},
                column name=\textbf{$Story$}, string type},
            display columns/1/.style={column type={S},
                column name=\textbf{$U_x$}, string type},
            display columns/2/.style={column type={S},
                column name=\textbf{$U_y$},string type},
            every head row/.style={before row={\toprule},after row=\midrule},
        every last row/.style={after row={\bottomrule}},
            my special cell/.style={@cell content=\textcolor{blue}{#1}},
            every row 3 column 2/.append style={
            postproc cell content/.append style={
            my special cell/.expanded={%
            \pgfkeysvalueof{/pgfplots/table/@cell content}%
            },
            },
        },]{\myLoadedTable}
\end{table}

\end{document}

當更改單元格的樣式時，舍入不再起作用，我得到：

答案1

您所需要做的就是使用my special cell/.style={@cell content=\color{blue}#1}.

\documentclass{scrbook}
\usepackage[table]{xcolor}
\usepackage{pgfplotstable}
\usepackage{booktabs}
\usepackage{siunitx}
\sisetup{
  round-mode          = places,
  round-precision     = 2, % precisión
}

\begin{filecontents*}{my-data.csv}
c1     & c2      & c3
Story4 & 33.7835 & 33.7878
Story3 & 38.4334 & 38.4334
Story2 & 37.7156 & 37.7156
Story1 & 38.4056 & 38.4034
\end{filecontents*}

\pgfplotstableread[col sep=&]{my-data.csv}\myLoadedTable

\begin{document}

\begin{table}
\pgfplotstabletypeset[
            display columns/0/.style={column type={c},
                column name=\textbf{$Story$}, string type},
            display columns/1/.style={column type={S},
                column name=\textbf{$U_x$}, string type},
            display columns/2/.style={column type={S},
                column name=\textbf{$U_y$},string type},
            every head row/.style={before row={\toprule},after row=\midrule},
        every last row/.style={after row={\bottomrule}},
            my special cell/.style={@cell content=\color{blue}#1},
            every row 3 column 2/.append style={
            postproc cell content/.append style={
            my special cell/.expanded={%
            \pgfkeysvalueof{/pgfplots/table/@cell content}%
            },
            },
        },]{\myLoadedTable}
\end{table}

\end{document}

在此輸入影像描述

附錄：如果你想玩弄字體粗細等等，你可能要指示siunitx不要忽略你。一種方法是將選項新增detect-all=true至\sisetup.

\documentclass{scrbook}
\usepackage[table]{xcolor}
\usepackage{pgfplotstable}
\usepackage{booktabs}
\usepackage{siunitx}
\sisetup{
  round-mode          = places,
  round-precision     = 2, % precisión
  detect-all=true
}

\begin{filecontents*}{my-data.csv}
c1     & c2      & c3
Story4 & 33.7835 & 33.7878
Story3 & 38.4334 & 38.4334
Story2 & 37.7156 & 37.7156
Story1 & 38.4056 & 38.4034
\end{filecontents*}

\pgfplotstableread[col sep=&]{my-data.csv}\myLoadedTable

\begin{document}

\begin{table}
\pgfplotstabletypeset[
            display columns/0/.style={column type={c},
                column name=\textbf{$Story$}, string type},
            display columns/1/.style={column type={S},
                column name=\textbf{$U_x$}, string type},
            display columns/2/.style={column type={S},
                column name=\textbf{$U_y$},string type},
            every head row/.style={before row={\toprule},after row=\midrule},
        every last row/.style={after row={\bottomrule}},
            my special cell/.style={@cell content=\color{blue}\bfseries#1},
            every row 3 column 2/.append style={
            postproc cell content/.append style={
            my special cell/.expanded={%
            \pgfkeysvalueof{/pgfplots/table/@cell content}%
            },
            },
        },]{\myLoadedTable}
\end{table}

\end{document}

在此輸入影像描述

答案2

請注意，我更新了其他答案使用該\pgfkeysgetvalue{/pgfplots/table/@cell content}{...}方法而不是my special cell/.expanded={...}為了檢索單元格內容不把它擴展到早期，在將其包裹進去之前\textcolor。

似乎可以siunitx與pgfplotstable, 1一起使用，但是手冊siunitx中沒有提到pgfplotstable。因此，現在我只建議那裡提到的方法，即使用/pgfplots/table/dec sep align.預設情況下，這在列內使用水平居中，但您可以使用dec sep align=l或指定不同的對齊類型dec sep align=r。開始了。 :-)

\documentclass{article}
\usepackage{xcolor}
\usepackage{pgfplotstable}
\pgfplotsset{compat=1.16}
\usepackage{booktabs}

\begin{filecontents*}{my-data.csv}
c1     & c2      & c3
Story4 & 33.7835 & 33.7878
Story3 & 38.4334 & 38.4334
Story2 & 37.7156 & 37.7156
Story1 & 38.4056 & 38.4034
\end{filecontents*}

\pgfplotstableread[col sep=&]{my-data.csv}\myLoadedTable

\begin{document}

\pgfplotstabletypeset[
  my numeric col/.style={fixed, fixed zerofill, precision=2, dec sep align},
  columns/c1/.style={column type={c}, column name=\textbf{Story}, string type},
  columns/c2/.style={my numeric col, column name=$U_x$},
  columns/c3/.style={my numeric col, column name=$U_y$},
  every head row/.style={before row={\toprule},after row=\midrule},
  every last row/.style={after row={\bottomrule}},
  my special cell/.style={@cell content=\textcolor{blue}{#1}},
  every row 3 column 2/.append style={
    postproc cell content/.append code={%
      \pgfkeysgetvalue{/pgfplots/table/@cell content}{\myTmpCellContents}%
      \pgfkeysalso{my special cell/.expand once={\myTmpCellContents}}%
    },
  }]{\myLoadedTable}

\end{document}

在此輸入影像描述

註腳

  1. 請參閱薛丁格的貓的答案！
