ASA 5505 vLAN 路由 - 2 LAN 1 WAN

我正在使用基本許可證設定 Cisco ASA 5505。

TCP/UDP通訊是從內部->外部、外部->內部、內部->安全進行的，這就是我想要的流量安全。

HTTP、SSH 和其他從內部 -> 安全的存取可以工作，但我無法從內部 -> 安全性（192.168.110.0 主機到 192.168.7.1 或 192.168.7.0 主機）執行 ping 操作。

如何啟用 ICMP？

配置：

interface Vlan1
 nameif inside
 security-level 100
 ip address 192.168.110.254 255.255.255.0
!
interface Vlan2
 nameif outside
 security-level 0
 pppoe client vpdn group birdie
 ip address removedIP 255.255.255.255 pppoe
!
interface Vlan3
 no forward interface Vlan1
 nameif secure
 security-level 50
 ip address 192.168.7.1 255.255.255.0
!
interface Ethernet0/0
 switchport access vlan 2
!
interface Ethernet0/1
!
interface Ethernet0/2
!
interface Ethernet0/3
!
interface Ethernet0/4
 switchport access vlan 3
!
interface Ethernet0/5
 shutdown
!
interface Ethernet0/6
 shutdown
!
interface Ethernet0/7
 shutdown
!
ftp mode passive
clock timezone EST -5
clock summer-time EDT recurring
access-list Outside-In extended permit icmp any any
access-list Outside-In extended permit tcp any any eq www
access-list Outside-In extended permit tcp any any eq https
access-list Outside-In extended permit tcp any any eq 5969
access-list inside_nat0_outbound extended permit ip any 192.168.111.0 255.255.255.224
access-list standardUser_splitTunnelAcl1 extended permit ip 192.168.111.0 255.255.255.0 any
access-list standardUser_splitTunnelAcl1 extended permit ip 192.168.110.0 255.255.255.0 any
access-list inside_in extended permit icmp any any
access-list inside_in extended permit ip any any
access-list secure_in extended permit icmp any any
access-list secure_in extended permit ip any any
pager lines 24
logging enable
logging asdm informational
mtu inside 1492
mtu outside 1492
mtu secure 1500
ip local pool vpnuser 192.168.111.5-192.168.111.20
icmp unreachable rate-limit 1 burst-size 1
asdm image disk0:/asdm-524.bin
no asdm history enable
arp timeout 14400
nat-control
global (outside) 1 interface
nat (inside) 0 access-list inside_nat0_outbound
nat (inside) 1 0.0.0.0 0.0.0.0
nat (secure) 1 192.168.7.0 255.255.255.0
static (inside,outside) tcp interface https 192.168.110.6 https netmask 255.255.255.255
static (inside,outside) tcp interface www 192.168.110.6 www netmask 255.255.255.255
static (inside,outside) tcp interface 5969 192.168.110.12 5969 netmask 255.255.255.255
static (inside,secure) 192.168.110.0 192.168.110.0 netmask 255.255.255.0
access-group inside_in in interface inside
access-group Outside-In in interface outside
access-group secure_in in interface secure
route outside 0.0.0.0 0.0.0.0 RemovedIP 1

答案1

在你的配置中，我覺得唯一奇怪的是static(inside,secure)聲明。這似乎是一個空操作，因為映射位址和真實位址是相同的。在我的配置中，我也有一個 dmz 類型的網絡，但沒有任何static(inside,dmz)聲明。 （我確實有static(dmz,outside) ...外部暴露的服務）。

不管怎樣，試著消除靜電，看看會產生什麼效果。
