配置 ssl mod 後 Apache Web 伺服器無法正常運作

tag-icon • tag-icon apache-2.2 ssl
配置 ssl mod 後 Apache Web 伺服器無法正常運作

我現在正在使用 Apache v2.4、php5.3.20 配置嵌入式伺服器 伺服器
版本：Apache/2.4.4 (Unix)
伺服器建置日期：2013 年 7 月 19 日 11:41:42
它確實運作得很好，但是當我配置它時對於SSL mod，它不能再處理http請求了。
我的伺服器現在可以透過 https 處理頁面，但是當我要求諸如htt p://10.38.13.238/test.php（故意錯誤）之類的頁面時，它會返回TCP 包（我使用wireshark to cactch），而沒有任何HTTP 包，例如「HTTP/1.1 200 OK”，而網頁瀏覽器總是說“當我收到空白頁時從 10.38.13.238" 傳輸。以下是更多資訊：
檔案 etc/apache2/httpd.conf：

<VirtualHost *:80>
DocumentRoot "/usr/local/www/apache2/htdocs"
ServerName mustang:80
ServerAdmin [email protected]
# Host-specific directory setup, options, etc
# Most of these options are likely to be set outside the VirtualHosts
# sections.
</VirtualHost>

...
# Secure (SSL/TLS) connections
Include /etc/apache2/extra/httpd-ssl.conf
#

檔案/etc/apache2/extra/httpd-ssl.conf：

<VirtualHost *:443>

#   General setup for the virtual host
DocumentRoot "/usr/local/www/apache2/htdocs/sslsite"
ServerName localhost:443
ServerAdmin [email protected]
ErrorLog "/usr/var/log/apache2/error_log"
TransferLog "/usr/var/log/apache2/access_log"

#   SSL Engine Switch:
#   Enable/Disable SSL for this virtual host.
SSLEngine on
SSLCertificateFile "/etc/apache2/server.crt"
SSLCertificateKeyFile "/etc/apache2/server.key"
SSLVerifyClient none
...
SSLOptions +StrictRequire +FakeBasicAuth +ExportCertData +StdEnvVars
<Directory />
    SSLRequireSSL
</Directory>
<FilesMatch "\.(cgi|shtml|phtml|php)$">
    SSLOptions +StdEnvVars
</FilesMatch>
<Directory "/usr/local/www/apache2/cgi-bin">
    SSLOptions +StdEnvVars
</Directory>

錯誤日誌檔：

[Wed Aug 28 09:22:58.702230 2013] [mpm_worker:notice] [pid 1969:tid 548459311104] AH00298: SIGHUP received.  Attempting to restart
[Wed Aug 28 09:22:58.812758 2013] [ssl:warn] [pid 1969:tid 548459311104] AH01906: RSA server certificate is a CA certificate (BasicConstraints: CA == TRUE !?)
[Wed Aug 28 09:22:58.814245 2013] [mpm_worker:notice] [pid 1969:tid 548459311104] AH00292: Apache/2.4.4 (Unix) OpenSSL/1.0.0j configured -- resuming normal operations
[Wed Aug 28 09:22:58.814285 2013] [core:notice] [pid 1969:tid 548459311104] AH00094: Command line: '/usr/sbin/httpd'
[Wed Aug 28 11:03:18.182732 2013] [mpm_worker:notice] [pid 1969:tid 548459311104] AH00295: caught SIGTERM, shutting down
[Wed Aug 28 11:03:33.782494 2013] [ssl:warn] [pid 2340:tid 547901157376] AH01906: RSA server certificate is a CA certificate (BasicConstraints: CA == TRUE !?)
[Wed Aug 28 11:03:33.990105 2013] [ssl:warn] [pid 2341:tid 547901157376] AH01906: RSA server certificate is a CA certificate (BasicConstraints: CA == TRUE !?)
[Wed Aug 28 11:03:33.991777 2013] [mpm_worker:notice] [pid 2341:tid 547901157376] AH00292: Apache/2.4.4 (Unix) OpenSSL/1.0.0j configured -- resuming normal operations
[Wed Aug 28 11:03:33.991847 2013] [core:notice] [pid 2341:tid 547901157376] AH00094: Command line: '/usr/sbin/httpd'

訪問日誌檔：

10.38.5.238 - - [28/Aug/2013:11:32:50 +0000] "GET /test.php?=PHPE9568F35-D428-11d2-A769-00AA001ACF42 HTTP/1.1" 200 2146
10.38.5.238 - - [28/Aug/2013:11:35:29 +0000] "GET /testxcache.php HTTP/1.1" 200 42
10.38.5.238 - - [28/Aug/2013:11:35:30 +0000] "GET /test.php HTTP/1.1" 200 47272
10.38.5.238 - - [28/Aug/2013:11:35:31 +0000] "GET /test.php?=PHPE9568F34-D428-11d2-A769-00AA001ACF42 HTTP/1.1" 200 2524
10.38.5.238 - - [28/Aug/2013:11:35:31 +0000] "GET /test.php?=PHPE9568F35-D428-11d2-A769-00AA001ACF42 HTTP/1.1" 200 2146
10.38.5.238 - - [28/Aug/2013:11:35:33 +0000] "GET /test.php HTTP/1.1" 200 47272
10.38.5.238 - - [28/Aug/2013:11:35:33 +0000] "GET /test.php?=PHPE9568F34-D428-11d2-A769-00AA001ACF42 HTTP/1.1" 200 2524
10.38.5.238 - - [28/Aug/2013:11:35:33 +0000] "GET /test.php?=PHPE9568F35-D428-11d2-A769-00AA001ACF42 HTTP/1.1" 200 2146
10.38.5.238 - - [28/Aug/2013:11:35:34 +0000] "GET /testxcache.php HTTP/1.1" 200 42
10.38.5.238 - - [28/Aug/2013:11:35:47 +0000] "GET /index.html HTTP/1.1" 200 45 10.38.5.238 - - [28/Aug/2013:11:36:07 +0000] "GET /test.php HTTP/1.1" 200 47272
10.38.5.238 - - [28/Aug/2013:11:36:07 +0000] "GET /test.php?=PHPE9568F35-D428-11d2-A769-00AA001ACF42 HTTP/1.1" 200 2146
10.38.5.238 - - [28/Aug/2013:11:36:07 +0000] "GET /test.php?=PHPE9568F34-D428-11d2-A769-00AA001ACF42 HTTP/1.1" 200 2524

任何建議將不勝感激。謝謝。
P/s：我按照這些網站為我的 Apache 伺服器設定 SSL
http://www.onlamp.com/2008/03/04/step-by-step-configuring-ssl-under-apache.html
http://forums.gentoo.org/viewtopic-p-6037402.html

答案1

HTTPS 只允許一個請求並立即關閉會話，因此它與 KeepAlives 不相容

答案2

我已經找到我的問題的答案了。我不太明白但如果我改變

KeepAlive On

到

KeepAlive Off

然後一切正常。我的伺服器現在可以處理 HTTP 和 HTTPS。不管怎麼說，還是要謝謝你。如果有人理解 KeepAlive 在這種情況下的含義，請告訴我。
