站對站 VPN

我面臨的問題是在 pfSense（版本 2.0.1）和 SonicWall Pro2040 增強版（韌體版本：SonicOS 增強版 4.2.1.4-7e）之間建立網站到網站 VPN。所有配置均已正確完成，但我在 sonicwall 中仍然收到以下錯誤 -

“有效負載處理失敗”

第 1 階段和第 2 階段正確通過，但「有效負載處理」出現問題，我發現這可能是共享金鑰不匹配，但我仔細檢查，兩個防火牆中的共享金鑰都沒有不匹配。它還在 sonicwall 中顯示隧道處於活動狀態

pfSense 的日誌如下 -

答案1

這是我的 sonicwall 和 pfsense 的設定：

Sonicwall 上的常規選項卡：

Authentication Method: IKE using Pre shared Secret

Name:  pfSense Site-to-Site PN

IPsec Primary Gateway Name or Address: 1.1.1.1 | IP for pfSense

IPsec Secondary Gateway Name or Address: 0.0.0.0

Shared Secret: Shared secret for this connection

Local IKE ID:  2.2.2.2 | Select ‘IP Address’ from the drop down menu and then type WAN IP of Sonicwall



Network tab on Sonicwall:

Local Networks

Choose local network from list: 192.168.21.0 | Create an address object for the network or you can use the built in one ‘LAN Subnets’

Destination Networks

Choose destination network from list: 192.168.65.0 | Create an address object for the remote LAN network



Proposals Tab:

IKE (Phase 1) Proposal

By default pfSense supports ‘Main Mode’ and ‘Aggressive’.

Exchange: Aggressive

DH Group: Group 2

Encryption: 3DES

Authentication: SHA1

Life Time (seconds): 28800

Ipsec (Phase 2) Proposal

Protocol: ESP

Encryption: 3DES

Authentication: SHA1

Enable Perfect Forward Secrecy: Checked

Life Time: 86400



Advanced Tab:

Check ‘Enable Keep Alive’

相應的pfSense設定：

Phase 1:

Authentication method: Mutual PSK

Negotiation Mode: Aggressive

My identifier: 1.1.1.1 (IP Address of pfSense WAN)

Peer identifier: 2.2.2.2 (IP Address of Sonicwall)

Pre Shared Key: Your pre share key

Policy Generation: Default

Proposal Checking: Obey

Encryption Algorithm: 3DES

Hash algorithm: SHA1

DH key group: 2

Lifetime: 28800



Advanced options

Nat Traversal: Enable

Dead Peer Detection: Check Enable DPD



Phase 2:

Mode: Tunnel

Local Network: 192.168.65.0/24

Remote Network: 192.168.21.0/24

Protocol: ESP

Encryption algorithms: 3DES

Hash algorithms: SHA1

PFS key group: 2

Lifetime: 84600

請看我的文章如何使用 pfsense 配置 sonicwall。
